2A – 34 POWER STEERING REASSEMBLY 28. Rear Housing 27. Pin 26. Cam 25. Rotor and Vane Install the rotor with its punch mark facing the front Install the vane with curved face in contact with the 24. Pressure Plate CAUTION: 23. Front Housing 22. O-ring Be sure to discard used parts, and always used new 21. O-ring Be sure to discard used parts, and always used new 20. Gasket Be sure to discard used parts, and always used new 19. Rear Housing Assemble and Pump Cartridge 18. Bolt Rear Housing Bolt Torque N·m (kg·m/lb·ft) 54 (5.5 / 40) 17. O-ring Be sure to discard used parts, and always used new |
