Peugeot 306 Break (2002 year). Instruction - part 5
88
YO U R 306 IN D ETA IL
1
2
3
Never leave a child in a
vehicle which is exposed
to the sun and has the
windows closed.
To protect young children
from the sun, fit sunblinds to the
rear windows.
Never leave the keys in the reach
of children inside the car.
Strap children into their child seats
even on short journeys.
CHILD SEATS
This was one of PEUGEOT’s main criteria when designing your vehicle, however
the safety of your children also depends on you. For maximum peace of mind,
please follow these simple precautions:
All children under the age of 10 are required to travel in approved child safety seats*,
fitted with seat belts.
After carrying out numerous tests, PEUGEOT recommend the following systems :
Up to 9 months (up to 22 lbs. or 10 kg)
«Baby Safe», a seat secured with its back to the engine and secured with a
1
three-point seat belt, on either the front or rear seat.
From 9 months to 3 or 4 years (20 to 40 lbs. or 9 to 18 kg)
2
«Römer Peggy» is fitted to the rear seat with a two-point (lap-belt) or three-point
belt.
Over 3 or 4 years old (33 to 80 lbs or 15 to 36 kg)
“Klippan Optima” : is fitted in the rear with a three point belt (removable seatback).
3
from 33 to 55 lbs. [15 to 25 kg] : booster + seatback.
from 55 to 80 lbs. [25 to 36 kg] : use the booster on its own.
Observe the precautions concern-
For maximum safety, fasten the three-point seat belts or the child seat straps keeping
ing the passenger airbag.
the slack in relation to the child’s body to a minimum, even for short journeys.
To prevent the doors from opening accidentally: use the child-proof lock.
Also, do not open the rear windows more than a third.
*According to current legislation
89
YO U R 306 IN D ETA IL
Pre-tensioning and force-
To be effective, a seat belt
1
limiting front seat belts*
must be tensioned as
Safety in the event of a frontal impact
close to the body as pos-
has been improved by the introduc-
sible.
tion of pre-tensioning and force-limit-
ing front seat belts. Depending on the
seriousness of the impact, the pre-
Depending on the nature and seri-
tensioning system instantly tightens
ousness of the impact the pre-ten-
the seat belts firmly against the body
sioning system may be triggered
of the occupant.
before and independently of the
airbags.
The pre-tensioning seat belts are
armed when the ignition is on.
In all cases, the airbag warning
light comes on.
The force-limiting device reduces the
pressure of the seat belt against the
occupant’s body in the event of an
Following an impact, have the
accident.
system checked by a PEUGEOT
dealer.
Rear seat belts
4-door: the rear seats are fitted with
The system has been designed to
3 three-point inertia reel seat belts.
be fully operational for ten years.
3/5-door, estate: The rear seats are
SAFETY: SEAT BELTS
fitted with
2 three-point inertia reel
seat belts and one lap belt.
Have it replaced at the end of this
To adjust the height of the
period.
Use the buckle retaining hooks when
front seat belts
the rear seats are not occupied.
Pull the knob 1 and slide it.
To lock the seat belts
Pull the strap, then insert the end into
the buckle.
* According to specification.
78
YO U R 306 IN D ETA IL
CHANGING THE REMOTE
CONTROL BATTERIES
A
To gain access to the battery, unclip
the key casing with a coin where you
can see the ring
(CR1620/3 volt
battery).
If the remote control does not work
after the battery has been changed,
re-programme the remote control.
PROGRAMMING THE
REMOTE CONTROL
B
Manual synchronisation
- Switch off the ignition,
- Switch on the ignition,
KEYS
THE REMOTE CONTROL
- Immediately after switching on the
A single press on button A locks the
ignition press button A.
Without central locking
doors and boot or tailgate, this is dis-
The remote control is now working
The key individually Iocks and unlocks
played by the direction indicators
again.
the doors and boot or tailgate.
staying on for about 2 seconds.
Automatic synchronisation
A single press on button B unlocks
the vehicle, this is displayed by the
- Switch on the ignition (position M),
With central locking
direction indicators flashing rapidly.
- Switch off the ignition and, during
Turning the key in the driver’s door
the next four minutes, lock the
lock will lock or unlock the doors and
vehicle using the remote control
boot or tailgate. If either of the front
(button A).
doors is not closed, the central locking
The remote control is now working
will not work.
again.
Note: do not repeatedly press the
button of your remote control out of
range of your vehicle. You risk
causing it not to work and the remote
control would have to be repro-
grammed.
124
SPECIAL FEATURES
To unlock the doors and boot
or tailgate
1
Place the ignition key in the lock of
one of the front doors and turn it
towards the front of the vehicle.
Alternatively, press button
2 on the
remote control.
2
Important
DEADLOCKING*
After deadlocking, anybody inside
the car, and without the remote
Deadlocking is an additional security device which means that the interior and
control, will not be able to get out
exterior door controls cannot open the doors, when deadlocked.
by themselves. The doors can
only be unlocked by using the
Deadlocking can be carried out in two ways:
remote control, or the ignition key
- With the remote control.
in the door lock.
- With the ignition key.
If the battery is disconnected
deadlocking remains activated. It
To operate deadlocking
is still possible to open one of the
After locking the doors you have five seconds in which to operate the dead-
front doors using the ignition key,
locking.
but the key will only open that par-
If using the remote control:
ticular door.
- press button 1 once to lock your vehicle, the direction indicators stay on for
2 seconds.
- press button 1 for a second time within the five seconds to deadlock your vehi-
cle, the direction indicators flash once.
- press button 2 to unlock your vehicle, the direction indicators flash several times.
If using the ignition key, keep the key in the lock of one of the front doors, with the
key turned towards the rear of the vehicle (turn the key towards the front to unlock).
* According to specification.
125
SPECIAL FEATURES
To programme the remote
To check that programming
Do not operate the dead-
control(s)
has been correctly carried out:
locking if there is some-
To program m e the deadlocking
- press button 1 on the remote con-
one inside the vehicle.
remote controls key(s) (on first use):
trol key (or one of the remote con-
- the doors must be unlocked.
trol keys*).
Keep your key reference
- use the key with remote control to
- the doors and boot or tailgate will
number in a safe place.
turn on the ignition (to position A
lock.
This will enable you to order a
“accessories”).
- if this is not the case: repeat the
new key if the key is lost or stolen.
- immediately press the large button
programming.
on the key.
Check that the batteries are in
- turn off the ignition.
good condition.
If the red indicator light comes on
this indicates correct operation of
the transmitter but not that the
doors have been opened or
locked; wait at least one second
between each attempt.
* According to specification.
126
SPECIAL FEATURES
ALARM SYSTEM*
To set the alarm (exterior and
To disarm the alarm (exterior
interior protection)
and interior protection)
Setting and disarming the
The ignition must be switched off.
Press the unlocking button on the
alarm
You must be outside the vehicle
remote control.
Press the locking button of the
The doors unlock.
Switching off the siren
remote control key
(if your vehicle
The direction indicators flash for two
The alarm completes the security
has deadlocking, you then need to
seconds.
equipment of your vehicle. It com-
press this button again).
The red lamp on the switch goes out.
prises two types of protection:
The doors will lock.
Note : if the lamp continues to flash
The direction indicators come on
after disarming the alarm, it is
- exterior protection: when this is
continuously for two seconds.
because it has been triggered. This
set, the alarm sounds if a door,
The red lamp on the switch flashes
flashing will stop on switching on the
the bonnet, the boot or the tail-
once a second.
ignition.
gate are opened.
Five seconds afterwards : the exteri-
- interior sensor protection: when
or protection is set.
it is set, the alarm sounds if the
sensors detect a variation in the
Fifty seconds afterwards : the interi-
air movement inside the vehicle
or protection is set.
(breaking of a window) or a
Note : when the alarm is triggered,
movement inside the vehicle.
the siren sounds for thirty seconds.
It is also equipped with an anti-
It then stops, but the alarm remains
tamper function.
set.
If an attempt is made to neutralise
the leads to the siren, the central
Warning
control or the battery:
If, on setting the alarm, a door, the
- the alarm is triggered,
boot, tailgate or the bonnet are not
properly closed, the siren will be trig-
- the siren sounds, the headlights
gered briefly. If the vehicle is proper-
come on*.
ly closed within forty five seconds
after this, the alarm is set, the direc-
tion indicators come on continuously
for two seconds.
In all cases the alarm is set forty five
seconds afterwards.
* According to specification.
127
SPECIAL FEATURES
Selecting the type of
To lock the vehicle without
protection
setting the alarm
Locking without setting the alarm
It is the remote control which sets the
Special precautions
alarm.
To set the alarm with exterior pro-
Therefore, if you wish to lock the
tection only
vehicle without setting the alarm,
use the key.
If, while you are away from the vehi-
1
cle, you wish to leave a window par-
To charge or replace the battery :
tially open or a pet inside the vehicle,
- Switch on the ignition.
you should choose exterior protec-
- Within ten seconds after switching
tion only. In this case :
on the ignition press the interior
- Switch off the ignition.
protection switch
1
and keep it
- Press the interior protection switch
pressed for two seconds.
1 until the lamp comes on continu-
- The indicator light flashes rapidly
ously.
for three seconds.
- Get out of the vehicle.
- Switch off the ignition.
- Press the locking button
(or the
- You can then disconnect the bat-
Emergency cut-off
deadlocking button if the vehicle is
tery.
(Failure of the remote control)
fitted with this) on the remote con-
After reconnecting the battery :
Unlock the doors with the key.
trol.
- Lock, then unlock, the vehicle,
Open the door.
- The doors will lock.
using the remote control.
The alarm is triggered. You then
- The direction indicators come on
The alarm will be set the next time
have ten seconds to stop it :
continuously for two seconds.
the vehicle is locked.
- Switch on the ignition.
- The red lamp on the switch
flashes once a second.
- Immediately press the interior pro-
tection switch 1.
To disarm the alarm on exterior pro-
tection only.
- The siren stops and the alarm is
disarmed.
Press the unlocking button on the
remote control key.
The doors unlock and the courtesy
lights come on.
The direction indicators flash for two
DO NOT MAKE ANY MODIFICATIONS
seconds.
TO THE ALARM SYSTEM.
The red lamp on the switch goes out.
79
YO U R 306 IN D ETA IL
DOORS
LOCKING FROM INSIDE THE
Take careful note of the
VEHICLE
numbers on the keys.
Opening the doors from
The key number is coded
outside
Without central locking
on the label attached to
To lock, press button A . The button
the key. If the key is lost
locks that door.
your PEUGEOT dealer can rapidly
supply you with new keys or a
With central locking
remote control.
To lock, press button A .
As a safety precaution (with chil-
Locking the driver’s door locks the
dren on board) remove the ignition
front and rear doors and the tailgate.
key when you leave the vehicle,
On the other doors the button only
even for a short time.
locks that door.
The high frequency remote control
is a high-performance system
which has a powerful beam. There-
fore do not operate it while it is in
Opening the doors from
your pocket as there is a possibil-
inside
ity that it may unlock your vehicle.
A
80
YO U R 306 IN D ETA IL
Locking or unlocking the
1
boot or tailgate
3 or 5 door without central locking
Turn the key in the tailgate lock.
Locking or unlocking the
4 door or estate
boot or tailgate
Using the key: turn the key in the boot
3 or 5 door with central locking
or tailgate lock.
The tailgate locks and unlocks at the
Child lock
Using the remote control*: the boot or
same time as the doors.
This prevents opening of the rear
tailgate locks and unlocks at the same
doors from inside the vehicle.
time as the doors.
Tailgate release
Turn control 1 a quarter turn using the
In the event of a central locking oper-
Locking the boot only (4 door)
ignition key.
ating fault, this enables the tailgate to
Turn the key to the right in the boot
be unlocked:
It is still possible to open the doors
lock.
from outside the vehicle.
- fold the rear seats to gain access
The boot will be locked whatever the
to the control from inside the
action of the remote control or the
vehicle.
driver’s door lock.
- Insert the ignition key in the
To open, turn the key to the left in the
opening and slide it to unlock the
boot lock. The boot will then be locked
tailgate.
at the same time as the central
locking of the doors.
The seat back locking control enables
you to prevent unauthorised entry to
the boot, even if the doors are open.
* According to specification.
81
YO U R 306 IN D ETA IL
1
1
TILT AND SLIDE ELECTRIC
Bonnet
Outside the vehicle
SUN ROOF*
Inside the vehicle: Pull the handle.
Raise the catch 1 and support the
bonnet as it rises.
Open the cover.
To open
Press the rear part of the switch 1.
To close
Press the front part of the switch 1.
To tilt
Press the front part of the switch 1.
To close, press the rear part of the
switch 1.
Tilting manual sun roof
Tilt the handle.
* According to specification.
82
YO U R 306 IN D ETA IL
Fuel filler flap
Filling with fuel
To open*: firm ly pull the handle on
Switch off the engine.
the floor to the outside of the driver’s
There is a holder for the fuel filler cap.
seat.
A label on the inside of the flap shows
To close: from outside, push the flap
which fuels are permitted and which
back and check that it is secured
are not allowed.
correctly.
The capacity of the tank is approx-
imately 13 gallons (60 litres).
Use the ignition key to open and close
the fuel filler cap independently of
opening the doors.
* According to specification.
90
YO U R 306 IN D ETA IL
Dipped beam/main beam change
Front and rear fog
Pull the stalk fully towards you.
lamps on.
A
B
These operate with the
Note: when the ignition is switched
side lights and the
off, if the driver’s door or front pas-
dipped/main beam headlights. When
senger door* is left open, a buzzer
the side lights are switched off, there
sound
s if you forget that you have left
is a return to the front fog lamps only
your lights on.
position.
Front and rear fog lights
Direction indicators
(flashers)
To switch on, turn the ring. The posi-
tion is confirmed by the light on the
Left : downwards.
instrument panel.
Right : upwards.
LIGHTING CONTROL
Front lights
Selection is by turning ring A.
Front and rear (ring B)
Horn
Press the end of the
lighting stalk.
Lights off.
Lights off.
Front fog lamps on.
Side lights on.
These operate with the side lights and
the dipped/main beam headlamps.
Dipped/main beam
headlamps
* According to specification.
91
YO U R 306 IN D ETA IL
Automatic windscreen wiper
3
In good weather or in rain,
In position 1, the wipers operate auto-
both day and night, if the
matically and adjust their speed to
rear fog lamp is lit it
the rainfall.
2
causes glare and is pro-
After switching off the ignition or
hibited.
after starting, this function must be
Do not forget to switch it off as
1
re-set, so the sensor can detect the
soon as it is no longer needed.
condition of the windscreen.
Do not cover the rain detector
To do this, change the stalk position :
located on the windscreen behind
-
from 1 to 0 then back to 1 (con-
the interior mirror.
firmed by a single wipe),
0
When using an automatic car
-
change from 1 to 2, then back to 1
wash, switch off the ignition or
(confirmed by two wipes).
check that the wiper control is not
in the automatic position.
A
In winter it is advisable to wait for
4
the windscreen to completely clear
of ice before operating the auto-
WINDSCREEN WIPERS
matic wipe.
Rear screen wiper
(estate)
Front windscreen wipers
Turn ring A to the first notch,
for intermittent wiping.
3 Fast wipe.
2 Normal wipe.
Rear screen wash
1 Intermittent or automatic wipe.
(estate)
Turn ring A beyond the first
0 Park.
notch.
4 Single wipe.
Windscreen and headlamp
wash*
Pull the wipers stalk towards you.
The headlamps wash works if the
dipped or main beam headlamps are
on.
* According to specification.
99
YO U R 306 IN D ETA IL
1
2
3
4
ELECTRIC WINDOWS*
Temporary locking of the rear
windows (child safety) control
1. Driver’s electric window control.
This allows the rear windows to be
locked in any position.
You have two options*:
Manual operation: Push or pull switch 1, lightly. The window stops when the
NOTE: as a safety measure (children
switch is released.
on board), remove the ignition key
when leaving the vehicle even for a
Automatic operation: Push or pull switch 1 firmly. Pressing once opens or
short time.
closes the window completely. Automatic opening and closing operate only
when the engine is switched on.
2. Passenger electric window control.
Push or pull switch 2. The window stops when the switch is released.
3. Left rear electric window control.
4. Right rear electric window control.
* According to specification.
100
YO U R 306 IN D ETA IL
2
A
Manual mirrors
Electric mirrors
Operate the adjusting lever in all four
Turn the control 2 to the right or to the
directions to adjust.
left to select the corresponding mirror.
Tilting windows (3-door)
Move the control 2 in all four direc-
To open the rear side windows, tilt the
tions to adjust.
lever A and push the window out-
wards.
When parked, the mirrors can be folded back manually.
The driver’s mirror is “non-spherical*” in order to reduce the “blind
spot”. As a result, objects observed in the mirror are closer than they
appear. This must be taken into account to correctly judge the dis-
tance of vehicles approaching from the rear.
* According to country.
104
YO U R 306 IN D ETA IL
Athermic windscreen*
The windscreen has two non-reflec-
tive zones located either side of the
base of the interior rear-view mirror.
These are for affixing toll cards or
parking passes.
Note: the athermic glass reduces the
effect of the sun’s rays, by limiting
the heating of the passenger com-
partment, but its reflective coating
blocks radio signals.
Rear screen blind (4 door)*
Storage compartments (estate)
Pull the blind by the central tab then
There are two storage compartments,
position the hooks in the locations.
fitted with elastic retaining straps,
Support it as it returns.
behind the boot side trims.
To gain access to a storage compart-
ment, pull the handle towards you.
* According to specification.
102
YO U R 306 IN D ETA IL
Hazard warning lights
Rear screen demisting
The switch and the direction
Rear screen (and mirrors)*
indicators flash.
electric demisting control.
This controls the indicator
Goes out automatically after
lights simultaneously and continu-
approximately 12 minutes to avoid
ously.
excessive power consumption.
Only use in case of danger, in an
Pressing the button again will operate
1
emergency stop or for driving in
the
demisting
for
another
unusual conditions.
12 minutes.
They can operate with the ignition off.
2
Digital clock*
Setting:
1 - Adjusting of hours.
2 - Adjusting of minutes.
Outside temperature display*
This indicates the outside tempera-
ture. When the temperature is
between minus 3 °C and + 5 °C, the
°C symbol flashes indicating a risk of
ice.
* According to specification.
