Peugeot iOn (2017 year). Instruction - part 11

Audio and Telematics

159

Ion_en_Chap10a_RDE2_ed01-2016

QUESTION

ANSWER

SOLUTION

The quality of reception of
the radio station listened
to gradually deteriorates
or the stored stations do
not function (no sound,
87.5 MHz is displayed...).

The vehicle is too far from the transmitter used by the station
listened to or there is no transmitter in the geographical area
through which the vehicle is travelling.

Activate the RDS function to enable the system
to check whether there is a more powerful
transmitter in the geographical area.

The environment (hills, buildings, tunnels, basement car parks...)
block reception, including in RDS mode.

This phenomenon is normal and does not indicate
a failure of the audio equipment.

The aerial is absent or has been damaged (for example when going
through a car wash or into an underground car park).

Have the aerial checked by a PEUGEOT dealer.

Sound cut-outs of 1 to
2 seconds in radio mode.

During this brief sound cut-out, the RDS searches for any frequency
permitting better reception of the station.

Deactivate the RDS function if the phenomenon is
too frequent and always on the same route.

Traffic announcement TA is
displayed. I do not receive
any traffic information.

The radio station does not broadcast traffic information.

Tune to a radio station which broadcasts traffic
information.

The stored stations are not
found (no sound,
87.5 MHz is displayed...).

An incorrect waveband is selected.

Press the SRC/TEL button to return to the
waveband (FM1 or FM2) on which the stations
are stored.

Audio and Telematics

160

Ion_en_Chap10a_RDE2_ed01-2016

QUESTION

ANSWER

SOLUTION

The CD is ejected
automatically or is not
played by the player.

The CD is inserted upside down, is unplayable, does not contain any
audio data or contains an audio format which the player cannot play.
The CD is protected by an anti-pirating protection system which is
not recognised by the audio equipment.

Check that the CD is inserted in the player the
right way up.

Check the condition of the CD: the CD cannot
be played if it is too damaged.

Check the content in the case of a recorded
CD: consult the advice in the "Audio" section.

The audio equipment's CD player does not
play DVDs.

Due to their quality level, certain writeable
CDs will not be played by the audio system.

The CD player sound is
poor.

The CD used is scratched or of poor quality.

Insert good quality CDs and store them in suitable
conditions.

The audio settings (bass, treble, ambience) are unsuitable.

Set the treble or bass level to 0, without selecting
an ambience.

The Bluetooth connection
is cut.

The battery of the peripheral may not be sufficiently charged.

Recharge the battery of the peripheral device.

The message "USB device
error" is displayed on the
screen.

The USB memory stick is not recognised.

Use only USB memory sticks formatted to FAT 32
(28-bit file allocation table).

A telephone connects
automatically,
disconnecting another
telephone.

Automatic connection overrides manual connection.

Modify the telephone settings to remove
automatic connection.

Audio and Telematics

161

Ion_en_Chap10a_RDE2_ed01-2016

QUESTION

ANSWER

SOLUTION

An iPod is not recognised
when connecting to the
USB port.

The iPod is of a generation that is not compatible with the USB
connection.

The hard disk or device
is not recognised when
connecting to the USB
port.

Some hard disks and devices need a power supply greater than is
provided by the audio system.

Connect the device to the 230 V socket, the 12 V
socket or an external power supply.
Caution: ensure that the device does not transmit
a voltage greater than 5 V (risk of destruction of
the system).

When streaming, the sound
cuts momentarily.

Some telephones prioritise connection of the "hands-free" profile.

Delete the "hands-free" connection profile to
improve streaming.

In "Random all" play, not all
of the tracks are played.

In "Random all" play, the system can only take into account up to
999 tracks.

With the engine off, the
audio system switches off
after a few minutes of use.

When the engine is switched off, the audio system operating time
depends on the battery charge.
The switch-off is normal: the audio system switches to economy
mode and switches off to prevent discharging the vehicle's battery.

Start the vehicle's engine to increase the battery
charge.

The message "the audio
system is overheated"
appears on the display.

In order to protect the installation if the surrounding temperature
is too high, the audio system switches to an automatic thermal
protection mode leading to a reduction of the volume or stopping of
the playing of the CD.

Switch the audio system off for a few minutes to
allow the system to cool.

Audio and Telematics

163

Ion_en_Chap10b_KENWOOD_ed01-2016

KENWOOD - KDC-X7000DAB

For more information, consult the KENWOOD
user guide provided with the system.

For obvious safety reasons, the vehicle
must be stationary when the driver
carries out operations which require
sustained attention.

Short press: on.
Long press: off.

Rotation: adjust the volume, navigate
in a list.
Press: confirm.

Change audio source.

Short press: search for a service.
Long press: updating of the list of
stations available.

Abandon the current operation.
Go up one level.
Reject or end a call.

Select an analogue waveband FM1 /
FM2 / FM3 / MW / LW.
Select a digital waveband DB1 /
DB2 / DB3.

Change of search method (automatic
or manual).

Navigate in a list.

Short press: search for a radio
station, a frequency or a service,
search for a previous/next track or
file, navigate in a list.
Long press: Rewind / fast forward.

Short press: select a stored radio
station.
Long press: store a radio station.

Short press: accept an incoming
call, switch between two calls, enter
Bluetooth mode.
Long press: smartphone voice
commands via the system.

Fitting the control
panel.

Removing the control
panel.

Alphabetical index

164

Ion_en_Chap11_index-alpha_ed01-2016

Accessories ..................................................58
Access to bulbs ................................... 127, 131
Adjusting headlamps ....................................56
Adjusting head

restraints .....................................................32

Adjusting seat .........................................32 , 34
Advice on driving .......................................... 87
Airbags ....................................................70, 77
Airbags, curtain .......................................72, 7 3
Airbags, front...........................................70, 73
Airbags, lateral ........................................72, 7 3
Air conditioning .................................42 , 43, 4 5
Air vents ........................................................ 41
Anti-lock braking

system (ABS) ..............................................63

Anti-slip regulation (ASR) .............................65
Assistance call .............................................. 61
Audio streaming

(Bluetooth) ................................................ 151

Daytime running lamps .........................55, 130
Deactivating the passenger

airbag ....................................................70, 77

Deactivating the passenger and rear

window control switches .............................30

Filter, passenger compartment ................... 111
Fitting a wheel ............................................. 121
Fittings, interior .............................................38
Fitting the mat ...............................................39
Flaps, charging ............................................. 31
Flashing indicators ................ 55 , 129 , 131 , 132
Foglamp, rear ........................................54, 133

Defrosting / demisting, front .........................46
Dimensions ................................................. 142
Direction indicators .......................55 , 129 , 132
Display screen ........................................ 21, 22
Door pockets .................................................38
Doors .............................................................28
Drive selector ................................................90

Electric motor ..............................................140
Electronic brake force distribution

(EBFD) ........................................................63

Electronic stability programme (ESP). .........65
Emergency braking assistance (EBA) ....63, 6 4
Emergency call ............................................. 61
Emergency warning lamps ...........................59
Engine brake .................................................66
Engine brake reduction indicator lamp ...10, 66
Environment ....................................................9

Battery, 12 V ........................................ 109, 113
Battery, main ......................................... 97, 140
Bluetooth (hands-free) ................................ 152
Bonnet .........................................................106
Bonnet stay .................................................106
Brake discs .................................................. 111
Brake lamps ..........................................59, 132
Brake lamps, automatic operation ................59
Brakes ......................................................... 111
Braking assistance system ...........................63
Bulbs (changing) ................................. 126, 131

CD, MP3 .............................................. 149, 150
Changing a bulb .................................. 126, 131
Changing a fuse ..........................................134
Changing a wheel ....................................... 121
Changing a wiper blade .............................. 112
Charging, fast ..............................................104
Charging, normal .......................................... 97
Charging time .............................................. 140
Checking components .........................107, 111
Checking the levels ............................. 109, 110
Checking tyre pressures

(using the kit) ............................................ 117

Child lock .................................................85 , 86
Children .............................................81 , 83 , 85
Child seats ............................69, 7 4 -76, 8 0, 8 1
Child seats, conventional ..............................80
Child seats, ISOFIX ................................ 83-85
Closing the boot ............................................29
Compartment, front ..................................... 107
Compartment, rear .....................................108
Control, heated seats ....................................34
Control stalk, lighting ....................................53
Control stalk, wipers .....................................56
Control unit ....................................................99
Courtesy lamp ...............................................57
Cup holder .....................................................38

Alphabetical index

165

Ion_en_Chap11_index-alpha_ed01-2016

Foglamps, front .....................................54, 130
Folding the rear seat backrest ......................34
Folding / unfolding the door

mirrors .........................................................36

Fuses ...........................................................134

Hazard warning lamps ..................................59
Headlamp adjustment ...................................56
Headlamps, automatic illumination ..............55
Headlamps, dipped beam ...........................130
Headlamps, main beam .............................. 129
Head restraints........................................ 32-34
Heating ..........................................................43
Horn...............................................................59

Jack ............................................................. 121

Key with remote control ..........................25 , 27
Kit, hands-free ............................................ 152
Kit, temporary puncture

repair ......................................................... 117

Immobiliser, electronic ............................26, 2 7
Indicator, energy consumption /

generation ...................................................20

Indicator lamps, operation ............................ 11
Indicators, direction ......................................55
Inflating tyres .......................................117, 144
Instrument panel ........................................... 10
Isofix mountings ...................................... 83-85

Markings, identification ............................... 143
Mat ................................................................39

Opening the boot ..........................................29
Opening the front compartment .................106

Pads, brake ................................................. 111
Parking brake ........................................ 89, 111
Pedestrian horn ............................................60
PEUGEOT Connect Assistance ................... 61
PEUGEOT Connect Packs ........................... 61
PEUGEOT Connect SOS ............................. 61
Player, MP3 CD ................................... 149, 150
Port, USB ..............................................40, 150
Pressures, tyre ..............................92, 143, 144
Pre-tensioning seat belts ..............................69

Mirror, rear view ............................................37
Mirrors, door..................................................36
Mountings, Isofix ..................................... 83-85
MP3, CD .............................................. 149, 150

Labels, identification ................................... 143
Lamps, front ................................................ 126
Lamps, rear ................................................. 131
Level, brake fluid .........................................109
Level, engine coolant ..................................109
Level, heating system fluid .........................109
Levels and checks .......................107, 109, 110
Level, screenwash fluid ..............................109
Lighting, automatic off ..................................55
Lighting dimmer ...................................... 21, 22
Locking from the inside .................................28

Number plate lamps .................................... 133

Alphabetical index

166

Ion_en_Chap11_index-alpha_ed01-2016

Selector, drive ...............................................90
Serial number, vehicle ................................ 143
Service indicator ...........................................22
Sidelamps ........................................... 129, 132
Side repeater .............................................. 131
Snow chains ................................................ 125
Socket, 12 V accessory ..........................38 , 39
Speedometer ................................................ 10
Stability control (ESP) ...................................65
Starting the vehicle .................................88 , 90
Stopping the vehicle ...............................88 , 90
Storage ..........................................................38
Sun visor .......................................................39

Technical data ..................................... 140, 141
Third brake lamp ......................................... 133
Total distance recorder ................................. 21
Towing another vehicle ............................... 139
Traction control (ASR) ..................................65
Traffic information (TA) ............................... 148
Tyres ......................................................92, 144
Tyre under-inflation detection ........... 17 , 24 , 92

Ventilation ................................................41-43

Warning and indicator lamps ............ 11, 1 4 , 15
Warning lamp, seat belts ..............................67
Weights ....................................................... 141
Wheel, spare ...............................................144
Window controls ...........................................30
Wiper blades (changing) ............................. 112
Wiper, rear.....................................................57
Wipers ...........................................................56

Safety, children ......................74-76 , 81 , 83 , 84
Screen menu map ....................................... 157
Screenwash ..................................................56
Seat belts .......................................... 67-69, 80
Seats, front ....................................................32
Seats, heated ................................................34
Seats, rear .....................................................34

Under-inflation detection, tyre. ......... 17 , 24 , 92
Unlocking from the inside .............................28
USB (PEUGEOT Connect) .....................38 , 40

Protecting children ................. 74 -76, 8 1, 8 3-86
Puncture ...................................................... 117

Radio ........................................................... 147
Range ...................................................... 21, 24
Rear screen, demisting .................................46
Recharging the main battery ........................97
Recirculation / exterior air intake ..................43
Reminder, lighting on ....................................54
Remote control ........................................ 27, 47
Removing a wheel ...................................... 121
Removing the mat .........................................39
Replacing bulbs .................................. 126, 131
Replacing fuses ..........................................134
Replacing the passenger compartment

filter ........................................................... 111

Reservoir, screenwash ...............................109
Reversing lamps ......................................... 132

Ion_en_Chap11_index-alpha_ed01-2016

After a battery disconnection, a code must be
entered for operation of the audio system.
A maximum of 5 attempt are possible. For the
last two attempts, a wait of around 15 minutes
is imposed.
Keep your code in a safe place, never inside
the vehicle.
When undertaking a long trip or journey,
however, it is advisable to take the code with
you along with your personal papers.

AUDIO SYSTEM
CODE

08-16

Reproduction or translation of all or part of
this document is prohibited without written
authorisation from Automobiles PEUGEOT.

Automobiles PEUGEOT declares, by
application of the provisions of the European
legislation (Directive 2000/53) relating to End
of Life Vehicles, that it achieves the objectives
set by this legislation and that recycled
materials are used in the manufacture of the
products that it sells.

Printed in the EU

Anglais

www.peugeot.com

Anglais

16ION.0040

*16ION.0040*

Content .. 9 10 11
