6A – 18 ENGINE MECHANICAL

Engine Electricals

N·m (kg·m/lb·ft)

060R200263

15(1.5/11)

94(9.6/69)

40(4.1/29.7)

24(2.4/17.4)

19(19/13.7)

ENGINE MECHANICAL 6A – 19

Injector

N·m (kg·m/lb·ft)

E06R200022

With
spacer type

Without
spacer type

20N·m(2.0kg·m/14 Ib ft)

7N·m(0.7kg·m/61 Ib in)

Recheck tightening torque
after tighten the oil rail

Apply engine oil on the
thread of stud bolts

20N·m(2.0kg·m/14 Ib ft)

Tighten 30N·m(3.1kg·m/22 Ib ft)
Then loosen it again tighten with
24N·m(2.4kg·m/17 Ib ft)

Apply engine oil
both side

6A – 20 ENGINE MECHANICAL

High Pressure Oil Pipe

N·m (kg·m/lb·ft)

80(8.1/57.9)

052R200002

ENGINE MECHANICAL 6A – 21

Air Duct and Intercooler (For General Export)

N·m (kg·m/lb·ft)

3.0(0.3/2.2)

4.0(0.4/3)

20(2.0/14.5)

4.0(0.4/3)

20(2.0/14.5)

135R200002
