Peugeot 301 (2017 year). Instruction

PEUGEOT Connect Radio

Selecting the source

Press

Radio Media to display the

primary page.

Press the "

SOURCES" button.

Choose the source.

Bluetooth

streaming

Streaming allows you to listen to music from
your smartphone.

The Bluetooth profile must be activated, first
adjust the volume on your portable device (to a
high level).
Then adjust the volume of your system.

If play does not start automatically, it may be
necessary to start the audio playback from the
smartphone.
Control is from the portable device or by using
the system's touch buttons.

Once connected in Streaming mode, the
smartphone is considered to be a media
source.

Connecting Apple

players

Connect the Apple

player to the USB port

using a suitable cable (not supplied).
Play starts automatically.

Control is via the audio system.

The classifications available are those
of the portable device connected
(artists / albums / genres / playlists /
audiobooks / podcasts), you can also use
a classification structured in the form of a
library.
The default classification used is by artist.
To modify the classification used, return
to the first level of the menu then select
the desired classification (playlists for
example) and confirm to go down through
the menu to the desired track.

The version of software in the audio system
may not be compatible with the generation of
your Apple

player.

Information and advice

The system supports USB Mass Storage
devices, BlackBerry

devices or Apple

players via USB ports. The adapter cable
is not supplied.
Device management is done by the audio
system controls.
Other peripherals, not recognised on
connection, must be connected to the
auxiliary socket using a jack cable (not
supplied) or via Bluetooth streaming,
depending on compatibility.

To protect the system, do not use a USB
hub.

The audio equipment will only play audio files
with ".wav, .wma, .aac, .ogg and .mp3" file
extensions and with a bit rate of between
32 Kbps and 320 Kbps.
It also supports VBR (Variable Bit Rate) mode.
No other file types (.mp4, etc.) can be read.
".wma" files must be of the standard
wma 9 type.
Sampling frequencies supported
are 11, 22, 44 and 48 KHz.

PEUGEOT Connect Radio

It is advisable to restrict file names to
20 characters, without using special characters
(e.g.: " " ? . ; ù) so as to avoid any reading or
display problems.

Use only USB keys in FAT32 format
(File Allocation Table).

It is recommended that the original USB
cable for the portable device is used.

In order to be able to play a burned CDR or
CDRW, select standards ISO 9660 level 1, 2 or
Joliet if possible when burning the CD.
If the disc is burned in another format, it may
not be played correctly.
It is recommended that the same burning
standard is always used on an individual disc,
with the lowest speed possible (4x maximum)
for the best acoustic quality.
In the particular case of a multi-session CD, the
Joliet standard is recommended.

Telephone

MirrorLink

smartphone

connection

As a safety measure and because it
requires sustained attention by the driver,
using a smartphone when driving is
prohibited.
All operations must be done with the

vehicle stationary.

The synchronisation of a personal
smartphone allows users to display
applications adapted for the smartphone's
MirrorLink

technology on the vehicle

screen.
The principles and standards
are constantly changing, for the
communication process between the
smartphone and the system to operate,
it is essential that the smartphone is
unlocked;

update the operating system

of the smartphone as well as the date

and time of the smartphone and the

system.

For the list of eligible smartphones, go
to the Brand's internet website in your
country.

As a safety measure, applications can
only be viewed with the vehicle stationary;
display is interrupted once the vehicle is
moving.

The "MirrorLink

" function requires a

compatible smartphone and applications.

Telephone not connected by

Bluetooth

Connect a USB cable. The
smartphone charges when
connected by a USB cable.

From the system, press
"

Telephone" to display the primary

page.

Press "

MirrorLink

" to start the

application in the system.

Depending on the smartphone, it may be
necessary to activate the "

MirrorLink

function.

PEUGEOT Connect Radio

During the procedure, several
screen pages relating to certain
functions are displayed.
Accept to start and complete the
connection.

When connecting a smartphone
to the system, it is recommended
that "Bluetooth

" be started on the

smartphone

Telephone connected by

Bluetooth

From the system, press
"

Telephone" to display the primary

page.

Press the "

PHONE" button to display the

secondary page.

Press "

MirrorLink

" to start the

application in the system.

Once the connection is established, a page
is displayed with the applications already
downloaded to your smartphone and adapted
to MirrorLink

technology.

Access to the different audio sources remains
accessible in the margin of the MirrorLink

display, using touch buttons in the upper bar.
Access to the menus for the system is possible
at any time using the dedicated buttons.

There may be a wait for the availability of
applications, depending on the quality of
your network.

CarPlay

smartphone

connection

As a safety measure and because it
requires sustained attention by the driver,
using a smartphone when driving is
prohibited.
All operations must be done with the

vehicle stationary.

The synchronisation of a personal
smartphone allows users to display
applications adapted for the smartphone's
CarPlay

technology on the vehicle screen

when the smartphone's CarPlay

function

has been previously activated.
As the principles and standards are
constantly changing,

it is recommended

that you keep your smartphone's

operating system updated.

For the list of eligible smartphones, go
to the Brand's internet website in your
country.

Connect a USB cable. The
smartphone charges when
connected by a USB cable.

From the system, press Car Play to
display the

Telephone

interface.

If the smartphone is already
connected by Bluetooth

PEUGEOT Connect Radio

Connect a USB cable. The
smartphone charges when
connected by a USB cable.

From the system, press
"

Telephone" to display the primary

page.

Press the "

PHONE" button to go to the

secondary page.

Press on "

CarPlay" to display the

CarPlay

interface.

On connecting the USB cable, the
CarPlay

function deactivates the

system's Bluetooth

mode.

You can go to the CarPlay

navigation at any time by pressing
the system's

Navigation button.

Smartphone connection

Android Auto

As a safety measure and because it
requires sustained attention by the driver,
using a smartphone when driving is
prohibited.
All operations must be done with the

vehicle stationary.

On your smartphone, download the
Android Auto application.

The synchronisation of a personal
smartphone allows users to display
applications adapted for the smartphone's
Android Auto technology on the vehicle
screen.
The principles and standards
are constantly changing, for the
communication process between the
smartphone and the system to operate,
it is essential that the smartphone is
unlocked;

update the operating system

of the smartphone as well as the date

and time of the smartphone and the

system.

For the list of eligible smartphones, go
to the Brand's internet website in your
country.

As a safety measure, applications can
only be viewed with the vehicle stationary;
display is interrupted once the vehicle is
moving.

The "Android Auto" function requires the
use of a compatible smartphone and
applications.

Telephone not connected by

Bluetooth

Connect a USB cable. The
smartphone charges when
connected by a USB cable.

From the system, press
"

Telephone" to display the primary

page.

Press "

Android Auto" to start the

application in the system.

Depending on the smartphone, it may be
necessary to activate the "

Android Auto"

function.

PEUGEOT Connect Radio

During the procedure, several
screen pages relating to certain
functions are displayed.
Accept to start and complete the
connection.

When connecting a smartphone
to the system, it is recommended
that "Bluetooth

" be started on the

smartphone

Telephone connected by

Bluetooth

From the system, press
"

Telephone" to display the primary

page.

Press the "

PHONE" button to display the

secondary page.

Press "

Android Auto" to start the

application in the system.

Different audio sources remain accessible in
the margin of the Android Auto display, using
touch buttons in the upper bar.
Access to the menus for the system is possible
at any time using the dedicated buttons.

There may be a wait for the availability of
applications, depending on the quality of
your network.

Pairing a Bluetooth

telephone

As a safety measure and because it
requires sustained attention by the
driver, the pairing of a Bluetooth mobile
telephone with the Bluetooth hands-free
system of your audio system must be
done with the

vehicle stationary and the

ignition on.

Activate the Bluetooth function on the
telephone and ensure that it is "visible to
all" (telephone configuration).

Procedure from the telephone

Select the name of the system in the
list of devices detected.

In the system, accept the connection request
from the telephone.

To complete the pairing, whichever
procedure is used (from the telephone or
from the system), ensure that the code
is the same in the system and in the
telephone.

Procedure from the system

Press

Telephone to display the

primary page.

Press "

Bluetooth search".

The list of telephones detected is
displayed.

Select the name of the chosen
telephone in the list.

PEUGEOT Connect Radio

On return to the vehicle, if the last
telephone connected is present again, it is
automatically recognised and within about
30 seconds of switching on the ignition,
the connection is established without any
action on your part (Bluetooth activated).

To modify the connection profile :

Press

Telephone to display the

primary page.

Press the "

PHONE" button to go to the

secondary page.

Press "

Bluetooth connection" to

display the list of paired devices.

Press the "details" button of a paired
device.

The system offers to connect the telephone
with 3 profiles:
- "

Telephone" (hands-free kit, telephone

only),

- "

Streaming" (streaming: wireless playing of

the audio files on the telephone),

- "

Internet data".

Select one or more profiles.

Press "

OK" to confirm.

The ability of the system to connect to just
one profile depends on the telephone.
All three profiles may connect by default.

The services available depend on
the network, the SIM card and the
compatibility of the Bluetooth devices
used. Check the instructions for your
telephone and with your service provider
for the services to which you have access.

The profiles compatible with the system
are: HFP, OPP, PBAP, A2DP, AVRCP,
MAP and PAN.

Go to the Brand's website for more information
(compatibility, additional help, ...).

Managing paired telephones

This function allows the connection or
disconnection of a peripheral device as
well as the deletion of a pairing.

Press

Telephone to display the

primary page.

Press the "

PHONE" button to go to the

secondary page.

If the pairing procedure fails, it is
recommended that you deactivate and
then reactivate the Bluetooth function in
your telephone.

Depending on the type of telephone, you
may be asked to accept or not the transfer
of your contacts and messages.

Automatic reconnection

PEUGEOT Connect Radio

Press "

Bluetooth connection" to

display the list of paired devices.

Press on the name of the telephone
chosen in the list to disconnect it.
Press again to connect it.

Deleting a telephone

Press the recycle bin at the top right
of the screen to display a recycle bin
alongside the telephone chosen.

Press the recycle bin alongside the
telephone chosen to delete it.

Receiving a call

An incoming call is announced by a ring and a
superimposed display in the screen.

Make a short press on the steering
mounted

PHONE button to accept

an incoming call.

And

Make a long press

on the steering mounted

PHONE

button to reject the call.

Press "

End call".

Making a call

Using the telephone is not recommended
while driving.
Park the vehicle.
Make the call using the steering mounted
controls.

Calling a new number

Press

Telephone to display the

primary page.

Enter the phone number using the
digital keypad.

Press "

Call" to start the call.

Calling a contact

Press

Telephone to display the

primary page.

Or make a long press

on the steering mounted

PHONE

button.

Press "

Contacts".

Select the desired contact from the list offered.

Press "

Call".

PEUGEOT Connect Radio

Calling a recently used

number

Press

Telephone to display the

primary page.

Make a long press

on the steering mounted button.

Press "

Recent calls".

Select the desired contact from the list offered.

It is always possible to make a call directly
from the telephone; as a safety measure,
first park the vehicle.

Setting the ringtone

Press

Telephone to display the

primary page.

Press the "

OPTIONS" button to go to the

secondary page.

Press "

Ring volume" to display the

volume bar.

Press the arrows or move the cursor
to set the ring volume.

Configuration

Profile settings

As a safety measure and because it
requires the sustained attention of the
driver, changes to settings must only be
done with the

vehicle stationary.

Press

Settings to display the

primary page.

Press "

Profiles".

Select "

Profile 1" or "Profile 2" or "Profile 3"

or "

Common profile".

Press this button to enter a name for
the profile using the virtual keypad.

Press "

OK" to save.

PEUGEOT Connect Radio

Press the back arrow to confirm.

Press this button to activate the
profile.

Press the back arrow again to
confirm.

Press this button to initialise the
profile selected.

Adjusting brightness

Press

Settings to display the

primary page.

Press

Brightness.

Move the cursor to adjust the
brightness of the screen and/or of
the instrument panel (depending on
version).
Press in the grey zone to confirm.

Modifying system settings

Press

Settings to display the

primary page.

Press "

Configuration" to go to the

secondary page.

Press "

System configuration".

Select "

Units" to change the units of distance,

fuel consumption and temperature.

Press "

Factory settings" to return to the initial

settings.

Returning the system to factory settings
activates the English language by default
(depending on version).

Select "

System info" to display the versions of

the different modules installed in the system.

Press the back arrow to confirm.

Press

Settings to display the

primary page.

Press "

Configuration" to go to the

secondary page.

Press "

Screen configuration".

Press "

Brightness".

Move the cursor to adjust the
brightness of the screen and/or of
the instrument panel (depending on
version).

Press "

Animation"

Activate or deactivate: "

Automatic

scrolling".

Select "

Animated transitions".

Press the back arrow to confirm.

PEUGEOT Connect Radio

Selecting the language

Press

Settings to display the

primary page.

Press "

Configuration" to go to the

secondary page.

Select "

Language" to change the

language.

Press the back arrow to confirm.

Setting the time

Press

Settings to display the

primary page.

Press "

Configuration" to go to the

secondary page.

Press "

Date and time".

Select "

Time".

Press this button to adjust the time
using the virtual keypad.

Press "

OK" to save the time.

Press this button to define the time
zone.

Select the display format for the time
(12h / 24h).

Activate or deactivate
synchronisation with GPS (UTC).

Press the back arrow to save the
settings.

The system does not automatically
manage the change between winter and
summer time (depending on the country
of sale).

Setting the date

Press

Settings to display the

primary page.

Press "

Configuration" to go to the

secondary page.

Press "

Date and time".

Select "

Date".

Press on this button to define the
date.

Press the back arrow to save the
date.

Select the display format of the date.

Press the back arrow again to
confirm.

PEUGEOT Connect Radio

Radio

QUESTION

RESPONSE

SOLUTION

The reception quality of the tuned radio station
gradually deteriorates or the stored stations are
not working (no sound, 87.5 Mhz is displayed ...).

The vehicle is too far from the transmitter of
the station or no transmitter is present in the
geographical area.

Activate the "RDS" function by means of the
upper band to enable the system to check
whether there is a more powerful transmitter in
the geographical area.

The environment (hills, buildings, tunnels,
basement car parks...) block reception, including
in RDS mode.

This phenomenon is normal and does not
indicate a failure of the audio equipment.

The aerial is absent or has been damaged (for
example when going through a car wash or into
an underground car park).

Have the aerial checked by a Brand dealer.

I cannot find some radio stations in the list of
received stations.
The name of the radio station changes.

The station is not received or has changed its
name in the list.

Press the round arrow on the "List" tab of the
"Radio" page.

Some radio stations send other information
in place of their name (the title of the song for
example).
The system interprets these details as the
station name.

PEUGEOT Connect Radio

Media

QUESTION

RESPONSE

SOLUTION

Playback of my USB memory stick starts only
after a very long wait (around 2 to 3 minutes).

Some files supplied with the memory stick
may greatly slow down access to reading
the memory stick (multiplication by 10 of the
catalogue time).

Delete the files supplied with the memory stick
and limit the number of sub-folders in the file
structure on the memory stick.

Some information characters in the currently
playing media are not displayed correctly.

The audio system does not display some types
of characters.

Use standard characters to name tracks and
folders.

Playback of streaming files does not start.

The connected device does not automatically
launch playback.

Start playback from the device.

Names of tracks and playing time are not
displayed on the audio streaming screen.

The Bluetooth profile does not allow the transfer
of this information.

PEUGEOT Connect Radio

QUESTION

RESPONSE

SOLUTION

I cannot connect my Bluetooth telephone.

The telephone's Bluetooth function may be
switched off or the telephone may not be visible.

Check that your telephone has Bluetooth
switched on.
Check in the telephone settings that it is "visible
to all".

The Bluetooth telephone is not compatible with
the system.

You can check the compatibility of your
telephone on the Brand's website (services).

The volume of the telephone connected in
Bluetooth mode is inaudible.

The sound depends on both the system and the
telephone.

Increase the volume of the audio system, to
maximum if required, and increase the volume
of the telephone if necessary.

Ambient noise affects the quality of the
telephone call.

Reduce the ambient noise level (close the
windows, reduce the booster fan speed, slow
down, ...).

The contacts are listed in alphabetical order.

Some telephones offer display options.
Depending on the settings chosen, contacts can
be transferred in a specific order.

Modify the telephone directory display settings.

Telephone

PEUGEOT Connect Radio

Settings

QUESTION

RESPONSE

SOLUTION

When changing the setting of treble and bass,
the equalizer setting is deselected.
When changing the equalizer setting, the treble
and bass settings are reset.

The selection of an equalizer setting imposes
the settings for treble and bass and vice-versa.

Modify the treble and bass or equalizer settings
to obtain the desired musical ambience.

When changing the balance setting, distribution
is deselected.
When changing the distribution setting, the
balance setting is deselected.

The selection of a distribution setting imposes
the balance settings and vice-versa.

Modify the balance setting or the distribution
setting to obtain the desired sound quality.

There is a difference in sound quality between
the different audio sources.

To allow for optimal listening quality, the
audio settings can be tailored to different
sound sources, which can generate audible
differences when changing source.

Check that the audio settings are adapted to the
sources listened to. Adjust the audio functions
to the middle position.

When the engine is off, the system stops after
several minutes of use.

When the engine is switched off, the system's
operating time depends on the state of charge
of the battery.
Stopping is normal; the system automatically
goes into energy economy mode to maintain an
adequate charge in the battery.

Turn the ignition on to increase the charge of
the battery.

Peugeot 301 (2017 year). Instruction - part 19
