7A–206
AUTOMATIC TRANSMISSION (AW30-40LE)
249RW003
249RY00008
240RY00005
5. Elbow
Coat new O–rings with ATF, install them to the two elbows.
Install the elbows as shown in the figure.
6. Neutral start switch
Using the control shift lever, fully turn the manual lever shaft
back and return two notches. It is now in neutral.
Insert the neutral start switch onto the manual valve shaft
and temporarily tighten the adjusting bolt.
Install the lock washer and install and torque the nut.
Align the neutral standard line and the switch groove and
tighten the adjusting bolt.
Bend the tabs of the lock washer.
NOTE:
Bend at least two of the lock washer tabs.
7. Control rod and shift lever
Install control shift lever.
11. Torque converter
Using calipers and a straight edge, measure from the
installed surface of the transmission housing.
N·m (kg·m/lb·ft)
Torque
29 (3.0/22)
N·m (kg·m/lb·in)
Torque
7 (0.7/61)
N·m (kg·m/lb·in)
Torque
13 (1.3/113)
N·m (kg·m/lb·ft)
Torque
29 (3.0/22)
mm (in.)
Correct distance
67(2.64) or more
