8D–218

WIRING SYSTEM

2

Stoplight On The Left (Or Right) Side Inoperative

(Body Build-in Type Stoplight)

(Bumper Build-in Type Stoplight)

•

WITH THE STOPLIGHT SW OR BRAKE SW DEPRESSED, IS THE
BATTERY VOLTAGE APPLIED BETWEEN 5    R-13    (OR 5    R-12   )
AND THE GROUND?

YES

REPAIR A POOR CONNECTION AT THE CONNECTORS
OR AN OPEN CIRCUIT BETWEEN 7    H-32    AND
5    R-13    (OR 5    R-12    )

NO

•

IS THE STOPLIGHT BULB ON THE LEFT (OR RIGHT) SIDE NORMAL?

REPLACE THE BULB

YES

NO

REPAIR A POOR CONNECTION AT THE CONNECTORS OR AN
OPEN CIRCUIT BETWEEN 1   R-13    (1    R-12   )  AND     R-4

•

WITH THE STOPLIGHT SW OR BRAKE SW DEPRESSED, IS THE
BATTERY VOLTAGE APPLIED BETWEEN 3    F-7    (OR 3    F-8    )
AND THE GROUND?

YES

REPAIR A POOR CONNECTION AT THE CONNECTORS
OR AN OPEN CIRCUIT BETWEEN 7   H-32    AND
3    F-7    (OR 3   F-8    )

NO

•

IS THE STOPLIGHT BULB ON THE LEFT (OR RIGHT) SIDE NORMAL?

REPLACE THE BULB

YES

NO

REPAIR A POOR CONNECTION AT THE CONNECTORS OR AN
OPEN CIRCUIT BETWEEN 2   F-7    (2    F-8   )  AND     R-4

WIRING SYSTEM

8D–219

3

High Mounted Stoplight Inoperative

•

•

REPAIR A POOR CONNECTION AT THE CONNECTORS OR AN
OPEN CIRCUIT BETWEEN 2    G-9    AND    R-3

ROMOVE THE HIGH MOUNTED STOPLIGHT CONNECTOR
IS THERE ANY CONTINUITY BETWEEN THE HIGH MOUNTED
STOPLIGHT CONNECTOR 1   G-9      AND 2   G-9    ?

YES

NO

GROUND IT SECURELY

YES

NO

REPAIR OR REPLACE THE HIGH MOUNTED
STOPLIGHT

•

YES

NO

REPAIR A POOR CONNECTION AT THE CONNECTORS
OR AN OPEN CIRCUIT BETWEEN 1     G-9     AND
1    H-37

•

IS     R-3     SECURELY GROUNDED?

IS THE BATTERY VOLTAGE APPLIED BETWEEN 1    G-9
AND THE GROUND WHEN THE BRAKE PEDAL IS
DEPRESSED?

8D–220

WIRING SYSTEM

Backup Light

General Description

The circuit consists of backup light switch (M/T),
mode switch (A/T) and backup light.
When shfit lever is set to “R” position, backup light
switch (M/T) or mode switch (A/T) is activated to
illuminate backup light.

WIRING SYSTEM

8D–221

Circuit Diagram (RHD)

3.0

B/Y

STARTER SW

(IG1)

MODE
SW
(A/T)

HAZARD

WARNING

SWITCH (8)

0.5

R/B

0.5

R/B

0.5

R/B

0.85

R/B

0.5

R/L

0.75

R/L

0.75

R/L

C-3 10A
TURN,BACK

H-25

17

H-7

17

M-25

M-25

8

H-11

7

R-4

3

A

BACKUP
LIGHT SW
(6VD1 M/T)

BACKUP
LIGHT
-LH

BACKUP
LIGHT
-RH

0.85

R/B

0.75

R/B

0.5

R/L

H-11

1

6

M-8

M-9

1

0.85

R/L

H-5

5

BACKUP
LIGHT SW
(4JG2)

0.5

R/B

0.85

R/B

0.5

R/L

H-5

E-43

1

6

E-42

1

0.5

R/L

0.85

R/L

0.5

R/L

1.25

B

1.25

B

0.5

R/L

H-32

8

H-7

16

A

BODY-RR

R-13

3

R-13

1

R-12

3

1

R-12

0.75

R/B

H-11

6

H-11

7

D08RWC64
