6A–30 ENGINE MECHANICAL Installation NOTE: For correct belt installation, the letter on the belt 014RY00042 Legend (1) Crankshaft Timing Pulley 014RY00043 Legend (7) Alignment Mark on Oil Pump. Pulley. (10) Alignment Mark (groove) on Crankshaft Timing Pulley. 014RW006 Legend (1) Timing Belt 1. Install timing belt. 1. Align the mark (notch) of crankshaft timing pulley (2) with mark on oil pump (1). NOTE: When timing marks are aligned, No.2 piston will 014RW003 Legend (1) Alignment Mark on Oil Pump |
