Peugeot Expert VU (2016 year). Instruction

Access

Expert_en_Chap02_ouvertures_ed01-2016

Unfolding / Folding the key

If you do not press the button, you risk
damaging the remote control.

It allows the central locking or unlocking of the
vehicle using the door lock or from a distance.
It also allows the vehicle to be located, the fuel
filler cap to be removed and refitted and the
engine to be started or switched off, as well as
providing protection against theft.

Key, remote control

this separation of cab and loading
area locking provides security in use.
It allows you to prevent access to the
part of the vehicle where you are not
present.

What is the point
of total or selective
unlocking?

total unlocking allows all of the vehicle's doors
(front, side and rear) to be unlocked.

the remote control buttons are not
active when the ignition is switched on.

Selective unlocking allows either the cab
doors, or the loading area doors (side and
rear) to be unlocked.

Key

the key allows the central locking or unlocking
of the vehicle using the door lock.
It also allows the fuel filler cap to be removed
and refitted and the engine started or switched
off.

F Press this button to unfold or fold the key.

Access

Expert_en_Chap02_ouvertures_ed01-2016

F to activate this selectivity

between cab and loading
area, switch the ignition on and
press this button for more than
2 seconds.

Its indicator lamp comes on.

the modification is confirmed by an audible
signal and, depending on equipment, the
display of a message.

F to deactivate this selectivity and

return to total unlocking, switch
the ignition on and press this
button for more than 2 seconds.

Its indicator lamp goes off.

By default, selectivity between cab and
loading area is activated.

Total unlocking

Using the remote control

F Press one of these buttons

(depending on equipment) to
unlock the vehicle.

unlocking is signalled by the rapid
flashing of the direction indicators for
about two seconds.
Depending on version, the door mirrors
unfold at the same time.

If fitted to your vehicle, pressing
and holding this button allows the
windows to be opened. the window
stops when you release the button.

Using the key

Using the remote control with
electric sliding side door(s)

F to

totally unlock the

vehicle and open the
side door, press and
hold this button until the
door has opened.

F to

totally unlock the vehicle

without opening the side door,
press this button.

Programming

F to

totally unlock the vehicle, turn the key

towards the front of the vehicle.

F then to open the door, pull the handle.
If your vehicle has an alarm, this is not
deactivated. opening a door will trigger the
alarm, which can then be stopped by switching
the ignition on.

Cab and loading area selectivity
deactivated.

Access

Expert_en_Chap02_ouvertures_ed01-2016

Using the key

F to unlock the cab doors only,

make an initial press on this
button.

F to unlock the loading area

doors (side and rear), press this
button again

Selective unlocking

unlocking is confirmed by rapid flashing
of the direction indicators for about
two seconds.
Depending on version, the electric door
mirrors unfold at the same time.

F to unlock the vehicle, turn the key to the

front of the vehicle.

F then pull the handle to open the door.
If your vehicle has an alarm, this is not
deactivated. opening a door will trigger the
alarm, which can then be stopped by switching
the ignition on.

Cab and loading area selectivity
activated.

Using the remote control

If fitted to your vehicle, pressing
and holding this button opens the
windows. the window stops when
you release the button.

F to unlock the loading area only,

press this button.

If fitted to your vehicle:

Using the remote control with
electric sliding side door(s)

F Press this button to

unlock the loading area
only and open the side
door, press and hold
this button until the door
has opened.

F Press this button to unlock

the loading area only, without
opening the side door.

Unlocking

Access

Expert_en_Chap02_ouvertures_ed01-2016

Using the remote control

F to unlock the vehicle, press this

button.

unlocking is signalled by the rapid
flashing of the direction indicators for
about two seconds.
Depending on version, the door mirrors
unfold at the same time.

Driving with the doors locked may
render access for the emergency
services difficult in an emergency.
As a safety measure (children on
board), never leave the vehicle without
taking your remote control, even for a
short period.

Ensure that no person or object might
prevent the correct closing of the
windows.
Be particularly aware of children when
operating the windows.

Locking

F to unlock the vehicle totally, turn the key

to the rear of the vehicle.

If your vehicle has an alarm, this will not be
activated.

F to lock the vehicle totally, press

this button.

Using the key

If a door is not fully closed (except
the right-hand door with side-hinged
doors):
-

vehicle stationary and the engine
running, this warning lamp
comes on, accompanied by an
alert message for a few seconds,

vehicle moving (speed above
6 mph (10 km/h)), this warning
lamp comes on, accompanied
by an audible signal and an alert
message for a few seconds.

If fitted to your vehicle, pressing
and holding this button closes the
windows. the window stops when
you release the button.

F to unlock the vehicle

and open the side door,
press and hold this
button until the door has
opened.

Using the remote control with
electric sliding side door(s)

Using the remote control

Access

Expert_en_Chap02_ouvertures_ed01-2016

Deadlocking

Deadlocking renders the exterior and
interior door controls inoperative.
It also deactivates the manual central
control button.
therefore, never leave anyone inside
the vehicle when it is deadlocked.

to deadlock the vehicle:
F turn the key to the rear of the vehicle.
F then

within five seconds, turn the key to

the rear again.

Depending on version, the door mirrors
fold at the same time.

Using the remote control

to lock the vehicle:

F Press this button.

F then

within five seconds after

locking, press this button again.

If your vehicle is not fitted with an alarm,
deadlocking is signalled by the fixed
illumination of the direction indicators
for about two seconds.

to deadlock the vehicle:

Using the key

If your vehicle is not fitted with an
alarm, locking is confirmed by the fixed
illumination of the direction indicators
for about two seconds.
According to version, the door mirrors
fold at the same time.

If one of the openings (doors or boot) is
still open, the central locking does not
take place.
When the vehicle is locked, if it is
unlocked inadvertently, it will lock itself
again automatically after about thirty
seconds unless a door is opened.
And if your vehicle has an alarm, this
will be reactivated (with volumetric
monitoring, even if this had been
deactivated).
the folding and unfolding of the door
mirrors by the remote control can be
deactivated by a PEugEot dealer or a
qualified workshop.

Access

Expert_en_Chap02_ouvertures_ed01-2016

Electronic engine immobiliser

the remote control contains an electronic chip
which has a special code. When the ignition is
switched on, this code must be recognised in
order for starting to be possible.
this electronic engine immobiliser locks the
engine management system a few moments
after the ignition is switched off and prevents
starting of the engine by anyone who does not
have the key.

F Press this button

Locating your vehicle

this function allows you to identify your vehicle
from a distance, particularly in poor light. Your
vehicle must have been locked for more than
five seconds.

this switches on the courtesy lamps and the
direction indicators flash for about ten seconds.

Remote operation of lighting

A short press on this button switches
on the lighting remotely (sidelamps,
dipped beam headlamps and number
plate lamps).

A second press on this button before
the end of the timed period cancels
the remote lighting.

Anti-theft protection

In the event of a fault, you are
informed by illumination of this
warning lamp, an audible signal and
a message in the screen.

Keep safely, away from your vehicle,
the label attached to the keys given to
you on acquisition of the vehicle.

In this case, your vehicle will not start; contact
a PEugEot dealer as soon as possible.

If fitted to your vehicle.

Ensure that no person or object could
prevent the correct closing of the
windows.
Be particularly aware of children when
operating the windows.

If fitted to your vehicle, pressing
and holding this button allows the
windows to be closed. the window
stops when you release the button.

Access

Expert_en_Chap02_ouvertures_ed01-2016

Back-up control(s)

Locking the driver's door

Locking the front passenger door

F open the door.

For mechanically locking and unlocking the doors in the event of a fault with the central locking
system or a battery failure.

If your vehicle has an alarm, it will not
be deactivated/activated on unlocking/
locking the vehicle.
opening a door will trigger the alarm,
which can be stopped by switching on
the ignition.

Locking the sliding side door

F If fitted to your vehicle, check that the

electric child lock is not on.

F open the door.

Unlocking

F Insert the key in the door lock and turn it to

the front.

Unlocking

use the interior door handle.

Unlocking

F use the interior door handle.

For more information on the Child lock,
refer to the corresponding section.

F Insert the key in the door lock and turn it to

the rear.

F Remove the cap on on the edge of the

door.

F Insert the key into the latch aperture

(without forcing) and turn the assembly.

F Remove the key and refit the cap.
F Close the door and check from the outside

that it has locked correctly.

F Remove the cap on the edge of the door.
F Insert the key into the latch aperture

(without forcing) and turn the assembly.

F Remove the key and refit the cap.
F Close the door and check from the outside

that it has locked correctly.

Access

Expert_en_Chap02_ouvertures_ed01-2016

Changing the battery

Do not throw the remote control
batteries away, they contain metals
which are harmful to the environment.
take them to an approved collection
point.

If the battery is flat, you are
informed by lighting of this warning

lamp in the instrument panel, an audible signal
and a message in the screen.

Reinitialisation

Locking the side-hinged doors

F If fitted to your vehicle, check that the

electric child lock is not on.

F open the left-hand door.

Battery ref.: CR1620 / 3 volts.

F Lock the driver's door using the

key.

F Press one of the remote control

buttons.

F turn the key to position 2 (Ignition on).
F Switch off the ignition and remove the key

from the ignition switch.

the remote control is fully operational again.

Unlocking

F use the interior door handle.

Remote control problem

Following disconnection of the vehicle battery,
replacement of the remote control battery or
in the event of a remote control malfunction,
you can no longer unlock, lock or locate your
vehicle.
F First of all, use the key in the lock to unlock

or lock your vehicle.

F then reinitialise the remote control.
If the problem persists, contact a PEugEot
dealer as soon as possible.

F unclip the cover using a screwdriver in the

cut-out.

F  Remove the cover.
F  Extract the flat battery from its location.
F  Place the new battery into its location

observing the original direction.

F Clip the cover in place.

F Insert the key into the latch aperture on the

edge of the door (without forcing) and slide
the assembly upward.

F Remove the key.
F Close the door and check from the outside

that it has locked correctly.

Access

Expert_en_Chap02_ouvertures_ed01-2016

"Keyless Entry and
Starting"

It allows the central locking or unlocking of the
vehicle from a distance.
It is also used to locate and start the vehicle, as
well as providing protection against theft.

Remote control

this separation of cab and loading
area locking provide security in use.
It allows you to prevent access to the
part of the vehicle where you are not
present.

What is the point
of total or selective
unlocking?

total unlocking allows all of the vehicle's doors
(front, side and rear) to be unlocked.

Selective unlocking allows either the cab
doors, or the loading area doors (side and
rear) to be unlocked.

F to activate this selectivity

between cab and loading
area, switch the ignition on and
press this button for more than
2 seconds.

Its indicator lamp comes on.

the modification is confirmed by an audible
signal and, depending on equipment, the
display of a message.

F to deactivate this selectivity and

return to total unlocking, switch
the ignition on and press this
button for more than 2 seconds.

Its indicator lamp goes off.

By default, selectivity between cab and
loading area is activated.

Programming

Access

Expert_en_Chap02_ouvertures_ed01-2016

With electric sliding side door(s)

F to

totally unlock the vehicle

without opening the side door,
press this button.

F to

totally unlock the

vehicle and open the
side door, press and
hold this button until the
door has opened.

unlocking is signalled by the rapid
flashing of the direction indicators for
about two seconds.
Depending on version, the door mirrors
unfold at the same time.

F Press one of these buttons

(depending on equipment) to
unlock the vehicle.

F to unlock only the cab doors,

make an initial press on this
button.

F to unlock the loading area

doors (side and rear), press on
this button again.

Total unlocking

Selective unlocking

Cab and loading area selectivity
deactivated.

Cab and loading area selectivity
activated.

If fitted to your vehicle, pressing
and holding this button allows the
windows to be opened. the window
stops when you release the button.

F Press on this button to unlock the

loading area only.

If fitted to your vehicle:

Access

Expert_en_Chap02_ouvertures_ed01-2016

Locking

Ensure that no person or object could
prevent the correct closing of the
windows.
Be particularly aware of children when
operating the windows.

If a door is not correctly shut (except
the right-hand door with side-hinged
rear doors):
-

vehicle stationary and the engine
running, this warning lamp
comes on, accompanied by an
alert message for a few seconds,

vehicle moving (speed above
6 mph (10 km/h)), this warning
lamp comes on, accompanied
by an audible signal and an alert
message for a few seconds.

F to

totally lock the vehicle, press

this button.

F to unlock the vehicle, press this

button.

With electric sliding side door(s)

With electric sliding door(s)

F to unlock the loading area only

without opening the side door,
press on this button.

F to unlock the loading

area only and open the
side door, press and
hold this button until the
door has opened.

F to unlock the vehicle

and open the side door,
press and hold this
button until the door has
opened

unlocking is signalled by the rapid
flashing of the direction indicators for
about two seconds.
Depending on version, the door mirrors
unfold at the same time.

Unlocking

If fitted to your vehicle, pressing
and holding this button allows the
windows to be closed. the window
stops when you release the button.

Access

Expert_en_Chap02_ouvertures_ed01-2016

Driving with the doors locked may make
access to the passenger compartment
by the emergency services more
difficult in the event of an emergency.
As a safety measure (children on
board), never leave the vehicle without
your remote control, even for a short
period.

If your vehicle is not fitted with an
alarm, locking is signalled by the fixed
illumination of the direction indicators
for about two seconds.
Depending on version, the door mirrors
fold at the same time.

If one of the doors remains open, the
central locking does not take place.
If the vehicle is inadvertently unlocked,
it will automatically lock itself again
after about thirty seconds, if no door is
opened.
And if fitted to your vehicle, the alarm is
reactivated (with volumetric monitoring,
even if you had deactivated it).

If fitted to your vehicle, pressing
and holding this button allows the
windows to be closed. the window
stops when you release the button.

Deadlocking

Deadlocking renders the exterior and
interior door controls inoperative.
It also deactivates the manual central
control button.
therefore, never leave anyone inside
the vehicle when it is deadlocked.

F Press this button.

F then

within five seconds after

locking, press this button again.

Ensure that no person or object could
prevent the correct closing of the
windows.
Be particularly aware of children when
operating the windows.

Depending on version, the door mirrors
fold at the same time.

the automatic folding and unfolding
of the electric door mirrors can be
deactivated by a PEugEot dealer or a
qualified workshop.

If your vehicle is not fitted with an alarm,
deadlocking is signalled by the fixed
illumination of the direction indicators
for about two seconds.

to lock the vehicle:

to deadlock the vehicle:

Access

Expert_en_Chap02_ouvertures_ed01-2016

the unlocking, locking or deadlocking
does not take place:
-

if the ignition is on,

if one of the doors or the boot is still
open,

if the key for the Keyless Entry and
Starting system has been left inside
the vehicle.

When the vehicle is locked (with the
remote control or Keyless Entry and
Starting), if it is unlocked inadvertently,
it will lock itself again automatically after
about thirty seconds unless a door has
been opened.
And if your vehicle has an alarm, this
will be reactivated (with volumetric
monitoring, even if this had been
deactivated).

"Keyless Entry and
Starting" on your person

this allows the unlocking, locking and starting
the vehicle while keeping the remote control on
your person.

As a safety measure (children on
board), never leave the vehicle without
taking your Keyless Entry and Starting
remote control, even for a short period.
guard against theft when the Keyless
Entry and Starting remote control is in
the recognition zone with the vehicle
unlocked.
In order to preserve the charge of the
cell battery in the remote control, the
"hands-free" functions go into extended
stand-by after 21 days of non-use.
to restore these functions, press one of
the remote control buttons or start the
engine with the remote control at the
reader.

the folding and unfolding of the door
mirrors by the remote control can be
deactivated by a PEugEot dealer or a
qualified workshop.

In the ignition on (accessories) position,
with the "StARt/StoP" button, the
hands-free function is deactivated.
For more information on "Keyless
Entry and Starting" and in particular
the "ignition on" position, refer to the
corresponding section.

Access

Expert_en_Chap02_ouvertures_ed01-2016

Cab and loading area selectivity
deactivated.

unlocking is signalled by the rapid
flashing of the direction indicators for
about two seconds.
Depending on version, the door mirrors
unfold and the alarm is deactivated.

Total unlocking

F to unlock the vehicle, remote control on

your person and in the recognition zone A,
pass your hand behind one of the door
handles (front doors, manual sliding side
doors or side-hinged doors).

F Pull the handle to open the corresponding

door.

With electric sliding slide door(s)

F to unlock the vehicle, remote control on

your person and in the recognition zone A,
pull and release the door handle. this
action also triggers the electrically powered
opening of the corresponding door.

With tailgate

F to unlock the vehicle, remote control on

your person and in the recognition zone A,
pull the tailgate handle.

F Raise the tailgate.

Access

Expert_en_Chap02_ouvertures_ed01-2016

Depending on version, the door mirrors
unfold only on unlocking the cab, the
alarm is deactivated

Cab and loading area selectivity
activated.

Selective unlocking

F to unlock the cab only, remote control on

your person in the recognition zone A or B,
pass your hand behind one of the front
door handles.

F Pull the handle to open the corresponding

door.

F to unlock the loading area only,

remote control on your person and in the
recognition zone A, B or C, pass your
hand behind the door handle on one of the
doors, left, right or rear.

F Pull on the handle to open the

corresponding door.

With electric sliding slide door(s)

F to unlock the loading area, remote control

on your person and in the recognition
zone A and B, pull and release the
door handle. this action also triggers
the electrically powered opening of the
corresponding door.

the state of the locks for the loading
area doors remains unchanged.

Access

Expert_en_Chap02_ouvertures_ed01-2016

With tailgate

F to unlock the loading area only,

remote control on your person and in the
recognition zone C, pull the tailgate handle.

F Raise the tailgate.

unlocking is signalled by the rapid
flashing of the direction indicators for
about two seconds.

Peugeot Expert VU (2016 year). Instruction - part 4
