6  Rear Washer Motor Does Not Operate

•

IS FUSE C-6 (10A) NORMAL?

YES

•

•

DISCONNECT THE CONNECTOR OF THE REAR WIPER &
WASHER SWITCH
WITH THE SWITCH SET AT “WASH” POSITION, IS THERE
CONTINUITY BETWEEN THE SWITCH CONNECTOR TERMI-
NALS  7   I-16   AND 6   I-16    ?

REPLACE THE FUSE

NO

YES

NO

•

•

TURN THE STARTER SWITCH ON
IS THE BATTERY VOLTAGE APPLIED BETWEEN THE REAR
WIPER & WASHER SWITCH HARNESS SIDE CONNECTOR
7   I-16   AND GROUND?

REPAIR A POOR CONNECTION AT THE CONNECTORS
OR AN OPEN CIRCUIT BETWEEN THE FUSE C-6 (10A)
AND 7   I-16

YES

NO

REPAIR OR REPLACE THE SWITCH

•

•

•

DISCONNECT THE CONNECTOR OF THE REAR WASHER MOTOR
TURN THE STARTER SWITCH ON
WITH THE REAR WIPER & WASHER SWITCH SET AT “WASH”
POSITION, IS THE BATTERY VOLTAGE APPLIED BETWEEN
THE REAR WASHER MOTOR HARNESS SIDE CONNECTOR
1   G-2   AND GROUND?

REPAIR A POOR CONNECTION AT THE CONNECTORS
OR AN OPEN CIRCUIT BETWEEN 1   G-2   AND 6   I-16

YES

NO

YES

•

IS   R-3   GROUNDED SECURELY?

NO

GROUND IT SECURELY

YES

REPAIR A POOR CONNECTION AT THE CONNECTORS OR AN
OPEN CIRCUIT BETWEEN 2   G-2   AND   R-3

•

•

CONNECT THE MOTOR SIDE CONNECTOR TERMINAL 1   G-2   TO
THE BATTERY (+) TERMINAL AND 2   G-2   TO THE (–) TERMINAL
DOES THE MOTOR OPERATE?

NO

REPLACE THE REAR WASHER MOTOR

WIRING SYSTEM

8D–331

Headlight Wiper/Washer

General Description

The circuit consists of the starter switch, headlight
wiper switch, headlight wiper motor and washer
motor. By pushing the headlight wiper/washer switch
with the starter switch on, the wiper will make 5
strokes with washer solution applied between each
of the first 4 strokes, regardless of the length of time
the switch is held down.
The washer nozzle is installed to the wiper blade, and
the tank to which the washer motor is installed shared
between the headlight washer and the windshield
washer.

8D–332

WIRING SYSTEM

Circuit Diagram (RHD) – 1

D08RY00228

M

C-23

6

342

5

5

12

C-23

0.5

R/B

0.5

R

0.5

R/Y

0.5

R/Y

0.5

R

0.5

R

0.5

R

0.5

R

0.5

L/W

0.5

L/W

3.0

B/Y

C-4 15A

ELEC,IG

C-7 10A

H/LAMP

WIPER

STATER SW

(IG1)

STATER SW

(IG2)

0.5

B

0.5

L/R

342

0.5

O/W

0.5

B

2.0

B

2.0

B

2.0

B

0.85

B

0.5

R/G

0.5

R/G

0.5

R

0.5

L/W

B-2

BODY

-LH

BODY

-RH

BODY

-CTR

B-26

B-18

A

C-23

H-7

B-6

C-23

C

C-23

1

B-6

9

B-7

10

B-7

M

M

C-30

6

15

2

C-30

H-7

D

C-30

C-36

10

H-41

E

B

C-30

F

15

H-15

1

C-36

ALARM&RELAY

CONTROL UNIT

ALARM&RELAY

CONTROL UNIT

H/LIGHT

WASHER

MOTOR

HEADLIGHT

WIPER

MOTOR-LH

HEADLIGHT

WIPER

MOTOR-RH

WIRING SYSTEM

8D–333

Circuit Diagram (RHD) – 2

D08RW932

1.25

B

0.5

B

0.5

B

0.5

B

0.3

R/G

ILLUMINATION

CONTROLLER

(3)

HEAD LIGHT

WIPER SW

TAIL RELAY

(4)

0.5

R/B

0.5

R/B

BODY-RH

B-19

FENDER-LH

6

I-4

2

I-4

20

H-9

A

7

I-4

0.85

G/R

3

I-4

5

H-26

4

C-16

0.5

L/R

0.5

L/R

11

H-24

B

8

I-4

0.5

O/W

1

H-9

D

5

I-4

0.5

L/W

0.5

O/W

0.5

L/W

6

H-9

E

0.5

B

C

0.5

B

F

4

I-4
