Peugeot 108 (2016 year). Instruction

Driving

108_en_Chap04_conduite_ed01-2016

temporarily taking control of
gear changes

You can temporarily take control of gear
changes using the "+" and "-" steering
mounted control paddles.
gear change commands are only acted on if
the engine speed allows. there is an audible
signal if a command is not accepted.
the gear engaged is displayed in the
instrument panel.
this function allows you to anticipate certain
situations such as overtaking a vehicle or
approaching a corner.
After a few moments with no action on the
controls, the gearbox returns to automatic
control of the gears.

It is possible to change mode at any time, by
moving the gear selector from position e to
position M and the other way round.

Never select neutral N when the vehicle
is moving.

F Place the gear selector in position M.
F Change up or down using:

- the gear selector, pushing:
- back,

"+" to change up,

- forward,

"-" to change down.

- or the "+" or "-" steering mounted

control paddle.

the gear engaged is displayed.
gear change commands are only acted on if
the engine speed allows.
It is not necessary to release the accelerator
peal during gear changes. there is an audible
signal if a command is not accepted.
When braking or slowing down, the gearbox
automatically changes down so that pick-up is
in the right gear.

Manual mode

under sharp acceleration, the gearbox will
not change up without action by the driver on
the gear selector or steering mounted control
paddles (unless the engine speed is close to
maximum).

to engage reverse, the vehicle must be
stationary with your foot on the brake pedal.
F Select position R.

Reverse

there is an audible signal on engaging reverse.

Driving

108_en_Chap04_conduite_ed01-2016

the vehicle can be stopped whatever the
position of the gear selector (N, e or R).
However, there is an audible signal on opening
the driver's door if the gear selector is not at
position N.

Switching off

When the vehicle is stopped with the
engine running, always put the gear
selector to neutral N.

there is a continuous audible signal
if you turn the ignition switch to "oFF"
with the vehicle in 2

, 3

, 4

or 5

gear.

In this case return the ignition switch
to "oN", move the gear selector to
position N, then to position e, M or R,
then turn the ignition switch to "oFF".

On a slope, use the brakes to
immobilise the vehicle and place the
gear selector in position N, e or R.

With the ignition on, illumination
of this warning lamp indicates a
gearbox fault.
Contact a PeugeOt dealer or a
qualified workshop.

operating faults

In all cases, it is essential that you
apply the parking brake to immobilise
the vehicle.

Before doing anything under the
bonnet, check that the gear selector is
in neutral N and the parking brake is
applied.

Limits of operation

On a gradient, or when hill start assist is
activated, never hold the vehicle using the
accelerator: you could damage the clutch.
In these situations there is an audible signal.
F Move the gear selector to position N.
F Wait 15 minutes to allow the clutch to cool

down before setting off.

check that the ignition switch is at the "oN"
position,

place the gear selector at N, then move it
to e, M or R.

If 1 is flashing in the instrument panel:
-

place the gear selector at e or M, then
move it to N.

If R is flashing in the instrument panel:
-

place the gear selector at R, then move it
to N.

If N is flashing in the instrument panel
accompanied by an audible signal for a long time:

Driving

108_en_Chap04_conduite_ed01-2016

System which reduces fuel consumption by recommending the most appropriate gear.

gear shift indicator

operation

example:
-

You are in third gear.

You press the accelerator pedal.

the system may suggest that you engage
a higher gear.

Depending on the driving situation and your
vehicle's equipment, the system may advise
you to change gear.
the gear engagement recommendations must
not be considered compulsory. In fact, the
configuration of the road, the amount of traffic
and safety remain determining factors when
choosing the best gear. therefore, the driver
remains responsible for deciding whether or not
to follow the advice given by the system.
this function cannot be deactivated.

the information appears in the
instrument panel in the form of an
arrow.

the system adapts its gear change
recommendation according to the
driving conditions (slope, load, ...) and
the demands of the driver (power,
acceleration, braking, ...).
the system never suggests:
-

engaging first gear,

engaging reverse gear.

With an etg electronic gearbox, the
system is only active in manual mode.

With the Puretech 82 engine, the system
only suggests when to change up.

Driving

108_en_Chap04_conduite_ed01-2016

Hill start assist

System which keeps your vehicle immobilised
temporarily (approximately 2 seconds) when
starting on a gradient, the time it takes to
move your foot from the brake pedal to the
accelerator pedal.
this system only operates when:
-

the vehicle is completely stationary, with
your foot on the brake pedal,

certain conditions of slope are met,

with the driver’s door closed.

the hill start assist system cannot be
deactivated.

on an ascending slope, with the vehicle
stationary, the vehicle is held for a
momentarily when you release the brake
pedal:
-

if you are in first gear or neutral with a
manual gearbox,

if you are in position e or M with an etg
electronic gearbox.

operation

on a descending slope, with the vehicle
stationary and reverse gear engaged, the
vehicle is held momentarily when you
release the brake pedal.

operating fault

If a fault in the system occurs, this
warning lamp comes on. Contact
a PeugeOt dealer or a qualified
workshop to have the system
checked.

Do not exit the vehicle while it is being
held in the hill start assist phase.
If you need to exit the vehicle with the
engine running, apply the parking brake
manually.

Driving

108_en_Chap04_conduite_ed01-2016

Stop & Start (Vti 68 S&S engine)

operation

going into engine StoP
mode

this indicator lamp comes on in the
instrument panel and the engine
goes into standby automatically:

when stationary, in neutral, and you
release the clutch pedal.

Never refuel with the engine in
StOP mode; you must switch off the
ignition with the button.

For smoother operation, during
parking manoeuvres StOP mode is
not available for a few seconds after
coming out of reverse gear.
the Stop & Start does not affect the
vehicle's systems, such as for example,
braking, power steering...

the Stop & Start system puts the engine
temporarily into standby - StOP mode - during
stops in the traffic (red lights, traffic jams, or
other...). the engine restarts automatically -
StARt mode - as soon as you want to move
off. the restart takes place instantly, quickly
and silently.
Perfect for urban use, the Stop & Start system
reduces fuel consumption and exhaust
emissions as well as the noise level when
stationary.

Stop & Start time counters

A partial time counter counts the periods in
StOP mode during a journey.
It is displayed in the trip computer once the
Stop & Start is operating.
Press one of the "DISP" buttons to return to the
previous display.
A global time counter counts the periods in
StOP mode since the last reset.
When it is displayed, press one of the
"DISP" buttons to reset the counter.

Driving

108_en_Chap04_conduite_ed01-2016

going into engine StARt
mode

this indicator lamp goes off and the
engine starts automatically:

when you fully depress the clutch pedal.

StARt mode is invoked automatically when:
-

you open the driver's door,

you open the bonnet,

you unfasten the driver's seat belt,

some special conditions (battery charge,
engine temperature, braking assistance,
descending a steep gradient, adjustment of
the air conditioning...) where the engine is
needed for control of a system.

Special cases: StARt invoked
automatically

In the event of a fault with the system,
this warning lamp flashes in the
instrument panel.

operating fault

Have it checked by a PeugeOt dealer or a
qualified workshop.

Special cases: StoP mode not
available

StOP mode is not invoked principally when:
-

the driver's door is open,

the driver's seat belt is not fastened,

the engine is needed to maintain a
comfortable temperature in the passenger
compartment,

demisting is active,

some special conditions (battery charge,
engine temperature, braking assistance,
vehicle stopped on a steep gradient, high
altitude...) where the engine is needed to
assure control of a system.

Driving

108_en_Chap04_conduite_ed01-2016

At any time, press this button to deactivate the
system.

Manual deactivation /
reactivation

If the system has been deactivated in
StOP mode, the engine restarts immediately.

the system is reactivated automatically at
every new engine start by the driver.

Press this button again.
the system is active again; this is confirmed by the
indicator lamp going off in the instrument panel.

Deactivation is confirmed by the
illumination of this indicator lamp in
the instrument panel.

Before doing anything under the
bonnet, deactivate the Stop & Start
system to avoid any risk of injury
resulting from automatic operation of
StARt mode.

Maintenance

the Stop & Start system requires a 12 V
battery of a special specification and
technology.
All work on this type of battery must be
done only by a PeugeOt dealer or a
qualified workshop.
For more information on the 12 V
battery, refer to the corresponding
section.

Driving

108_en_Chap04_conduite_ed01-2016

the speed limiter cannot, in any
circumstances, replace the need to
observe speed limits, nor can it replace the
need for vigilance on the part of the driver.

Speed limiter (Puretech 82 engine)

the speed limiter is switched on manually:
this can be done whatever the speed of the
vehicle. However, if you are driving at less than
20 mph (30 km/h), the programmed speed will
be fixed at 20 mph (30 km/h).
the speed limiter is paused by operation of the
control.
the programmed speed can be exceeded
temporarily by pressing the accelerator firmly
beyond the point of resistance.
to return to the programmed speed, simply
release the accelerator pedal until the vehicle
returns to the programmed speed limit.

System which prevents the vehicle from exceeding the speed programmed by the driver.

Steering mounted controls

the controls are grouped together on this
control stalk at the steering wheel.
1. Speed limiter on / off: by pressing the end

of the control stalk.

2. Decrease the setting: by pushing the

control stalk down.

3. Increase the setting: by pushing the control

stalk up.

4. Speed limiter on / pause: by pulling the

control stalk towards you

Displays in the instrument panel

the information is grouped together in the
instrument panel screen.
5.  Speed limiter mode selection indication.
6.  Speed limiter on / pause indication.
7.  Speed value setting.

the programmed speed remains in the
memory when the ignition is switched off.

Driving

108_en_Chap04_conduite_ed01-2016

Switching on

F Press the end of the control stalk: the

speed limiter mode is selected but is not
switched on.

F Switch the speed limiter on by pulling the

control stalk towards you, if the speed
displayed is suitable (by default, the last
speed programmed).

Once the function is selected, you can modify
the speed setting by:
-

by pushing the control stalk up to increase
the setting,

by pushing the control stalk down to
decrease the setting.

A brief push on the control stalk modifies the
speed setting by + or - 1 mph (km/h).
A maintained push on the control stalk modifies
the speed setting by + or - 5 mph (km/h).

Adjusting the speed limit
setting

You do not have to switch the speed
limiter on in order to set the speed.

Pause

F You can temporarily stop the the speed

limiter by pulling the control stalk towards
you again: the display confirms that it has
been stopped (Pause).

F Pull the control stalk towards you again to

restore the speed limiter.

Driving

108_en_Chap04_conduite_ed01-2016

Switching off

F Press the end of the control stalk.

the display of information related to the
speed limiter disappears.

operating fault

Illumination of this warning lamp in
the instrument panel indicates a fault
with the speed limiter.
Have it checked by a PeugeOt
dealer or a qualified workshop.

the use of mats not approved by
PeugeOt may interfere with the
operation of the speed limiter.
to avoid any risk of jamming of the
pedals:
-

ensure that the mat is secured
correctly,

do not fit one mat on top of another.

temporarily exceeding the
programmed speed

F Press

firmly on the accelerator pedal,

going beyond the point of resistance, to
exceed the programmed speed limit.

the speed limiter is deactivated temporarily
and the displayed programmed speed flashes.

As soon as the vehicle's speed returns to the
programmed value, the limiter operates again:
the display of the programmed speed becomes
steady again.

An audible signal accompanies the
flashing of the programmed speed
when exceeding the speed is not due to
an action by the driver (steep hill...).

Driving

108_en_Chap04_conduite_ed01-2016

Speed limiter (Vti 68 engine)

System which prevents the vehicle from exceeding the speed programmed by the driver.

the programmed limit speed is erased
when switching off the ignition.

Steering mounted controls

the controls are grouped together on this
control stalk at the steering wheel.
1. Speed limiter on / off: by pressing the end

of the control stalk.

2. Programming the speed

Decrease the setting: by pushing the
control stalk down.

3. Restore speed limiter

Increase the setting: by pushing the control
stalk up.

4. Pause speed limiter: by pulling the control

stalk towards you.

Displays in the instrument panel

the information is grouped together in the
instrument panel screen.
5. Speed limiter on / pause indication.
6. Speed value setting.

the speed limiter cannot, in any
circumstances, replace the need to
observe speed limits, nor can it replace the
need for vigilance on the part of the driver.

If you choose to display other information
(trip A for example), the speed limiter
information is automatically displayed again
after about 6 seconds.

Driving

108_en_Chap04_conduite_ed01-2016

F Press the end of the control stalk: the

speed limiter is switched on.

F Accelerate or decelerate to attain the

desired speed.

F Push the control stalk down and release, to

programme the speed.

the speed at which the vehicle is running
at the moment when you release the
control stalk becomes the programmed
speed.

Adjusting the speed limit
setting

Once a speed is programmed, you can modify
it by pushing and releasing the control stalk:
-

up to increase the speed setting,

down to reduce the speed setting.

A brief push on the control stalk modifies the
speed setting by + or - 1 mph (km/h).
A maintained push on the control stalk modifies
the speed setting by + or - 5 mph (km/h).

Switching on

this indicator lamp comes on in the
instrument panel.

Pause

F You can temporarily stop the the speed

limiter by pulling the control stalk towards
you.

F Push the control stalk up to restore

operation of the speed limiter with the
same speed setting.

Driving

108_en_Chap04_conduite_ed01-2016

Switching off

F Press the end of the control stalk

the display of information related to the
speed limiter disappears.

operating fault

Illumination of this warning lamp in
the instrument panel indicates a fault
with the speed limiter.

the use of mats not approved by
PeugeOt may interfere with the
operation of the speed limiter.
to avoid any risk of jamming of the
pedals:
-

ensure that the mat is secured
correctly,

do not fit one mat on top of another.

temporarily exceeding the
programmed speed

F Press

firmly on the accelerator pedal,

going beyond the point of resistance, to
exceed the programmed speed limit.

the speed limiter is deactivated temporarily
and the displayed programmed speed flashes.

Have it checked by a PeugeOt dealer or a
qualified workshop.

An audible signal accompanies the
flashing of the programmed speed
when exceeding the speed is not due to
an action by the driver (steep hill...).

As soon as the vehicle's speed returns to the
programmed value, the limiter operates again:
the display of the programmed speed becomes
steady again.

Driving

108_en_Chap04_conduite_ed01-2016

Reversing camera

the reversing camera is activated automatically when reverse gear is engaged.

the reversing camera cannot in any
circumstances replace the need for the
vigilance on the part of the driver.

the image is provided in the touch screen
only, with an indication of the limit of the rear
bumpers (red line) and the general direction of
the vehicle (blue lines).

Clean the reversing camera regularly
using a soft, dry cloth.

the field of vision covered by the camera is
limited: objects in the immediate proximity of
the bumper or located below it are not visible.

the camera's wide-angle lens deforms the
image presented in the screen: the distances
visible in the screen may be different from
the true distances. this deformation varies
according to the loading of the vehicle and the
slope of the road.

High pressure jet washing
When washing your vehicle, do not
direct the lance within 30 cm of the
camera lens.

Never reverse the vehicle looking only
at the screen.

It is normal to be able to see part of the number
plate at the bottom of the screen.

Driving

108_en_Chap04_conduite_ed01-2016

Lane departure warning system

System which detects the unintended crossing of longitudinal traffic lane markings on the ground, using a camera that recognises both solid and
broken lines.
to improve your safety, the camera analyses the image and then triggers a warning if the vehicle wanders over a lane marking (speed higher than
30 mph (50 km/h)).
this system is particularly suitable for motorways and dual carriageways.

the lane departure warning system
cannot in any circumstances replace
the need for vigilance on the part of
the driver.
It is necessary to observe driving
regulations and take a break every
two hours.

Activation

F Press this button, located on the steering

wheel.

Detection

You are alerted by an audible signal and the
display of a warning lamp in the instrument panel.

No alert is given if the direction
indicators are on and for around
20 seconds after they stop flashing.

the system should be deactivated when
driving with snow chains or the spare
wheel fitted.

Driving

108_en_Chap04_conduite_ed01-2016

Deactivation

operating fault

Displays in the instrument panel

the detection may be impeded:
-

if the ground markings are worn,

if there is little contrast between the markings on the ground and the road surface,

if the windscreen is dirty,

in certain extreme weather conditions: fog, heavy showers, bright sunlight or direct
exposure to the sun (low sun, leaving a tunnel...) and shadows.

F Press this button again.

the status of the system remains in the
memory when the ignition is switched off.

In the event of a malfunction, this (orange)
warning lamp comes on in the instrument panel.

Contact a PeugeOt dealer or a qualified
workshop without delay.

Display in the instrument panel

Comments

the function has been activated (green indicator).

the system has identified a marking on the ground (green
indicator).

the system is alerting you that a road marking is being crossed
(green and orange warning).
the display of this warning is accompanied by an audible signal.

Peugeot 108 (2016 year). Instruction - part 6
