MUA MODEL  7B1 – 53

Front Propeller Shaft

Remove the splined yoke flange bolt at the transfer case
side.

Do not allow the splined yoke to fall away from the front
propeller shaft.

If the splined yoke should fall away from the front
propeller shaft, align the setting marks 3 on the splined
yoke  1 and the propeller shaft 2 to reassemble the two
parts.

The setting marks 3 are punched circles approximately 3
mm (0.12 in) in diameter.

TDC Sensor (4JA1TC Model)

Disconnect the TDC sensor from the transmission
housing.

Harness Connector

Disconnect the 4WD switch connectors, back up light
switch connector and the speedometer sensor connector.

220R200001

Slave Cylinder

Remove the slave cylinder from the transmission case.

220LV019

Engine LIfting Hanger

1. Attach the engine lifting hanger to the front portion of

the engine.

2. Attach the lifting wire to both ends of the engine

lifting hange.
