8D–366

WIRING SYSTEM

Power Door Mirror

General Description

The circuit consists of door mirror control switch,
folding switch, defogger switch and door mirrors on
both sides.
When control switch is operated with starter switch at
either “ACC” or “ON” position, motors incorporated
in door mirrors on both sides rotates to allow the
horizontal and vertical adjustment of mirror angle.
Folding switch can be used to fold mirror and return
it to its original position.
When turning on door mirror defogger switch with
starter switch at “ON” position, built–in heater in
mirror is activated to perform defogger function.

WIRING SYSTEM

8D–367

Circuit Diagram (RHD)-1

D08RW652

4

B-55

3.0

L/B

0.5

O/G

0.5

O/G

C-11 10A

AUDIO(ACC), MIRROR

STARTER SW

(ACC)

A

0.85

G/R

TAIL RELAY

(4)

2

B-55

0.5

B/G

0.5

B/G

H-18

B

8

B-55

10

0.5

W/B

0.5

W/B

H-18

C

6

B-55

8

LV

LH

RH

RV

0.5

B/L

0.5

B/L

H-22

D

8

B-55

5

0.5

W/G

0.5

W/G

H-22

E

6

B-55

7

0.5

B/W

0.5

B/W

H-18

F

18

0.5

B/W

0.5

B/W

0.5

B/W

H-22

G

H

18

B-55

19

2.0

B

0.5

B

0.3

R/G

0.5

B

BODY-LH

B-55

3

ILLUMINATION

CONTROLLER (3)

MIRROR CONTROL SW

B-55

B-2

2.0

B

BODY-CTR

B-26

2.0

B

BODY-RH

B-18

8D–368

WIRING SYSTEM

Circuit Diagram (RHD)-2

D08RW646

0.5

B/G

B

0.5

W/B

0.5

B/W

4

6

D-12

C

F

M

M

MIRROR

-LH

RIGHT

LEFT

DOWN

UP

D-12

0.5

B/L

D

0.5

W/G

0.5

B/W

4

6

D-3

E

G

M

M

MIRROR

-RH

RIGHT

LEFT

DOWN

UP

D-3

5

D-12

5

D-3

WIRING SYSTEM

8D–369

Circuit Diagram (RHD)-3

D08RY00232

A

B-56

6

B-56

5

B-56

8

B-56

7

B-56

4

H-18

17

H-18

16

CLOSE

OPEN

0.5

O/G

0.5

B

H

0.5

B

2.0

B

0.5

GR/L

0.5

GR/L

0.5

GR/L

0.5

GR/G

0.5

B

D-12

2

D-12

7

M

MIRROR-LH

H-22

17

H-22

16

0.5

GR/L

0.5

GR/G

0.5

GR/L

0.5

GR/G

D-3

2

D-3

7

M

MIRROR-RH

MIRROR DEFOGGER SW

MIRROR

DEFOGGER

-LH

MIRROR

FOLDING SW

3.0

B/Y

0.5

L/W

0.5

L/W

C-4  15A

ELEC. IGN.

STARTER SW

(IG1)

8

H-18

B-1

2.0

B

0.5

B

0.5

B

0.5

P/W

0.5

P/W

D-12

5

B-57

B-57

7

H-18

5

D-12

3

B-57

4

MIRROR

DEFOGGER

-RH

8

H-22

B-18

BODY-LH

BODY-RH

1.25

B

0.5

B

0.5

B

0.5

P/W

0.5

P/W

0.5

B

D-3

7

H-22

5

D-3

3

I

3

I
