STEERING LINKAGE 2A – 49 RELAY LEVER 2 2 3 6 5 4 1 hese steps are based on the LHD model. Removal Steps 1. Nut and cotter pin 2. Bolt and nut 3. Relay lever and Bracket 4. Nut and washer 5. Relay lever 6. Bracket Installation Steps 6. Bracket 5. Relay lever 4. Nut and washer 3. Relay lever and bracket 2. Bolt and nut 1. Nut and cotter pin REMOVAL Preparation: 1. Nut and Cotter pin Disconnect relay lever at the center track rod. Remover: 5-8840-2121-0 (J-36831) 433RW005 These steps are based on the LHD model. |
