Peugeot Expert VU (2016 year). Instruction

479

Audio and Telematics

Expert_en_Chap10c_RCC-1_ed01-2016

Media

QUESTION

ANSWER

SOLUTION

Playback of my uSB
memory stick starts only
after a very long wait
(around 2 to 3 minutes).

Some files supplied with the memory stick may greatly slow down
access to reading the memory stick (multiplication by 10 of the
catalogue time).

Delete the files supplied with the memory stick
and limit the number of sub-folders in the file
structure on the memory stick.

Some characters in the
media information are not
displayed correctly while
playing.

the audio system does not display some types of characters.

use standard characters to name tracks and
folders.

Playing of streaming files
does not start.

the peripheral device connected does not support automatic play.

Start the playback from the device.

the names of tracks and
the track length are not
displayed on the screen
when streaming audio.

the Bluetooth profile does not allow the transfer of this information.

480

Audio and Telematics

Expert_en_Chap10c_RCC-1_ed01-2016

QUESTION

ANSWER

SOLUTION

I cannot connect my
Bluetooth telephone.

the telephone's Bluetooth function may be switched off or the
telephone may not be visible.

Check that your telephone's Bluetooth function is
switched on.
Check in the telephone settings that it is "visible
to all".

the Bluetooth telephone is not compatible with the system.

You can check the compatibility of your
telephone at the brand's website (services).

the volume of the
telephone connected
in Bluetooth mode is
inaudible.

the volume depends both on the system and on the telephone.

Increase the volume of the audio system, to
maximum if required, and increase the volume of
the telephone if necessary.

the ambient noise level has an influence on the quality of
telephone communication.

Reduce the ambient noise level (close the
windows, reduce the booster fan speed, slow
down, ...).

Some contacts are
duplicated in the list.

the options for synchronizing contacts are synchronizing the
contacts on the SIM card, the contacts on the telephone, or both.
When both synchronizations are selected, some contacts may be
duplicated.

Select "Display SIM card contacts" or "Display
telephone contacts".

Contacts are not shown in
alphabetical order.

Some telephones offer display options. Depending on the settings
chosen, contacts can be transferred in a specific order.

Modify the display setting in the telephone
directory.

the system does not
receive SMS text messages.

the Bluetooth mode does not permit sending SMS text messages
to the system.

Telephone

481

Audio and Telematics

Expert_en_Chap10c_RCC-1_ed01-2016

QUESTION

ANSWER

SOLUTION

In changing the setting
of treble and bass the
equalizer setting is
deselected.

the selection of an equalizer setting imposes the settings for treble
and bass and vice-versa.

Modify the treble and bass or equalizer settings
to obtain the desired musical ambience.

In changing the equalizer
setting, treble and bass
return to zero.

When changing the
balance settings, the
distribution setting is
deselected.

the selection of a distribution setting imposes the balance settings
and vice-versa.

Modify the balance or distribution settings to
obtain the desired musical ambience.

When changing a
distribution setting,
the balance setting is
deselected.

Settings

482

Audio and Telematics

Expert_en_Chap10c_RCC-1_ed01-2016

QUESTION

ANSWER

SOLUTION

there is a difference in
sound quality between the
different audio sources.

For optimum sound quality, the audio settings for Loudness,
Ambience, treble, Bass and Volume can be adapted to the different
sound sources, which may result in audible differences when
changing source.

Check that the audio settings for Loudness,
Ambience, treble, Bass and Volume are adapted
to the sources listened to. Adjust the Balance,
treble and Bass to the middle position, select the
"None" musical ambience and set the loudness
correction to the "Active" position in CD mode or
to the "Inactive" position in radio mode.

With the engine off, the
system switches off after a
few minutes of use.

When the engine is switched off, the system's operating time
depends on the state of charge of the battery.
the switch-off is normal: the system switches to economy mode
and switches off to prevent discharging of the vehicle's battery.

Start the vehicle's engine to increase the battery
charge.

483

Audio and Telematics

Expert_en_Chap10d_RD6_ed01-2016

Bluetooth

audio system

Contents

First steps

484

Steering mounted controls - type 1

485

Steering mounted controls - type 2

486

Menus 487
Radio 488
DAB (Digital Audio Broadcasting) radio

490

Media 492
telephone 497
Frequently asked questions

502

Your audio system is coded in such a way that it will only operate
in your vehicle.

the different functions and adjustments described vary
according to the version and configuration of your vehicle.

As a safety measure and because it requires the sustained
attention of the driver, the pairing of your Bluetooth telephone to
the Bluetooth hands-free audio system must only be carried out
with the vehicle stationary and the ignition on.
to avoid discharging the battery, the audio system may switch
off after a few minutes if the engine is not running.

484

Audio and Telematics

First steps

Press: on / off
Rotate: adjust volume.

Short press: change audio source
(Radio; uSB; AuX (if a device is
connected); CD; Streaming).
Long press: display the telephone
menu (if a telephone is connected).

Radio:
Short press: display the list of radio
stations.
Long press: update the list.
Media:
Short press: display the list of folders.
Long press: display the sorting
options.

Select the screen display mode,
between:
Date; Audio functions; trip computer;
telephone.

Adjust audio settings:
Front/rear fader; left/right balance;
bass/treble; loudness; audio
ambience.
Activation / deactivation of automatic
volume adjustment (linked to the
speed of the vehicle).

Radio:
Manual step by step search up /
down for radio stations.
Select previous / next MP3 track.
Media:
Select previous / next folder / genre /
artist / playlist on the uSB device.
Scroll in a list.

Abandon the current operation.
go up one level (menu or folder).

Confirm or display contextual menu.

Buttons 1 to 6.
Short press: select the preset radio
station.
Long press: preset a station.

Radio:
Automatic step by step search up /
down for radio stations.
Media:
Select previous / next CD, uSB,
streaming track.
Scroll in a list.

Access to main menu.

Activate / Deactivate tA (traffic
announcements)
Long press: select type of
announcement.

Select waveband: FM / DAB / AM.

485

Audio and Telematics

Expert_en_Chap10d_RD6_ed01-2016

Steering mounted controls - type 1

Radio:
Short press: display the list of radio
stations.
Long press: update the list.
Media:
Short press: display the list of folders.
Long press: display the sorting
options.

Decrease volume.

Radio:
Select the previous / next preset
radio station.
Select the previous / next item in a
menu or a list.
Media:
Select of the previous / next track.
Select the previous / next item in a
menu or a list.

Mute / Restore sound by
simultaneously pressing the increase
and decrease volume buttons.

Other than telephone calls:
Short press: change audio source
(Radio; uSB; AuX (if a device is
connected); CD; Streaming), confirm
if the "Telephone" menu is open.
Long press: open the "Telephone"
menu.
In the event of a telephone call:
Short press: accept the call.
Long press: reject the call.
During a telephone call:
Short press: open the contextual
telephone menu.
Long press: end the call.

Confirm a selection.

Increase volume.

486

Audio and Telematics

Steering mounted controls - type 2

Decrease volume.

Mute / Restore sound.

Other than telephone call:
Short press: change audio source
(Radio; uSB; AuX (if a device is
connected); CD; Streaming), confirm
if the "Telephone" menu is open.
Long press: open the "Telephone"
menu.
In the event of a telephone call:
Short press: accept the call.
Long press: reject the call.
During a telephone call:
Short press: open the contextual
telephone menu.
Long press: end the call.

Increase volume.

Access to the main menu.

Start voice recognition of your
smartphone via the system.

Radio:
Short press: display the list of radio
stations.
Long press: update the list.
Media:
Short press: display the list of folders.
Long press: display the sorting
options.

Radio:
Select the previous / next preset
radio station.
Select the previous / next item in a
menu or a list.
Media:
Select the previous / next track.
Select the previous / next item in a
menu or a list.

Press the thumbwheel: confirm.

487

Audio and Telematics

Expert_en_Chap10d_RD6_ed01-2016

Menus

"Multimedia": Media settings, Radio
settings.

Depending on version.

Move from one menu to another.

Enter a menu.

"Trip computer".

"Maintenance": Diagnosis, Warning
log, ...

"Connections": Manage
connections, search for devices.

"Telephone": Call, Directory
management, telephone
management, End call.

"Personalisation-configuration":
Define the vehicle settings, Choice
of language, Display configuration,
Choice of units, Date and time
adjustment.

Press the "MENU" button.

488

Audio and Telematics

RDS

Short procedure

Long procedure

the external environment (hills,
buildings, tunnels, basement car
parks, ...) may block reception,
including in RDS mode. this is a
normal effect of the way in which radio
waves are transmitted and does not
indicate any failure of the audio system.

Press the "MENU" button.

Select "Audio functions".

Press OK.

Select the "FM waveband
preferences" function.

Press OK.

Select "RDS".

Press OK, RDS is displayed in the
screen.

In "Radio" mode, press the OK button to
activate or deactivate RDS directly.

RDS, if activated, enables you to continue
listening to the same station by automatic
retuning to alternative frequencies.
However, in certain conditions, coverage
of an RDS station may not be assured
throughout the country as radio stations
do not cover 100 % of the territory. this
explains the loss of reception of a station
that can occur during a journey.

If RDS is not available, the RDS symbol
appears barred in the screen.

Radio

Selecting a station

Press the SOURCE button
repeatedly and select the radio.

Press this button to select a
waveband (FM / AM / DAB).

Press one of the buttons to carry
out an automatic search for radio
stations.

Press one of the buttons to carry out
a manual search up / down for radio
frequencies.

Press this button to display the list of
stations received locally.
to update this list, press for more
than two seconds. the sound is cut
while updating.

489

Audio and Telematics

Expert_en_Chap10d_RD6_ed01-2016

Receiving TA messages

Press the TA button to activate or
deactivate traffic messages.

the tA (traffic Announcement)
function gives priority to tA alert
messages. to operate, this function
needs good reception of a radio station
transmitting this type of message.
When a traffic report is transmitted, the
current audio source (Radio, CD, ...)
is interrupted automatically to play the
tA message. Normal playback of the
audio source resumes at the end of the
transmission of the message.

take care when increasing the volume
while listening to tA messages. the
volume may prove too high on return to
the original audio source.

Select "RadioText (TXT) display"
and confirm OK to save.

Select or deselect categories.

With the radio displayed on the
screen, press OK to display the
contextual menu.

Make a long press on this button to
display the list of categories.

Receiving INFO messages

the INFo function gives priority to tA
traffic announcements. to be active,
this function needs good reception
of a radio station that transmits this
type of message. When a message is
transmitted, the current audio source
(Radio, CD, uSB, ...) is interrupted
automatically to receive the INFo
message. Normal play resumes at the
end of the message transmission.

Radio text is information transmitted by
the radio station related to the current
programme or song.

Display RADIO TEXT

Activate or deactivate the reception of
the corresponding messages.

490

Audio and Telematics

DAB (Digital Audio Broadcasting) radio

Display options:
if active but not available, the display will
be struck out.

Preset radio station, buttons 1 to 6.
Short press: select the preset radio
station.
Long press: preset a radio station.

Display the name of the multiplex
service being used.

Display the list of all radio stations and
"multiplexes".

Represents the signal sterngth for the
band being listened to.

Display Radiotext (tXt) for the current
radio station.

Display the name of the current radio
station.

If the current "DAB" radio station is not available
on "FM", "DAB FM" is barred.

When changing region, an update
of the list of preset radio stations is
advisable.

491

Audio and Telematics

Expert_en_Chap10d_RD6_ed01-2016

Select "Multimedia" and confirm.

Select "DAB / FM auto tracking"
and confirm

Long press: select the desired
categories of announcements from
transport, News, Entertainment and
Flash special (availability according
to the station).

Change of station within the same
"multiplex service".

Press the "Menu" button.

Start a search for the previous / next
"multiplex service".

Change band (FM1, FM2, DAB, ...)

Digital radio provides a superior audio
quality and also additional categories of
traffic announcements (tA INFo).
the different "multiplex services"
offer a choice of radio stations in
alphabetical order.

Digital radio

When the radio station is displayed in
the screen, press on "OK" to display
the contextual menu.
(Frequency search (RDS), DAB / FM
auto tracking, Radiotext (tXt) display,
Information on the station, ...)

DAB / FM tracking

"DAB" does not have 100% coverage of
the country.
When the digital signal is weak,
"DAB / FM auto tracking" allows you to
continue listening to the same station,
by automatically switching to the
corresponding analogue "FM" station
(if there is one).
When "DAB / FM auto tracking" is
active, the DAB station will be selected
automatically.

If "DAB / FM auto tracking" is activated,
there will be a difference of a few
seconds in the programme when the
system changes to analogue "FM" radio,
with sometimes a variation in volume.

If the "DAB" station you are listening
to is not available on "FM" ("DAB/FM"
option barred), or if "DAB / FM auto
tracking" is not on, the sound will be cut
when the digital signal is too weak.

492

Audio and Telematics

Media

USB player

this unit consists of a uSB port and an
auxiliary Jack socket, depending on model.

Insert a uSB memory stick into the uSB port
or connect a uSB peripheral device to the uSB
port using a suitable cable (not supplied).
the system changes automatically to "uSB"
source.

the system creates playlists
(temporary memory), which can take
from a few seconds to several minutes
on the first connection.
Reducing the number of non-music
files and the number of folders reduces
this waiting time. Playlists are updated
every time a new uSB memory stick is
connected.

Press this button to display the
contextual menu for the Media
function.

Press this button to select the play
mode.

Press this button to confirm.

Play mode

the play modes available are:
-

Normal: the tracks are played in order,
depending on the classification of the
selected files.

Random: the tracks in an album or folder
are played in a random order.

Random on all media: all of the tracks
saved in the media are played in random
order.

Repeat: the tracks played are only those
from the current album or folder.

the choice made is displayed at the top of the
screen.

While connected by uSB, the portable
device may be charged automatically.

493

Audio and Telematics

Expert_en_Chap10d_RD6_ed01-2016

Choosing a track to play

File classification

Playing files

Make a long press on this button to
display the different classifications.

Choose by "Folder" / "Artist" /
"Genre" / "Playlist"*.

Press OK to select the desired
classification, then press OK again
to confirm.

Make a long press on this button to
display the chosen classification.

Navigate in the list using the left /
right and up / down buttons.

Confirm the selection by pressing
OK.

Press one of these buttons to go to
the previous / next track in the list.
Press and hold one of these buttons
for fast forward or fast back.

Press one of these buttons to go
to the next "Folder" / "Artist" /
"Genre" / "Playlist"* in the list.

* Depending on availability and the type of

device used.

Press one of these buttons to go to
the previous / next track.

Press one of these buttons to go to
the previous / next folder.

494

Audio and Telematics

Jack auxilary (AUX) socket

Connect the portable device (MP3 player, …) to
the auxiliary Jack socket using an audio cable
(not supplied).

Press the SOURCE button several
times in succession and select
"AUX".

First adjust the volume on your portable device
(to a high level). then adjust the volume on
your audio system. operation of controls is via
the portable device.

Do not connect a device to both the
Jack auxiliary socket and the uSB port
at the same time.

CD player

Insert circular compact discs only.
Some anti-pirating systems, on original discs
or CDs copied using a personal recorder, may
cause faults which are no reflection on the
quality of the vehicle's player.
Insert a CD in the player, play begins
automatically.

to play a disc which has already
been inserted, press the SOURCE
button several times in succession
and select CD.

Press one of the buttons to select a
track on the CD.

Press the LIST button to display the
list of tracks on the CD.

Press and hold one of the buttons for
fast forward or fast back.

Playing an MP3 compilation

Insert an MP3 CD compilation in the player.
the audio equipment searches for all of the
music tracks, which may take anything between
a few seconds and several tens of seconds,
before play begins.

on a single disc, the CD player can
read up to 255 MP3 files spread over
8 folder levels.
However, it is advisable to keep to a
limit of two levels to reduce the access
time before the CD is played.
While the CD is being played, the folder
structure is not followed.
All of the files are displayed on a single
level.

External CD players connected via the
uSB port are not recognised by the
system.

Peugeot Expert VU (2016 year). Instruction - part 31
