Peugeot 206 CC Dag (2006 year). Instruction

Visibility

01-01-2006

Automatic windscreen wipers

In the

AUTO position, the windscreen

wipers operate automatically and

adapt their speed to the intensity

of the rainfall.

Do not cover the rain

sensor located on the

windscreen behind the

interior mirror.

When using an automatic car

wash, switch off the ignition or

check that the wiper stalk is not in

the

AUTO position.

In winter, it is advisable to wait

for the windscreen to completely

clear of ice before operating the

automatic wipe.

Operating check
Activation

Activation of the function is

accompanied by a message on the

multi-function display.

In the event of malfunction, the

driver is informed by an audible

signal.

In the

AUTO position, the windscreen

wiper will operate in intermittent

mode.

Contact a PEUGEOT dealer to have

the system checked.

74 - Visibility

01-01-2006

Automatic operation

Pressing the switch triggers complete

opening or closing of the window,

pressing the switch again stops the

movement of the window.

A long press controls the movement

of the window which then stops if

you release the switch. A maintained

press or a second press triggers the

opening or closing of the rear quarter

panel window.

Notes: Only the front window on the

driver's side closes automatically

(engine running or vehicle moving),

when the rear quarter panel window

is closed.

The window switches do not function

while the roof is being operated.

ELECTRIC WINDOWS

1. Driver's electric window

switch.

2. Passenger's electric windows

switch.

Each switch controls, on its own side,

the front window and the rear quarter

panel window.

Always remove the key

from the ignition when

leaving the vehicle, even

for a short time.

If an obstacle is detected when

operating the electric windows,

you must reverse the movement

of the window. To do this, press

the control concerned.

When the driver operates the

passenger

electric

window

controls, he must ensure that no

one is preventing correct closing

of the windows.

The driver must ensure that

passengers use the electric

windows correctly.

Be aware of children when

operating the windows.

The battery must be disconnected

with the doors closed.

Manual operation

Press the switch (to open) or pull it

(to close) without going beyond the

point of resistance.

The window stops when the switch

is released.

The rear quarter panel window

can be opened only when the front

window is completely open, after an

inactive period of one second.

REINITIALISING THE

ELECTRIC WINDOWS

Following reconnection of the battery

or in the event of a malfunction,

release the switch and pull it again

until the window closes completely.

Continue to pull the switch for

approximately one second after

closing.

The safety auto-reverse function

does not operate during these

operations.

Visibility

01-01-2006

Manual interior mirror

The interior mirror has two positions:

- day (normal),

- night (anti-dazzle).

To change from one to the other,

push or pull the lever on the lower

edge of the mirror.

ELECTRIC EXTERIOR

MIRRORS

Turn knob

1 to the right or to the left

to select the corresponding mirror.

Move knob

1 in all four directions to

adjust.

The exterior mirror on the

driver's side is convex

in order to eliminate the

"blind spot".

Furthermore, objects observed

in the driver's and passenger's

mirrors are in reality closer than

they appear.

This must be taken into account

to judge correctly the distance

of vehicles approaching from

behind.

Fold-back electric mirrors

With the ignition on, turn knob

1 to

position

A .

76 - Layout

01-01-2006

COURTESY LIGHT

LIGHTER

Press and wait a few moments until it

springs out automatically.

It is supplied with power with the

ignition key in the accessories

position (1st notch).

In this position, it comes on

for about 30 seconds :

- on unlocking the vehicle,

- when opening a door,

- on switching off the ignition.

It ﬂashes while driving if a door is not

closed correctly.

Permanently off.

Permanently on when the

ignition key is in the acces-

sories position or the ignition

is on.

FRONT ASHTRAY

To empty, close the cover.

Pull the lug and release the ashtray

upwards.

SUN VISOR

The sun visors are ﬁtted with a vanity

mirror, with a concealing ﬂap on the

driver's side.

AREAS FOR TOLL CARDS /

CAR PARK TICKETS

The athermic windscreen has two

non-reﬂective zones located either

side of the base of the interior

mirror.

They are intended for afﬁxing toll

cards and/or car park tickets.

Layout

01-01-2006

GLOVE COMPARTMENT

The glove compartment is ﬁtted with

a lock.

To open the glove compartment, lift

the handle.

The light comes on when the lid is

opened.

1. Vehicle document folder storage

2. Can holder

3. Pen holder

4. Spectacles storage

5. Map storage

6. Coin storage

BOTTLE HOLDER

A bottle holder is ﬁtted between the

two rear seat backs.

To open it, pull the top of the cover.

LASHING RINGS

Use the 4 lashing rings on the

luggage compartment ﬂoor to secure

your luggage.

LUGGAGE RETAINING NET

Hooked onto the lashing rings, this

enables you to secure your luggage.

78 - Driving

01-01-2006

«PORSCHE TIPTRONIC

system» AUTOMATIC

GEARBOX

The four speed

automatic gearbox

offers a choice between the comfort

integral automatic operation,

enhanced by a

sport and a snow

programme,

manual

gear

changing.

Gear selection gate



Move the lever in the gate to

select a position.

The indicator light corresponding to

the position selected appears on the

instrument panel screen.

ark: to

immobilise the vehicle

and to

start the engine, with the

handbrake on or off.

everse: to

reverse (select this

position with the vehicle stationary,

engine at idle).

eutral: to

start the engine and to

park, with the handbrake on.
If position

N is inadvertently engaged

while driving, allow the engine

to return to idle before engaging

position

D to accelerate.

Drive: for driving in automatic

mode.

anual: for

selection

of gears.

S : sport programme.



: snow programme.

Moving Off

With the engine running, to move off

from position



it is essential to press the brake

pedal to exit position P,



select position R, D or M, then

gradually release the pressure

on the brake pedal; the vehicle

moves off immediately.

You can also move off from

position



release the handbrake, with your

foot on the brake,



select position

R, D or M, then

gradually release the pressure

on the brake pedal; the vehicle

moves off immediately.

WARNING

When the engine is at idle, brakes

not applied, if position

R, D or M

is selected, the vehicle moves

even without the accelerator being

pressed.

For this reason,

do not leave

children unsupervised inside the

vehicle, with the engine running.

When maintenance operations need

to be carried out with the engine

running, apply the handbrake and

select position

Starting the engine



with the handbrake on, select

position

P or N in the gate,



turn the ignition key to the

Start

position.

Driving

01-01-2006

Manual operation

Manual changing of the four gears :


select position

M in the gate,



push the lever to the

+ sign to

change to a higher gear,



pull the lever to the

- sign to

change to a lower gear.

You can change from position

(driving in automatic mode) to

position

M (driving in manual mode)

at any time.

If you take your foot off the

accelerator suddenly, the gearbox

will not change to a higher gear for

reasons of safety.

Automatic operation

Automatic changing of the four

gears:


select position

D in the gate.

The gearbox always selects the

most suitable gear according to the

following parameters:

- the road proﬁle,

- the vehicle load.

The gearbox is then operating in

auto-adaptive mode, without any

action on your part.

WARNING

Never select position

N when the

vehicle is moving.

Never select positions

P or R unless

the vehicle is stationary.

Never change between positions

to optimise braking on a slippery

surface.

Notes

For immediate maximum acceleration

without touching the gear lever, press

the accelerator pedal down as far as

it will go (kickdown). The gearbox

will automatically change down or

maintain the gear selected until

maximum engine speed is reached.

When the brake is applied, the

gearbox will automatically change

down in order to provide efﬁcient

engine braking.

Sport and snow programmes

In addition to the auto-adaptive

programme, there are two special

programmes.

The programme is displayed on the

instrument panel screen.

Sport programme



Press button S once the engine

has been started.

The gearbox automatically favours

sporty driving and more dynamic

acceleration.

Snow programme

This programme improves starting

and drive when traction is poor.


Press button



once the engine

has been started.

The gearbox adapts to driving on

slippery roads.

Note: you can return to the auto-

adaptive programme at any time.


Press button

S or



again to

switch off the programme you are

in.

Notes

It is only possible to change from

one gear to another if the vehicle

speed and engine speed permit. If

they do not, the vehicle will operate

temporarily in automatic mode.

When the vehicle is stationary or

moving very slowly, the gearbox

automatically selects gear

M1.

Programmes

S (sport) and



(snow)

do not operate in manual mode.

80 - Driving

01-01-2006

Operating abnormality

Any

operating

abnormality

indicated by an audible signal,

accompanied by the message

"Automatic gear fault" on the multi-

function display, by a

"-" and ﬂashing

of the Sport and Snow warning lights

on the instrument panel display.

In this situation the gearbox operates

in downgrade mode (locked in 3rd

gear). You may feel a substantial

knock when changing from

P to R

and from

N to R (this will not cause

any damage to the gearbox).

Do not exceed 60 mph (100 km/h),

respecting local speed limits.

Contact a PEUGEOT dealer as soon

as possible.

If the battery is ﬂat and the

lever is in position

, it will

be impossible to change

to another position.

In particular, do not force

the lever or there is a risk the

gearbox may be damaged.

HANDBRAKE

Applying

Pull the handbrake to immobilise

your vehicle.
Releasing

Pull on the handle and press the

button to release the handbrake.

Illumination of this warning

light and of the

STOP

warning light, accompanied

by an audible signal (while

the vehicle is being driven) and the

message

"handbrake on" on the

multifunction display, indicates that

the handbrake is still on or has not

been properly released.

When parking on a slope,

direct your wheels towards

the pavement and pull the

handbrake.

HORN

Press one of the spokes of

the steering wheel.

80 - Driving

01-01-2006

Operating abnormality

Any

operating

abnormality

indicated by an audible signal,

accompanied by the message

"Automatic gear fault" on the multi-

function display, by a

"-" and ﬂashing

of the Sport and Snow warning lights

on the instrument panel display.

In this situation the gearbox operates

in downgrade mode (locked in 3rd

gear). You may feel a substantial

knock when changing from

P to R

and from

N to R (this will not cause

any damage to the gearbox).

Do not exceed 60 mph (100 km/h),

respecting local speed limits.

Contact a PEUGEOT dealer as soon

as possible.

If the battery is ﬂat and the

lever is in position

, it will

be impossible to change

to another position.

In particular, do not force

the lever or there is a risk the

gearbox may be damaged.

HANDBRAKE

Applying

Pull the handbrake to immobilise

your vehicle.
Releasing

Pull on the handle and press the

button to release the handbrake.

Illumination of this warning

light and of the

STOP

warning light, accompanied

by an audible signal (while

the vehicle is being driven) and the

message

"handbrake on" on the

multifunction display, indicates that

the handbrake is still on or has not

been properly released.

When parking on a slope,

direct your wheels towards

the pavement and pull the

handbrake.

HORN

Press one of the spokes of

the steering wheel.

Safety

01-01-2006

ANTI-LOCK BRAKING

SYSTEM (ABS) AND THE

ELECTRONIC BRAKE FORCE

DISTRIBUTION (EBFD)

The ABS, in conjunction with the

electronic brake force distribution,

increases

the

stability

and

manoeuvrability of your vehicle on

braking, in particular on poor or

slippery road surfaces.

Note: when changing wheels (tyres

and rims), make sure that these are

approved.

The anti-lock braking system comes

into operation automatically when

there is a risk of wheel lock.

EMERGENCY BRAKING

ASSISTANCE SYSTEM

In an emergency, this system enables

the optimum braking pressure to be

reached more quickly, thus reducing

the stopping distance.

It is triggered by the speed at which

the brake pedal is activated. The

effect of this is a reduction in the

resistance of the pedal and an

increase in braking efﬁciency.

In the event of emergency braking,

depending on the force of the

deceleration, the hazard warning

lights are switched on automatically.

They are switched off automatically

on acceleration.

When this warning light

comes on, accompanied by

a buzzer and a message,

it indicates that there is a

malfunction of the ABS, which can

cause a loss of control of the vehicle

when braking.

When this warning light

comes on, connected to

the

STOP

warning light,

accompanied by a buzzer

and a message, it indicates that there

is a malfunction of the electronic

brake force distribution, which can

cause a loss of control of the vehicle

when braking.

Stop immediately.

In both cases, consult a Peugeot

dealer.

Normal operation of the ABS may

make itself felt by slight vibrations

of the brake pedal.

In emergency braking, press

very ﬁrmly without releasing the

pressure.

Automatic lighting of hazard

warning lights*

When braking in an emergency,

depending on the deceleration,

the hazard warning lights come

on automatically. They switch off

automatically the ﬁrst time you

accelerate.

It is also possible to switch them off

by pressing the button.

HAZARD WARNING LIGHTS

Press the button, the direction

indicators ﬂash.

They can operate with the ignition

off.

* According to country.

82 - Safety

01-01-2006

Operating check

TRACTION CONTROL (ASR)

AND DYNAMIC STABILITY

CONTROL (ESP)

These systems are linked and

complement the ABS.

The ASR system optimises drive

to prevent the wheels skidding, by

acting on the brakes of the drive

wheels and on the engine. It also

allows the directional stability of

the vehicle to be improved on

acceleration.

If there is a variation between the

trajectory followed by the vehicle and

that required by the driver, the ESP

system automatically acts on the

engine and the brake of one or more

wheels, in order to put the vehicle

back on course, within the limits of

the laws of physics.

The warning light ﬂashes if

the ASR or ESP is activated.

The switch lights up and

the warning light comes on,

accompanied by a message

on the multifunction display :

the ASR and ESP systems are

disarmed.

Operation of the ASR and ESP

systems

Disarming the ASR/ESP systems

In exceptional conditions (starting a

vehicle which is bogged down, stuck

in snow, on soft ground), it may be

advisable to disarm the ASR and

ESP systems, so that the wheels can

move freely and regain grip.


Press the

"ESP OFF" switch,

located under the steering wheel

to the left.

These are triggered again:


automatically if the ignition is

switched off,



manually by pressing the switch

again.

When a malfunction of the

systems occurs, the switch

light ﬂashes and the warning

light comes on.

Contact a PEUGEOT dealer to have

the systems checked.

The ASR/ESP systems

offer exceptional safety

in normal driving, but this

should not encourage the

driver to take extra risks or drive at

high speed.

The

correct

functioning

these systems depends on

observation of the manufacturer's

recommendations

regarding

wheels (tyres and rims), the

braking components and the

electronic

components

and

the PEUGEOT assembly and

operation procedures.

After an impact, have these

systems checked by a PEUGEOT

dealer.

Safety

01-01-2006

FRONT AIR BAGS

These are folded in the centre of the

steering wheel for the driver and in

the fascia for the front passenger.

They are deployed simultaneously,

except in cases where the air bag is

disarmed.

AIR BAGS

The air bags have been designed to

maximise the safety of the occupants

in the event of serious collisions; they

work in conjunction with the force

limiting seat belts.

In the event of a serious collision,

the electronic detectors record and

analyse any abrupt deceleration of

the vehicle: if the triggering threshold

is reached, the air bags inﬂate

instantly and protect the occupants

of the vehicle.

Immediately after the impact, the

air bags deﬂate rapidly, so that they

do not hinder the visibility of the

occupants nor their possible exit

from the vehicle.

The air bags will not be deployed in

collisions which are not serious, for

which the seat belt is sufﬁcient to

provide maximum protection. The

seriousness of the collision depends

on the nature of the obstacle and the

speed of the vehicle at the moment

of impact.

Air bags only operate when the

ignition is switched on.

Note: the gas escaping from the air

bags can be a minor irritant.

If this warning light comes

on, accompanied by a

buzzer and a message on

the multifunction display,

contact a PEUGEOT dealer to have

the system checked.

Front air bag malfunction

Disarming the passenger

air bag*

To ensure the safety of your child, it

is essential to disarm the passenger

air bag when you install a rear-facing

child seat on the front passenger

seat. Otherwise, the child would risk

being killed or seriously injured if the

air bag were to inﬂate.


With the ignition switched off,

insert the key into the passenger

air bag disarming switch

1, turn

it to the

"OFF" position, then

remove the key keeping the slot

in this position.

The air bag warning light

on the instrument panel is

lit throughout the period of

disarming.

* According to country.

84 - Safety

01-01-2006

In the

"OFF" position, the passenger

air bag will not be triggered in the

event of an impact.

As soon as the child seat is removed,

turn the air bag slot to the

"ON"

position to re-activate the air bag

and thus ensure the safety of your

passenger in the event of an impact.

SIDE AIRBAGS *

These are incorporated into the

frame of the front seat back, on the

door side.

They are deployed independently

of each other depending on which

side the collision occurs, in collisions

which could cause injury to the chest,

the abdomen or the head.

This is conﬁrmed by an indicator light

on the instrument panel.

It comes on for six seconds, each

time the ignition is switched on.

With the ignition on (2nd

notch), illumination of this

warning light accompanied

by a message on the

multifunction display, indicates that

the passenger air bag is disarmed

(switch in the

"OFF" position).

If the two air bag warning

lights are lit continuously,

do not install a rear-facing

child seat. Contact a

PEUGEOT dealer.

Operating check

* According to destination.

If the indicator light:

- does not light up when the ignition

is switched on, or

- does not go out after six seconds,

- ﬂashes for ﬁve minutes then stays

on,

contact a PEUGEOT dealer.

Disarming check

This is conﬁrmed by an indicator

light, accompanied by a message on

the multifunction display.

Safety

01-01-2006

For the front and side*

air bags to be fully

effective, observe the

following safety rules:

• Wear a correctly adjusted seat

belt.

• Sit in a normal upright position.

• Do not leave anything between

the occupants and the air bags

(child, animal, object...).

This could hamper the operation

of the air bags or injure the

occupants.

• All work on the air bag systems

is strictly prohibited unless it is

carried out by qualiﬁed personnel

of the PEUGEOT network.

• After an accident or if the vehicle

has been stolen or broken

into, have the air bag systems

checked.

Front air bags

• Do not drive holding the steering

wheel by its spokes or resting

your hands on the centre part of

the wheel.

• Passengers must not place their

feet on the fascia.

• Smoke as little as possible;

deployment of the air bags can

cause burns or the risk of injury

from a cigarette or pipe.

• Never remove or pierce the

steering wheel or hit it violently.

Side air bags*

• Only put approved covers on

the front seats. Contact your

PEUGEOT dealer.

• Do not ﬁx or glue anything to

the front seat backs. This could

cause injury to the chest or arms

when the side air bag inﬂates.

• Do not sit with the upper part of

the body any nearer to the door

than necessary.

* According to country.

84 - Safety

01-01-2006

In the

"OFF" position, the passenger

air bag will not be triggered in the

event of an impact.

As soon as the child seat is removed,

turn the air bag slot to the

"ON"

position to re-activate the air bag

and thus ensure the safety of your

passenger in the event of an impact.

SIDE AIRBAGS *

These are incorporated into the

frame of the front seat back, on the

door side.

They are deployed independently

of each other depending on which

side the collision occurs, in collisions

which could cause injury to the chest,

the abdomen or the head.

This is conﬁrmed by an indicator light

on the instrument panel.

It comes on for six seconds, each

time the ignition is switched on.

With the ignition on (2nd

notch), illumination of this

warning light accompanied

by a message on the

multifunction display, indicates that

the passenger air bag is disarmed

(switch in the

"OFF" position).

If the two air bag warning

lights are lit continuously,

do not install a rear-facing

child seat. Contact a

PEUGEOT dealer.

Operating check

* According to destination.

If the indicator light:

- does not light up when the ignition

is switched on, or

- does not go out after six seconds,

- ﬂashes for ﬁve minutes then stays

on,

contact a PEUGEOT dealer.

Disarming check

This is conﬁrmed by an indicator

light, accompanied by a message on

the multifunction display.

Safety

01-01-2006

For the front and side*

air bags to be fully

effective, observe the

following safety rules:

• Wear a correctly adjusted seat

belt.

• Sit in a normal upright position.

• Do not leave anything between

the occupants and the air bags

(child, animal, object...).

This could hamper the operation

of the air bags or injure the

occupants.

• All work on the air bag systems

is strictly prohibited unless it is

carried out by qualiﬁed personnel

of the PEUGEOT network.

• After an accident or if the vehicle

has been stolen or broken

into, have the air bag systems

checked.

Front air bags

• Do not drive holding the steering

wheel by its spokes or resting

your hands on the centre part of

the wheel.

• Passengers must not place their

feet on the fascia.

• Smoke as little as possible;

deployment of the air bags can

cause burns or the risk of injury

from a cigarette or pipe.

• Never remove or pierce the

steering wheel or hit it violently.

Side air bags*

• Only put approved covers on

the front seats. Contact your

PEUGEOT dealer.

• Do not ﬁx or glue anything to

the front seat backs. This could

cause injury to the chest or arms

when the side air bag inﬂates.

• Do not sit with the upper part of

the body any nearer to the door

than necessary.

* According to country.

Peugeot 206 CC Dag (2006 year). Instruction - part 6
