Alphabetical index

351

3008-2_en_Chap11_index-alpha_ed01-2016

Under-inflation

(detection) ...................................................223

Unlocking ..................................................55, 58
Unlocking from the inside ...............................68
Unlocking the boot .................................... 57, 59
Unlocking the tailgate ............................... 57, 59

Ticket holder ................................................. 119
Time (setting) ..................................................45
Tool box .........................................................139
Tools ..............................................................309
Total distance recorder ................................... 41
Touch screen.......................42, 48, 50, 102 , 121
Towball, quickly

detachable ..................................................285

Towbar .......................................... 163, 196 , 284
Towbar with quickly

detachable towball ......................................285

Towed loads ..........................................339, 342
Towing another vehicle .................................336
Traction control (ASR) ........... 26, 160, 162, 164
Trailer ........................................... 163, 196 , 284
Trailer stability assist (TSA) ..................160, 163
Trajectory control systems ............................160
Triangle, warning...........................................307
Trip computer ............................................43, 44
Trip distance recorder ..................................... 41
Tyres ........................................................10, 345
Tyre under-inflation

detection .............................................223 , 316

Ventilation ............................... 10, 104-106 , 108
Visibility ......................................................... 116
Vision, 180° forward .....................................269
Vision, panoramic .........................................265
Visio Park ......................................265, 267, 269

Warning and indicator

lamps ................................................16, 21 , 22

Warning lamp, braking

system ...........................................................26

Warning lamp, Diesel

engine pre-heater .........................................18

Warning lamps ..............................19 , 22, 25, 40
Warning lamp, Service....................................23
Weights .................................................339, 342
Welcome lighting..................................... 57, 148
Wheel, spare ................................. 309, 317, 345
Window controls .............................................82
Windscreen, heated ...................................... 117
Wiper blades (changing) ...............................154
Wiper, rear.....................................................153
Wipers .............................................20, 152, 155
Wipers, automatic

rain sensitive .......................................152, 155

04-16

3008-2_en_Chap12_Couverture_ed01-2016 - Copie

Reproduction or translation of all or part of
this document is prohibited without written
authorisation from Automobiles PEUGEOT.

Automobiles PEUGEOT declares, by
application of the provisions of the European
legislation (Directive 2000/53) relating to End
of Life Vehicles, that it achieves the objectives
set by this legislation and that recycled
materials are used in the manufacture of the
products that it sells.

Printed in the EU

Anglais

www.peugeot.com

3008-2_en_Chap12_Couverture_ed01-2016 - Copie

Anglais

16P84.0040

*16P84.0040*

Audio and Telematics

Transversal-Peugeot_en_Chap01_NAC-2-2-0_ed01-2016

PEUGEOT Connect Nav

GPS satellite navigation - Applications - Multimedia audio - Bluetooth

GPS satellite navigation - Applications - Multimedia audio - Bluetooth telephone

Contents

First steps

Steering mounted controls

Menus 6
Voice commands

Navigation 14
Connected navigation

Applications 40
Radio Media

Telephone 68
Settings 80
Frequently asked questions

The system is protected in such a way
that it will only operate in your vehicle.
Displaying of the

Energy Economy

Mode message signals that a change

to standby is imminent.

The different functions and settings
described vary according to the version
and configuration of your vehicle.

The link below gives access to OSS
(Open Source Software) codes for the
system.
http://www.psa-peugeot-citroen.com/oss

As a safety measure and because it
requires sustained attention by the
driver, the pairing of a Bluetooth mobile
telephone with the Bluetooth hands-
free system of your audio system must
be done with the

vehicle stationary

and the ignition on.

FM/87.5 MHz

87.5MHz

12:13

18,5

21,5

23 °C

Audio and Telematics

Transversal-Peugeot_en_Chap01_NAC-2-2-0_ed01-2016

First steps

With the engine running, a press
mutes the sound.
With the ignition off, a press turns the
system on.

Volume.

Use the buttons either side of or below the
touch screen for access to the menus, then
press the virtual buttons in the touch screen.
All of the touch areas of the screen are white.
Press the cross to go back a level.
Press "OK" to confirm.

The touch screen is of the "capacitive"
type.
To clean the screen, use a soft, non-
abrasive cloth (spectacles cloth) with
no additional product.
Do not use sharp objects on the
screen.
Do not touch the screen with wet
hands.

12:13

18,5

21,5

23 °C

Audio and Telematics

Transversal-Peugeot_en_Chap01_NAC-2-2-0_ed01-2016

Select the audio source (depending on
version):
-

FM / DAB * / AM * radio stations.

USB memory stick.

CD player.

- Media player connected via the auxiliary

socket (Jack, cable not supplied).

Telephone connected by Bluetooth * using
Bluetooth * audio streaming.

* Depending on equipment.

Certain information is displayed permanently in
the upper band of the touch screen:
-

Reminder of the air conditioning
information and direct access to the
corresponding menu.

- Go directly to the selection of the audio

source, to the list of radio stations (or list of
titles depending on the source).

- Go to the message notifications, emails,

map updates and, depending on the
services, the navigation notifications.

- Go to the settings for the touch screen and

the digital instrument panel.

In very hot conditions, the volume may
be limited to protect the system. It may
go into standby (screen and sound off)
for at least 5 minutes.
The return to normal takes place when
the temperature in the passenger
compartment has dropped.

In the "Settings" menu you can create
a profile for just one person or a group
of people with common points, with
the possibility of entering a multitude
of settings (radio presets, audio
settings, navigation history, contact
favourites, ...); these settings are taken
into account automatically.

Audio and Telematics

Transversal-Peugeot_en_Chap01_NAC-2-2-0_ed01-2016

Steering mounted controls

Media (short press): change the

multimedia source.

Telephone (short press): call.

Call in progress (short press):

access to telephone menu.

Telephone (long press): reject an

incoming call, end call, access to
telephone menu.

Decrease volume.

Voice commands :

Short press, system voice
commands.
Long press, smartphone voice
commands via the system.

Mute / Restore the sound.
Or
Mute by pressing the volume
increase and decrease buttons
simultaneously.
Restore the sound by pressing one of
the two volume buttons.

Radio (rotate): automatic search for

the previous / next station.

Media (rotate): previous / next track,

move in a list.

Short press : confirm a selection;

other than selection, access to
presets.

Radio : display the list of stations.

Media : display the list of tracks.

Radio (press and hold): update the

list of stations received.

Increase volume.

12:13

18,5

21,5

23 °C

21,5

18,5

12:13

23 °C

12:13

18,5

21,5

23 °C

12:13

18,5

21,5

23 °C

Audio and Telematics

Transversal-Peugeot_en_Chap01_NAC-2-2-0_ed01-2016

Connected navigation

Driving

Applications

Enter navigation settings and choose a
destination.
Use services available in real time, depending
on equipment.

Activate, deactivate and configure certain
vehicle functions.

Operate certain applications on a smartphone
connected via CarPlay

or MirrorLink

Check the state of the Bluetooth

and Wi-Fi

connections.

Menus

Air conditioning

Manage the various temperature and air flow
settings.

According to version

FM/87.5 MHz

87.5MHz

12:13

18,5

21,5

23 °C

12:13

18,5

21,5

23 °C

12:13

18,5

21,5

23 °C

Audio and Telematics

Transversal-Peugeot_en_Chap01_NAC-2-2-0_ed01-2016

Settings

Radio Media

Telephone

Configure a personal profile and/or configure
the sound (balance, ambience, ...) and the
display (language, units, date, time, ...).

Select an audio source, a radio station, display
photographs.

Connect a telephone by Bluetooth

, read

messages and emails and send quick
messages.

Audio and Telematics

Transversal-Peugeot_en_Chap01_NAC-2-2-0_ed01-2016

Voice commands

First steps

Steering mounted controls

Information - Using the system

Press the Push To Talk
button and tell me what you'd
like after the tone. Remember
you can interrupt me at any

time by pressing this button. If you
press it again while I'm waiting for you
to speak, it'll end the conversation. If
you need to start over, say "cancel".
If you want to undo something, say
"undo". And to get information and tips
at any time, just say "help". If you ask
to me do something and there's some
information missing that I need, I'll
give you some examples or take you
through it step by step. There's more
information available in "novice" mode.
You can set the dialogue mode to
"expert" when you feel comfortable.

To ensure that voice commands are
always recognised by the system,
please observe the following
recommendations:
- speak in a normal tone without

breaking up words or raising your
voice.

- always wait for the "beep" (audible

signal) before speaking.

- for best operation, it is

recommended that the windows
and opening roof be closed to
avoid extraneous interference
(according to version).

- before making a voice command,

ask other passengers to not speak.

The voice commands, with a choice
of 12 languages (English, French,
Italian, Spanish, German, Dutch,
Portuguese, Polish, Turkish, Russian,
Arabic, Brazilian), are made using the
language previously chosen and set in
the system.

The voice commands in Arabic for:
"Navigate to address" and "Display POI
in the city", are not available.

Alternative synonyms can be used for
some voice commands.
E.g. Guide to / Navigate to / Go to / ...

Example of a "voice command" for
navigation:

"Navigate to address 11 Regent

Street, London" .
Example of a "voice command" for
the radio and media:

"Play artist Madonna" .
Example of a "voice command" for
the telephone:

"Call David Miller" .

Pressing this button activates the
voice commands function.

Content .. 21 22 23 24 ..
