Peugeot Expert Tepee (2014 year). Instruction - part 9

Checks

CHECKS

Battery

At the start of winter, have your battery

checked by a PEUGEOT dealer or a

qualified workshop.

Brake pads

Brake pad wear depends on the style of

driving, in particular for vehicles which are

used in town, over short distances. It may

be necessary to check the thickness of the

pads, even between services.
Unless there is a leak in the system, a drop

in the brake fluid level indicates that the

brake pads are worn.

Brake disc / drum wear

For any information on checking the brake

disc / drum wear, contact a PEUGEOT

dealer or a qualified workshop.

Parking brake

Where the parking brake travel is too great

or there is a reduction in the performance

of the system, the parking brake should be

adjusted, even between services.
Have the system checked by a PEUGEOT

dealer or a qualified workshop.

Oil filter

Change the filter regularly, in accordance

with the servicing schedule.

Carbon filter and passenger

compartment filter

The carbon ﬁ lter permits continuous and

effective ﬁ ltering of dust.
If the passenger compartment ﬁ lter becomes

clogged, this may reduce the performance

of the air conditioning system and generate

unpleasant odours.
We recommend the use of a combined

passenger compartment ﬁ lter. By means of

its second special active ﬁ lter, it contributes

to the puriﬁ cation of the air breathed by the

occupants and the cleanness of the passenger

compartment (reduction of allergic symptoms,

unpleasant odours and greasy deposits).
Refer to the servicing and warranty booklet

to ﬁ nd out the replacement interval for these

components.
Depending on the environment (dusty

atmosphere...) and the use of the vehicle

(urban driving...), change them twice as often

if necessary.

Particle emission filter (Diesel)

This filter actively contributes

to the preservation of air quality

by trapping unburnt polluting

particles. It is controlled

completely and automatically by the engine

management system.
This warning lamp comes on if there is a risk

of blockage of the filter.
This alert signals the start of saturation of

the particle emissions filter (exceptionally

prolonged driving in urban conditions:

reduced speed, traffic jams…).
If this alert persists, contact a PEUGEOT

dealer or a qualified workshop.
On acceleration after the vehicle has been

running for a prolonged period at very low

speed or at idle, you may, in exceptional

circumstances, notice the emission of water

vapour at the exhaust. This water vapour

does not have any adverse effect on vehicle

handling or the environment.
To regenerate the filter, it is recommended

that as soon as driving conditions permit,

you drive at a speed of at least 36 mph

(60 km/h) for at least 5 minutes (until the

warning lamp goes off and/or the message

disappears).

Refer to "Under the bonnet" in

section 6.

128

Checks

Manual gearbox

Have the level checked in accordance with

the manufacturer's servicing schedule.

Good practice

To check the main levels and certain

components, in accordance with the

manufacturer's servicing schedule, refer to

the pages of the warranty and maintenance

record which correspond to your vehicle's

engine.

Only use products recommended by

PEUGEOT or products of equivalent

quality and specification.
In order to optimise the operation of units as

important as the braking system, PEUGEOT

selects and offers specific products.
In order to avoid damaging the electrical

units, high pressure washing to clean the

engine compartment is strictly prohibited.
After washing the vehicle dampness, or in

winter, ice may form on the brake discs and

pads: braking efficiency may be reduced.

Make some light brake applications to dry

and de-ice the brakes.

1.6 litre HDi

2 litre HDi

Bleeding the water contained in the

Diesel filter

If this warning lamp comes on,

bleed the filter. Otherwise bleed

regularly each time the engine oil

is changed.

To evacuate the water, unscrew the bleed

screw located on the end of the transparent

pipe.
Operate until all of the water in the

transparent pipe has been drained out then

tighten the bleed screw.
HDi engines use advanced technology.
Contact a PEUGEOT or a qualified

workshop for all work on the system.

During this regeneration, you may notice

that the idling speed is higher than normal

and that the cooling fan is running. As

operation of the exhaust emissions controls

may cause the exhaust gas temperature to

reach very high levels, it is recommended

that you do not stop the vehicle over easily

inflammable surfaces (dry grass and leaves,

pine needles, edge of a meadow or forest).

129

Maintenance with TOTAL

CHECKS

RECOMMENDS

Innovation at the service of performance
The TOTAL Research and Development

teams develop lubricants for PEUGEOT which

satisfy the requirements of the latest technical

innovations incorporated in PEUGEOT vehicles.
This ensures that you obtain the best

performance and the maximum engine life.

Reduced exhaust emissions
TOTAL lubricants are formulated to optimise the

efficiency of engines and the protection of the

emissions post-treatment systems. It is crucial to

observe the servicing recommendations made by

PEUGEOT to ensure correct operation.

130

Fuel

FILLING WITH FUEL

Filling with fuel
The fuel tank must be filled

with the

engine off .

When this warning lamp ﬁ rst comes

on and when the needle is at the

start of the red zone, the minimum

fuel tank level has been reached.

At this moment, you have

approximately

8 litres of fuel remaining.
Fill up without delay to avoid running out of fuel.

When filling with fuel, do not open the

left-hand side door, if fitted on your

vehicle, as there is a risk of damage to the

fuel filler flap.

Never continue to drive until you run

out of fuel as this may damage the

emission control and injection systems.

Low fuel level

It is normal to hear the noise of an inrush

of air when the cap is opened as there is a

vacuum caused by the sealing of the fuel

system.
A label affixed to the inside of the flap

reminds you of the type of fuel to be used.
More than 8 litres of fuel must be added in

order to be registered by the fuel gauge.
When filling the fuel tank, do not continue

after the 3

cut-off of the nozzle. This could

cause malfunctions.

The capacity of the fuel tank is

approximately 80 litres.
- After filling the fuel tank, lock the cap

and close the flap.

You can lock this door using the

electric child lock. Refer to "Access"

in section of 2.

Open the fuel filler flap.

Insert the key, then turn it a quarter turn.

- Remove the cap and hook it onto the

clip located on the inside of the flap.

DIESEL

131

Fuel

CHECKS

FUEL CUT-OFF

In a serious collision, a mechanism

automatically prevents fuel from reaching

the engine.

DIESEL PRIMING PUMP

If you should run out of fuel, it is necessary

to prime the circuit:
- fill the fuel tank with at least five litres of

diesel,

- squeeze and release the manual priming

pump, under the bonnet under the

protective cover, until fuel appears in the

transparent pipe,

- operate the starter until the engine

starts.

The flashing of this warning lamp

is accompanied by a message in

the screen.

Check that there is no odour or leakage of

fuel outside the vehicle and re-establish the

fuel supply:
- switch off the ignition (STOP position),
-

remove the key,

- put the key back in the ignition,
- switch on the ignition and start.

Quality of the fuel used for Diesel

engines

Quality of the fuel used for petrol

engines

The Diesel engines are perfectly compatible

with biofuels which conform to current

and future European standards (Diesel

fuel which complies with standard EN 590

mixed with a biofuel which complies with

standard EN 14214) available at the pumps

(containing up to 7 % Fatty Acid Methyl

Ester).
The B30 biofuel can be used in certain

Diesel engines; however, this use is subject

to strict application of the special servicing

conditions. Contact a PEUGEOT dealer or a

qualified workshop.
The use of any other type of (bio)fuel

(vegetable or animal oils, pure or diluted,

domestic fuel...) is strictly prohibited (risk of

damage to the engine and fuel system).

The petrol engines are perfectly compatible

with E10 or E24 type petrol biofuels

(containing 10 % or 24 % ethanol),

conforming to European standards EN 228

and EN 15376.
E85 type fuels (containing up to 85 %

ethanol) are reserved exclusively for

vehicles marketed for the use of this type

of fuel (BioFlex vehicles). The quality of

the ethanol must comply with European

standard EN 15293.
For Brazil only, special vehicles are

marketed to run on fuels containing up to

100 % ethanol (E100 type).

132

Fuel

DIESEL PRIMING BUTTON

If you should run out of fuel, it is necessary

to prime the system using the priming

button:
- fill the fuel tank with at least five litres of

Diesel fuel,

open the bonnet,

- unclip the protective cover for access to

the priming push button,

- place the cover to the right of the engine,

- firmly squeeze and release the manual

priming pump until fuel stiffens the pipe,

- operate the starter until the engine starts,

- place the two slots in the lugs behind the

engine to allow the protective cover to

be refitted,

- clip the protective cover in place,
-

close the bonnet.

If the engine does not start first time,

do not keep trying.
Operate the priming push button again,

then start the engine.

133

Battery

QUICK HELP

BATTERY

This is housed in a compartment located

underneath the ﬂ oor, in front of the front right seat.

Before disconnecting the battery, you must

wait for 2 minutes after switching off the

ignition.
Never disconnect a terminal when the

engine is running.
Never charge a battery without first

disconnecting the terminals.
After every reconnection of the battery,

switch on the ignition and wait 1 minute

before starting to allow the electronic

systems to be initialised. If some problems

persist after this operation, please contact a

PEUGEOT dealer or a qualified workshop.

It is advisable to disconnect the battery

if the vehicle is not to be used for a

period of more than one month.

charger

Disconnect the battery,

- Follow the instructions for use given by

the battery charger manufacturer,

- Reconnect starting with the negative (-)

terminal,

- Check that the terminals and connectors

are clean. If they are covered with

sulphate (white or greenish deposit),

disconnect them and clean them.

To start the vehicle from another

battery

- Connect the red cable to the positive (+)

terminals of the two batteries,

- Connect one end of the green or black

cable to the negative (-) terminal of the

slave battery,

- Connect the other end of the green or

black cable to an earth point on the

broken down vehicle as far as possible

from the battery,

- Operate the starter, let the engine run,
- Wait for the engine to return to idle, then

disconnect the cables.

The presence of this label indicates

the use of a 12 V lead-acid battery

with special technology and specification,

for which the involvement of a PEUGEOT

dealer or qualified workshop is required

when replacing or disconnecting the battery.
Failure to observe this recommendation may

cause premature ageing of the battery.

134

Battery

ECONOMY MODE

After the engine has stopped, with the key

in the ignition position, certain functions

(windscreen wiper, electric windows, courtesy

lamps, audio equipment, etc.) can only

be used for a cumulative duration of thirty

minutes, to prevent discharging of the battery.

Once the thirty minutes are over, the active

functions are put on standby and the battery

warning lamp flashes accompanied by a

message in the screen.
To resume the use of these functions

immediately, start the engine and let it run

for a few minutes.

The time available will then be double the

time for which the engine was left running.

However, this time will always be between

five and thirty minutes.

A flat battery will prevent the engine from

starting.

135

Repairing a wheel

QUICK HELP

PUNCTURE REPAIR KIT

The kit is located at the left hand rear of the

vehicle.

The temporary puncture repair kit consists

of a compressor and a cartridge (containing

a sealant).

Using the kit

switch off the ignition,

- affix the speed limitation sticker to the

vehicle's steering wheel to remind you

that a wheel is in temporary use,

- check that the switch

A is at position " 0 ",

- connect the pipe of the bottle

1 to the

valve of the tyre to be repaired,

- connect the compressor's electrical plug

to the vehicle's 12V socket,

- start the vehicle and let the engine run,
- switch on the compressor by pressing

the switch

A to position " 1 " until the tyre

pressure reaches 2.0 bars,

- remove the compressor, unclip and

store the bottle in a sealed bag to avoid

staining your vehicle with traces of fluid,

drive immediately, for approximately

two miles (three kilometres), at reduced

speed (between 12 and 37 mph (20 and

60 km/h)), to seal the puncture,

- stop to check the repair and the

pressure,

Vehicles supplied with a temporary

puncture repair kit do not have a spare

wheel or tooling (jack, wheelbrace, ...).

If, after approximately five to

ten minutes, you are not able to obtain

this pressure, the tyre cannot be repaired;

contact a PEUGEOT dealer or a qualified

workshop for roadside assistance.

136

Repairing a wheel

Warning, the sealant cartridge contains

ethylene-glycol, this product is harmful

if swallowed and causes irritation to

the eyes. Keep this product out of reach of

children.
The expiry date of the sealant is indicated

under the cartridge.
The cartridge is intended for a single use;

once opened, it must be replaced.
After use, do not discard the cartridge into

the environment, take it to a PEUGEOT

dealer or to a specialised waste

disposal site.
Do not forget to obtain a new sealant

cartridge, available from a PEUGEOT dealer

or a qualified workshop.

- adjust the pressure using the

compressor (to inflate: switch

A in

position "

1 "; to deflate: switch A in

position "

0 " and press button B ), in

accordance with the vehicle's tyre

pressure label (located on the door

aperture, on the driver's side), then

remember to check that the leak has

been sealed correctly (no further

loss of pressure after several miles

(kilometres)),

- remove the compressor, then stow the

complete kit,

- drive at reduced speed (50 mph (80 km/h)

max) limiting the distance travelled to

approximately 125 miles (200 km),

- visit a PEUGEOT dealer or a qualified

workshop as soon as possible to have

the tyre repaired or replaced by a

technician.

- connect the compressor pipe directly to

the valve of the repaired wheel.

- connect the compressor's electrical plug

to the vehicle's 12V socket again,

- start the vehicle again and let the

engine run,

137

Changing a wheel

QUICK HELP

CHANGING A WHEEL

If your vehicle is equipped with a spare

wheel located underneath the vehicle, follow

these instructions.

1. PARKING THE VEHICLE

- You must ensure that the occupants

get out of the vehicle and wait in a safe

location.

- If possible, park the vehicle on level,

stable and non-slippery ground.

- Apply the parking brake, switch off the

ignition and engage first or reverse gear.

- If available, place a chock under the

wheel diagonally opposite the one to be

changed.

On certain types of ground and/or if heavy

loads are being transported, the vehicle

must be raised in order to disengage

the spare wheel from the carrier. Call a

PEUGEOT dealer or a qualified workshop.

If your vehicle is fitted with suspension

with pneumatic height correction,

please deactivate the system. Refer to the

"Rear suspension" section of chapter 3.

- If fitted on your vehicle, open the

plastic flap located at the rear left of the

vehicle.

- Unscrew the nut then take out the jack

and the wheelbrace.

1. Wheelbrace.

2. Jack.

3. Towing eye.

The jack and the tool kit are specific to

your vehicle. Do not use them for other

purposes.

138

Changing a wheel

- Open the cover, located on the sill, to

access the carrier bolt.

- Unscrew the bolt using the wheelbrace

until the carrier is lowered fully.

- Detach the carrier from the hook and

place the spare wheel near the wheel to

be changed.

3. SPARE WHEEL

- Gain access to the spare wheel from the

rear.

Open the rear doors.

You can switch on the courtesy lamp to

improve visibility.

139

Changing a wheel

QUICK HELP

4. OPERATING PROCEDURE

- Place the jack in contact with the

locating point provided, the one which is

closest to the wheel to be changed.

Ensure that the jack is straight and that

the base of the jack is fully in contact

with the ground.

- Extend the jack to lift the wheel clear of

the ground.

- Resume and complete the unscrewing of

the wheel bolts.

- Remove the bolts and remove the wheel.

- Remove the trim pulling it using the

towing eye.

- Loosen the wheel bolts and start

unscrewing them.

Do not extend the jack until you have

started unscrewing the bolts on the

wheel to be changed and have placed

the chock under the wheel diagonally

opposite.

140

Changing a wheel

- Lower the vehicle completely by folding

the jack, then remove the jack.

- Tighten the bolts again using the

wheelbrace, tighten them fully without

forcing them.

- Place the wheel to be repaired in the

carrier.

- Secure the carrier on the hook then

raise the carrier using the bolt and the

wheel brace. Check that the wheel and

the carrier are flush against the floor of

the vehicle.

- Remember to close the flap, located on

the sill.

- Store the trim in the vehicle.

Never go underneath the vehicle when

it is supported only by the jack.
Never use a screwdriver in place of the

wheelbrace.

WHEEL

- Position the wheel on the hub and start

tightening the wheel bolts by hand.

- Carry out an initial tightening of the bolts

using the wheelbrace.

141

Snow screen

QUICK HELP

REMOVABLE SNOW SCREEN

According to country, the removable snow

screen is installed on the lower part of the

front bumper to prevent the accumulation of

snow at the radiator cooling fan.

FITTING

- Offer up the snow screen facing its

centring pin

A on the front bumper.

- Put it in place by pressing at each clip

located in the four corners.

Do not forget to remove the snow screen

when the exterior temperature is higher than

10°C (no risk of snowfall) and when towing.

REMOVAL

- Pass a screwdriver into the hole located

near each of the clips.

- Use the screwdriver as a lever to unclip

the four clips

B in turn.

6. REFITTING THE REPAIRED

WHEEL

The wheel is refitted as described in step 5,

not forgetting to refit the wheel trim.

Refer to the "Identification markings"

section of chapter 8 to locate the tyre

label.

The spare wheel is not designed to

be used over long distances. Have

the tightening of the bolts and the tyre

pressure checked by a PEUGEOT dealer or

a qualified workshop as soon as possible.

Also, have the original wheel repaired and

refitted by a PEUGEOT dealer or a qualified

workshop as soon as possible.

142

Snow chains

SNOW CHAINS

In wintry conditions, snow chains improve

traction as well as the behaviour of the

vehicle when braking.

The snow chains must be fitted only to

the driving wheels. They must never be

fitted to "space-saver" type spare wheels.

Take account of the legislation in force

in your country on the use of snow

chains and the maximum running speed

authorised.

Advice on installation
 If you have to fit the chains during

a journey, stop the vehicle on a flat

surface on the side of the road.

 Apply the parking brake and position any

wheel chocks to prevent movement of

your vehicle.

 Fit the chains following the instructions

provided by the manufacturer.

 Move off gently and drive for a few

moments, without exceeding 30 mph

(50 km/h).

 Stop your vehicle and check that the

snow chains are correctly tightened.

Avoid driving on roads that have been

cleared of snow, to avoid damaging

your vehicle's tyres and the road surface. It

is recommended that before you leave, you

practise fitting the snow chains on a level

and dry surface. If your vehicle is fitted with

alloy wheels, check that no part of the chain

or its fixings is in contact with the wheel rim.

Use only the chains designed to be fitted to

the type of wheel fitted to your vehicle:

For more information on snow chains,

contact a PEUGEOT dealer or a qualified

workshop.

Original tyre size

Maximum link

size.

215/65 R15

12 mm

215/60 R16

MICHELIN

215/60 R16

BRIDGESTONE

Content .. 7 8 9 10 ..
