8C–6

ENTERTAINMENT

Antenna Rod

Removal

1. Disconnect the battery ground cable.
2. Remove the antenna nut(1).
3. Until the lower part of the antenna rod(4) is removed

from the bezel part, rotate the antenna motor in an
ascending way, and expand the rod.

4. Turn the antenna top(2) counterclockwise.
5. Remove the contact sleeve(3).
6. Remove the antenna rod(4).

890RW076

Installation

To install, follow the removal steps in the reverse order,
nothing the following points.

1. Rotate the antenna motor in a descend way, and push

in vertically until the antenna rod is in the complete
state of storage.

2. After ending the installation, confirm that the antenna

rod works correctly.

ENTERTAINMENT

8C–7

Radio

Removal

1. Disconnect the battery ground cable.
2. Remove the front console assembly (1).

Refer to the Instrument Panel Assembly in Body
Structure section.

3. Remove the lower cluster assembly (2).

Refer to the Instrument Panel Assembly in  Body
Structure section.

4. Remove the instrument panel driver lower cover

assembly (3).
Refer to the Instrument Panel Assembly in Body
Structure section.

821RW024

5. Remove the instrument panel cluster assembly(4).

Refer to the Instrument Panel Assembly in Body
Structure section.

6. Remove two screws and disconnect the radio

connector(5) and antenna feeder plug(6) to remove
the radio(7).

825RW039

Installation

To install, follow the removal steps in the reverse order.

8C–8

ENTERTAINMENT

Front Speaker

Removal

1. Disconnect the battery ground cable.
2. Pull the grille(1) to release the locks and then remove

it.

3. Remove four screws and disconnect the

connector(3) to remove the speaker(2).

890RW013

Installation

To install, follow the removal steps in the reverse order.

ENTERTAINMENT

8C–9

Rear Speaker

Removal

1. Disconnect the battery ground cable.
2. Pull the grille(1) to release the locks and then remove

it.

3. Remove four screws and disconnect the

connector(3) to remove the speaker(2).

890RW015

Installation

To install, follow the removal steps in the reverse order.
