SEATS 8G–23 Reassembly (Bench Type) To reassemble, follow the disassembly steps in the 1. Tighten the reclining device fixing bolts to the specified torque. Torque: 27 N·m (2.8kg·m/20 lb ft) 2. Loosen the rubber stopper lock nut(1) and adjust the stopper rubber(3) so there is no clearance between 755RS005 Third Seat Assembly Parts Location 755RW034 Legend (1) Cover (2) Rear Side of LH Removal 1. Disconnect the battery ground cable. 2. Remove the cover. |
