MUA MODEL  7B1 – 59

Exhaust Pipe

1. Connect the front exhaust pipe and 2nd-3rd exhaust

pipe.

2. Install the exhaust pipe bracket to the transmission

case.

220LV018

Transfer Case Protector (Except 00 Year or Subsequent
ones)

1. Install the transfer case protector 1 to the mounting

member 2 and the sidemebers 3.

2. Tighten the transfer case protector bolts to the

specified torque.

Transfer Case Protector Bolt Torque

kg·m (lb·ft/N·m)

3.7 ± 1.0 (26.8 ± 7.2/36.3 ± 9.8)

Gear Shift Lever and Transfer Change Lever

1. Replenish the transmission case and the transfer

case with the specified engine oil.

Transmission and Transfer Case Oil

lit (US/UK qt.)

Transmission Case

2.95 (3.12/2.6)

Transfer Case

1.45 (1.53/1.28)

2. Install the gear shift lever to the gear control box.

Shift Lever Cover Bolt Torque

kg·m (lb·ft/N·m)

2.0 ± 0.2 (14.5 ± 1.5/19.6 ± 1.96)

3. Install the dust cover.

4. Insert the transfer change lever to the transfer case.

Change Lever Retainer Bolt Torque

kg·m (lb·ft/N·m)

2.0 ± 0.2 (14.5 ± 1.5/19.6 ± 1.96)

5. Install the grommet.

6. Install the front console assembly and center console

assembly.

7. Install the gear shift lever and the transfer change

lever knobs.

235RT004
