7A–38 AUTOMATIC TRANSMISSION (4L30–E) 17. Install harness protector. 815RW002 18. Install the front propeller shaft, and tighten the bolts to the specified torque. Torque: 63 N • m (6.4 kg·m/46 lb ft) 19. Install the rear propeller shaft, and tighten the bolts to the specified torque. Torque: 63 N • m (6.4 kg·m/46 lb ft) 20. Install the transfer and exhaust protectors, and tighten the bolts to the specified torque. Torque: 37 N • m (3.8 kg·m/27 lb ft) 21. Install the transfer control lever. assembly. 24. Connect the wiring harness connectors. assembly. Refer to Selector Lever in this section. 26. Connect the wiring harness connectors to front console. 27. Install the front console. |
