4JG2-NA/4JG2-TURBO ENGINE 6A 2– 29 23. Rocker Arm Shaft Assembly • Loosen all adjusting screws. • Align fixing bolts to not of rocker arm shaft and • Valve clearance adjustment. • Refer to valve clearance adjustment steps in 22. Fuel Leak Off Pipe • Install fuel leak off pipe with new copper gasket 54 (5.5/40) N·m (kg·m/lb·ft) 21. Injection Pipe • Install injection pipes and sleeve nuts securely and 29 (3.0/22) N·m (kg·m/lb·ft) 29 (3.0/22) N·m (kg·m/lb·ft) 20. Glow Plug Harness • Apply engine oil to the rocker arms and the valve • Install the cylinder head cover gasket to the • Tighten the cylinder head cover nuts to the 18. Fuel Leak Off Hose • Install front exhaust pipe and tighten fixing bolts to 13 (1.3/113) N·m (kg·m/lb·in) 19 (1.9/14) N·m (kg·m/lb·ft) 16. Exh. Manifold W/turbo (4JG2-T Only) • Install manifold gasket in cylinder head. • Insert exh. manifold into studs on cylinder head a • Under this condition, insert oil return pipe frange • Tighten exh. manifold fixing bolts and nut to 26 (2.7/20) N·m (kg·m/lb·ft) 15. Oil Cooler Hose • Tighten joint bolt to the specified torque. 8 (0.8/69) N·m (kg·m/lb·in) |
