6E–102 4JX1–TC ENGINE DRIVEABILITY AND EMISSIONS DTC P0202 – Injector # 2 Circuit Fault
Step Action Value(s) Yes No 1 Was the “On-Board Diagnostic (OBD) System Check” — Go to Step 2 Go to OBD System Check 2 Will the engine start? — Go to Step 3 Go to Engine Cranks But Will Not Run chart 3 1. Install the Tech 2. Clear the DTC. Does DTC P0202 reset? — Go to Step 5 Go to Step 4 4 1. Review the Freeze Frame data with the ignition “ON” and the engine “OFF” and note the 2. Operate the vehicle within the Freeze Frame conditions as noted. Does P0202 reset? — Go to Step 5 — 5 Check the Injector test. Does the working noise confirm? — Go to Step 6 Go to Step 7 6 1. Install the Tech 2. Clear the DTC. Dose DTC P0202 reset? — Verify repair Go to Step 7 7 Check for an open circuit between the injector Was there an open circuit? — Go to Step 8 Go to Step 9 8 Repair the open circuit. Is the action complete? — Verify repair — 9 Replace the ECM (Refer to the Data Programming in Is the action complete? — Verify repair Go to Step 10 10 Replace the Injector (Refer to the Injector Group Sign Is the action complete? — Verify repair — |
