7A–122 AUTOMATIC TRANSMISSION (AW30-40LE) 252RY00034 252RY00023 252RY00022 252RY00035 5. Race Coat the race with petroleum jelly and install it to the 6. Ring gear flange Install ring gear flange to OD planetary ring gear. 7. Snap ring Install snap ring, using a screwdriver. 8. Thrust bearing Coat the race and bearing with petroleum jelly and install Race diameter (Reference) mm (in.) Inside diameter 27.3 (1.075) Outside diameter 41.8 (1.646) Race and bearing diameter (Reference) mm (in.) Inside Outside Race 24.2 (0.953) 47.8 (1.882) Bearing 26.0 (1.024) 46.8 (1.843) |
