Peugeot 5008 (2017 year). Instruction

Access

Triggering of the alarm

This is indicated by sounding of the siren
and flashing of the direction indicators for
30 seconds.
The monitoring functions remain active until
the alarm has been triggered eleven times in
succession.
When the vehicle is unlocked using the remote
control or the " Keyless Entry and Starting"
system, rapid flashing of the indicator lamp
in the button informs you that the alarm was
triggered during your absence. When the
ignition is switched on, this flashing stops
immediately.

Failure of the remote
control

To deactivate the monitoring functions:
F unlock the vehicle using the key (integral to

the remote control) in the driver's door lock,

F open the door; the alarm is triggered,
F switch on the ignition; the alarm stops; the

indicator lamp in the button goes off.

Locking the vehicle without
activating the alarm

F Lock or deadlock the vehicle using the key

(integral to the remote control) in the driver's
door lock.

Operating fault

When the ignition is switched on, fixed
illumination of the indicator lamp in the button
indicates a fault with the system.
Have it checked by a PEUGEOT dealer or a
qualified workshop.

Doors

Opening

From outside

F After unlocking the vehicle or holding the

electronic key of the Keyless Entry and
Starting system in the recognition zone, pull
the door handle.

When the selective unlocking is activated,
the first press of the remote control
unlocking button permits unlocking of the
driver's door only.

Access

Closing

When a door is not closed correctly:

with the engine running or the
vehicle moving (speed below
6 mph (10 km/h)), this warning
lamp comes on, accompanied by
an alert message displayed for a
few seconds.

with the vehicle moving (speed
above 6 mph (10 km/h)), in
addition to the warning lamp and
alert message, an audible signal
sounds for a few seconds.

Boot

Opening the tailgate

With the exterior tailgate control

F With the vehicle unlocked or with the

electronic key of the Keyless Entry and
Starting system in the recognition zone,
press the central tailgate control.

F Raise the tailgate.

When selective unlocking is activated, the
electronic key must be close to the rear of
the vehicle.

The tailgate is not designed to take a
bicycle carrier.

From inside

F Pull a door opening lever on the inside; this

unlocks the whole vehicle.

With the selective unlocking activated:
- opening the driver's door unlocks the

driver's door only (if the vehicle has not
already been completely unlocked),

- opening one of the passenger doors

unlocks the rest of the vehicle.

Access

Closing the tailgate

F Lower the tailgate using the interior grips.
F Release the grips and press down on the

outside of the tailgate to close it.

If the tailgate is not properly closed:

engine running, this warning
lamp and a message appear in
the instrument panel for a few
seconds,

vehicle moving (speed above
6 mph (10 km/h)), this warning
lamp and a message appear in
the instrument panel for a few
seconds, accompanied by an
audible signal.

Hands-free tailgate

General points

The motorised operation of the tailgate can be
activated or deactivated in the vehicle settings
menu.
The motorised tailgate must only be operated
with the vehicle stationary.

Safety anti-pinch

The motorised tailgate has an obstacle
detection system that automatically interrupts
and reverses its movement by a few degrees to
allow the obstacle to be cleared.
Please note that this anti-pinch system is not
active at the end of the closing travel (around
1 cm from completely closed).

Check that there is enough space to
allow for the movement of the motorised
tailgate.

Never introduce a finger in the locking
system of the motorised tailgate – Risk of
a serious injury!

Access

There are several ways of operating the
tailgate:

using the electronic key of the Keyless
Entry and Starting system,

using the exterior tailgate control,

using the interior tailgate control,

using the control on the dashboard,

using the "hands-free access" procedure
below the rear bumper.

Opening / Closing

Bicycle carrier / Towbar

The motorised tailgate is not designed to
support a bicycle carrier.
When installing a bicycle carrier on a towbar
with connection of a cable to the towbar socket,
the motorised operation of the tailgate will be
automatically deactivated.
If using a towbar or bicycle carrier not
recommended by PEUGEOT, it is essential
to deactivate the motorised operation of the
tailgate.

Motorised operation

Activation / deactivation of the
motorised operation of the tailgate is
done in the Vehicle / Driving menu
of the touch screen.

This function is deactivated by default.

To avoid the risk of injury through pinching
or trapping, before and during operation of
the motorised tailgate:
- ensure that there is no person close to

the rear of the vehicle,

- watch the activity of your passengers,

particularly any children.

F Press and hold the central button A of the

electronic key.

or
F Press the exterior control B on the tailgate

with the electronic key on your person.

or
F Press the interior tailgate control C (closing

only).

or
F Press twice in succession on the dashboard

control D.

or
F With the electronic key on you, use the

"hands-free" access E by performing a
"kicking" movement below the rear bumper.

The command is confirmed by an audible
signal.

The tailgate opens, either completely
by default, or to the position memorised
beforehand.
If motorised operation is not activated,
these actions release the tailgate.
The request to open the tailgate with one
of the controls A, B or E enables you to
unlock the vehicle or the tailgate alone
beforehand, if selective unlocking of the
boot is activated.
Closing the tailgate with the "hands-free"
access function enables you to lock the
vehicle.

Access

Hands-Free Tailgate Access

Activation and deactivation of the
"Hands-Free Tailgate Access"
function is done in the Vehicle /
Driving menu of the touch screen.

This function is deactivated by default.

Ensure that you are steady on your
feet before performing the quick foot
movement.
Take care not to touch the exhaust system
which may be hot – Risk of burns!

At any point, It is possible to interrupt the
operation of the tailgate.
Pressing one of these controls again
interrupts the movement that is underway.
Following the interruption of a movement,
pressing one of these controls again
reverses the movement.

Automatic locking using the
"Hands-Free Tailgate Access" function

To activate automatic locking of the vehicle
when closing the tailgate using the Hands-Free
Tailgate Access function:

F Press this button; its indicator

lamp comes on.

Pressing this button again
deactivates the function; its indicator
lamp goes off.

Memorising an opening
position

To limit the motorised tailgate opening angle:
F open the tailgate to the desired position,
F press button C or the exterior control B for

more than 3 seconds.

Memorisation of the maximum opening position
of the tailgate is confirmed by an audible signal.

To cancel the memorised position:
F stop the tailgate in an intermediate position,
F press button C or the exterior control B for

more than 3 seconds.

Cancellation of the memorised position is
confirmed by an audible signal.

Manual operation

The tailgate can be manoeuvred by hand, even
with motorised operation activated.
The tailgate must be immobile.
When opening and closing a motorised tailgate
manually, there is no assistance from gas
struts. Resistance to opening and closing is
therefore entirely normal.

Access

Precautions in use

Recommendations related
to the "Hands-Free Tailgate
Access" function

If several kicking movements to operate the
tailgate have no effect, wait a few seconds
before trying again.

The function automatically deactivates in heavy
rain or following a build-up of snow.

If it does not work, check that the electronic key
is not exposed to a source of electromagnetic
pollution (smartphone etc.).

The function may not work correctly with a
prosthetic leg.

The function may not work correctly if your
vehicle is fitted with a towbar.

In some circumstances, the tailgate may open
or close by itself, particularly if:
-  you hitch or unhitch a trailer,
-  you fit or remove a bicycle carrier,
-  you load or unload bicycles from a bicycle

carrier,

- you place or lift something behind the

vehicle,

-  an animal approaches the rear bumper,
-  you are washing your vehicle,
-  your vehicle is being serviced,
-  you are accessing the spare wheel

(depending on version).

To avoid such operating problems, keep the
electronic key away from the sensor zone or
deactivate the "Hands-Free Tailgate Access"
function.

In wintry conditions
In the event of an accumulation of snow
on the tailgate, clear the snow before
commanding a motorised opening of the
tailgate.
The formation of ice can block the tailgate
and prevent its opening: wait until the ice
melts with the heating of the passenger
compartment.

When washing
When washing the vehicle in an automatic
car wash, do not forget to lock your vehicle
to avoid the risk of unexpected opening.

Reinitialising the motorised
tailgate

This operation is necessary where there is no
movement – after detection of an obstacle,
connecting or recharging the battery, etc.
F Open the tailgate manually, if necessary.
F Fully close the tailgate manually.
If the problem persists, contact a PEUGEOT
dealer or a qualified workshop.

Repeatedly opening and closing of the
motorised tailgate can cause overheating
of its electric motor, after which opening
and closing will not be possible.
Allow at least 10 minutes for the electric
motor to cool down before operating the
tailgate again.
If you are unable to wait, operate it
manually.

Access

Electric windows

Left-hand front.

Right-hand front.

Right-hand rear.

Left-hand rear.

Deactivate the electric window switches
located at the rear seats.

Manual operation

To open or close the window, press or pull the
switch gently, without exceeding the resistance
point. The window stops as soon as the switch
is released.

Automatic operation

Safety anti-pinch

When the window rises and meets an obstacle,
it stops and immediately partially lowers again.
In the event of unwanted opening of the
window on closing, press the switch until the
window opens completely, then pull the switch
immediately until the window closes. Continue
to hold the switch for approximately one second
after the window has closed.
The safety anti-pinch function is not active
during this operation.

To open or close the window, press or pull the
switch fully, beyond the resistance point: the
window opens or closes completely when the
switch is released. Pressing the switch again
stops the movement of the window.

The electric window switches remain
operational for approximately 45 seconds
after switching off the ignition.
Once this time has elapsed, the electric
windows will not operate. To reactivate
them, switch the ignition on again.

Deactivating the rear
controls for the rear
windows

For the safety of your children, press switch
5 to prevent operation of the rear windows
irrespective of their positions.

The indicator lamp in the button comes on,
accompanied by a message confirming
activation. It remains on until cancelled.

Use of the rear electric windows from the
driver's controls remains possible.

Access

Reinitialising the electric
windows

Following reconnection of the battery, the
safety anti-pinch function must be reinitialised.
The safety anti-pinch function is not active
during these operations.
For each window:
- bring the window down completely,

then bring it back up. It will go up by a
few centimetres each time. Perform the
operation again until the window is fully
closed,

- continue to pull the switch for at least one

second after reaching this position, window
closed.

In the event of contact during operation
of the windows, you must reverse the
movement of the window. To do this, press
the switch concerned.
When operating the passenger electric
window switches, the driver must ensure
that nothing is preventing correct closing
of the windows.
The driver must ensure that the
passengers use the electric windows
correctly.
Be particularly aware of children when
operating the windows.
Be aware of passengers or other persons
present when closing the windows using
the electronic key or the " Keyless Entry
and Starting" system.

Panoramic opening sunroof

The panoramic sunroof and its blind are
opened and closed using the buttons in the roof
console.

Blind control button.

Sunroof control button.

Ensure that any luggage or accessories
carried on the roof bars do not interfere
with the movement of the sunroof.
Do not place heavy loads on the fixed or
mobile glass of the sunroof.

Access

Principles

Complete opening of the sunroof involves partly
raising the mobile glass, then sliding it over the
fixed glass.
Any intermediate position is possible.
Opening the roof involves opening the blind. By
contrast, the blind can remain open when the
roof is closed.

The control buttons for the sunroof and blind
can be used:
- with the ignition on, if the state of charge of

the battery is adequate,

-  with the engine running,
-  in STOP mode with Stop & Start,
-  during the 45 seconds after switching off

the ignition,

- during the 45 seconds after locking the

vehicle.

Before operating the sunroof or blind
control buttons, ensure that no object or
person might prevent the movement.

Operating the sunroof

Opening

With the sunroof fully closed or partly
raised:
F press and release the rear of

button B without going beyond
the point of resistance to fully
raise the sunroof.

With the sunroof opened beyond the raised
position:
F press and release the rear of button B

without going beyond the point of resistance
to open the sunroof.

With the sunroof partly or fully closed:
F press and release the rear of button B going

beyond the point of resistance to fully open
the sunroof.

Any new action on this button interrupts the
movement.

F Press and hold the rear of button B without

going beyond the point of resistance; the
sunroof opens and stops when you release
the button.

If the sunroof is wet, following a shower
or washing the vehicle, wait until it is
completely dry before opening.
Do not operate the sunroof if it is covered
by snow or ice – Risk of damage!
Use only plastic scrapers to remove snow
or ice from the sunroof.

Do not put your head or arms through
the open sunroof when driving – Risk of
serious injury!

Closing

With the sunroof partially or fully
open:
F press and release the front of

button B going beyond the point
of resistance to fully close the
sunroof.

Any new action on this button
interrupts the movement.

With the sunroof partially or fully open:
F press and release the front of button B

without going beyond the point of resistance
to close the sunroof to its raised position.

Access

F press and release the front of button B

again to fully close the sunroof.

With the sunroof fully or partly raised:
F press and release the front of button B

without going beyond the point of resistance
to fully close the sunroof.

F press and hold the front of button B without

going beyond the point of resistance; the
sunroof closes and stops when you release
the button.

Never leave the vehicle with the sunroof
open.

Anti-pinch system

If the sunroof encounters an obstacle when
closing, the movement is automatically
reversed.
The anti-pinch system is designed to be
effective at speeds of up to 75 mph (120 km/h).

Reinitialisation

Following reconnection of the battery or in
the event of a fault or jerky movement of
the sunroof, the opening sunroof must be
reinitialised:
F press the rear of button B until the sunroof

is fully open,

F press and hold the rear of button B again for

at least 3 seconds.

Check the condition of the sunroof seals
regularly (presence of dust or deposits,
dead leaves, etc.).
If using a car wash, check that the roof
is correctly closed in advance and keep
the tip of the high-pressure lance at least
30 centimetres from the seals.

Operating the sunroof blind

The closing movement of the blind is limited by
the position of the opening sunroof: the blind
cannot be further forward than the front of the
mobile glass.

Opening

F Press the rear of button A going

beyond the point of resistance to
fully open the blind.

Any new action on this button
interrupts the movement.

F Press and hold the rear of button A, without

going beyond the point of resistance; the
blind opens and stops when you release the
button.

Closing

F Press the front of button A, going

beyond the point of resistance to
fully close the blind.

Any new action on this button
interrupts the movement.

F Press and hold the front of button A, without

going beyond the point of resistance; the
blind closes and stops when you release the
button.

Access

Anti-pinch system

If the blind encounters an obstacle when
closing, the movement is automatically
reversed.

Reinitialisation

Following reconnection of the battery or in the
event of a fault or jerky movement of the blind,
the blind must be reinitialised:
F press the rear of button A until the blind is

fully open,

F press and hold the rear of button A again for

at least 3 seconds.

During simultaneous closing of the sunroof
and the blind, if the blind catches up with
the sunroof, the blind then suspends its
movement and automatically resumes
when the sunroof stops.

When locking the vehicle, pressing and
holding the locking button simultaneously
closes the windows and the sunroof
and then the blind. The movements are
interrupted when you release the locking
button.

Never leave the electronic key inside the
vehicle if you get out of the vehicle, even
for a short time.
If something is trapped when closing the
sunroof or blind, you should reverse the
movement of the sunroof or blind. To do
this, press the control button in question.
The driver must ensure that passengers
use the sunroof and blind correctly.
Be particularly aware of children when
operating the sunroof or blind.

Ease of use and comfort

Driving position

Adopting a good driving position helps improve
your comfort and protection.
It also optimises interior and exterior visibility
as well as access to controls.

Sitting comfortably

Whether or not your vehicle has certain seat
adjustments described in this section depends
on the trim level and country of sale.

Driver’s side

As a safety precaution, adjust the seats
only when the vehicle is stationary.

If your vehicle has electric seats, the
ignition must be on to adjust them.

Passenger’s side

Sit fully back in the seat with your pelvis, back
and shoulders in contact with the seat backrest.
The cushion height should be set so your eyes
are looking at the centre of the windscreen.
The head room should be at least 4 in (10 cm).
Adjust the longitudinal position of the seat so
you can fully press the pedals with legs slightly
flexed.
The knee room should be at least 4 in
(10 cm) from the dashboard for access to the
dashboard controls.
Adjust the backrest angle to as vertical a
position as possible; never tilt it more than 25°.
Adjust the head restraint so that its upper edge
is level with the top of your head.
Adjust the length of the seat cushion to support
your thighs.
Adjust the lumbar support so that it conforms to
the shape of your spine.
Adjust the steering wheel so that it is at least
10 in (25 cm) from your sternum and your arms
are slightly bent.
The steering wheel should not hide the
instrument panel.

Sit fully back in the seat with your pelvis, back
and shoulders in contact with the seat backrest.
Adjust the longitudinal position of the seat
so that you are at a distance of at least 10 in
(25 cm) from the dashboard.
Adjust the head restraint so that its upper edge
is level with the top of your head.

Ease of use and comfort

Before moving off

If your vehicle has electric door mirrors,
the ignition must be on to adjust them.

When driving

Never adjust the seats or steering wheel
when driving.
Always keep your feet on the floor.

Adjust the interior and exterior door mirrors to
reduce blind spots.

Fasten your seat belt: place the diagonal belt in
the middle of your shoulder and adjust the lap
belt so that it is tightened across your pelvis.
Ensure that all passengers have fastened their
seat belts correctly.

Maintain a good driving position and hold the
steering wheel with both hands at the quarter
to three position, so that you can easily and
quickly reach the controls behind and near the
steering wheel.

Ease of use and comfort

Front seats

Manual seats

1. Adjusting the seat forwards and backwards
F Raise the control bar and slide the seat

forwards or backwards.

F Release the bar to lock the seat in position

in the runners.

2. Adjusting the seat height
F Raise or lower the control as many times as

needed to obtain the desired seat height.

3. Adjusting the seat backrest angle
F Turn the knob forwards or backwards to

recline the backrest to the desired angle.

or
F For a passenger seat that can be placed in

the table position, pull the handle and guide
the backrest forwards or backwards.

4. Adjusting the height of the head restraint
Refer to the corresponding section.

5. Adjusting the lumbar support
(only on the driver's seat)
F Turn the knob forwards or backwards to

increase or decrease the level of lumbar
support.

Before moving the seat backwards, ensure that there is nothing that might prevent the full
travel of the seat.
There is a risk of trapping or pinching passengers if present in the rear seats or jamming the
seat if large objects are placed on the floor behind the seat.

Ease of use and comfort

"AGR" certified seats

Additional adjustments

1. Adjusting the length of the seat cushion
F Pull the handle forwards to release the

cushion, then move the front part of the seat
cushion forwards or backwards.

2. Adjusting the seat cushion angle electrically
F Press and hold the front or rear of the

control to raise or lower the front of the seat
cushion.

3. Adjusting the lumbar support electrically
The control allows independent adjustment of
the depth and vertical position of the lumbar
support.
F Press and hold the front or rear of the

control to increase or reduce the lumbar
support.

F Press and hold the top or bottom of the

control to raise or lower the lumbar support
area.

Ease of use and comfort

The backrest of the passenger seat can be fully
folded forward and secured in this position.
This function, when associated with folding
of the backrest of the rear seats, helps in
transporting long and voluminous objects.

First steps:
F  lower the head restraint,
F  straighten the "Aircraft" type table,
F  move the seat fully back to allow space for

the head restraint when folding,

F adjust the seat to the lowest position,
F check that there is nothing that might

interfere with folding of the backrest (seat
belt, child seat, items of clothing, bags, etc.).

Deactivation of the passenger front airbag
is recommended.

Folding the backrest

In this position, the backrest can support a
maximum load of 30 kg.
When sharp deceleration occurs, objects
placed on the folded backrest can turn into
projectiles.

Returning the backrest to the
normal position

F Pull the control fully up to release the

backrest.

F Raise the backrest and guide it back until it

latches into place.

F Check that the backrest has engaged

correctly.

Placing the passenger seat
in the table position

F Pull the control fully up to release the

backrest.

F Tip the backrest fully forward.

Peugeot 5008 (2017 year). Instruction - part 5
