7A–42 AUTOMATIC TRANSMISSION (4L30–E) 8. Connect wiring harness to band control and shift solenoids. 9. Install roller and spring assembly to manual detent. D Install two 13 mm screws, and tighten them to the Torque: 20 N • m (2.0 kg·m/15 lb ft) 10. Install oil filter and three 13 mm screws. Tighten the screws to the specified torque. Torque : 20 N • m (2.0 kg·m/15 lb ft) 11. Install oil pan gasket, magnet, oil pan and sixteen 10 mm screws. Tighten the screws to the specified Torque: 11 N • m (1.1 kg·m/96 lb in) 12. Install third crossmember and rear mount. Tighten the bolts and nuts to the specified torque. Torque Third crossmember bolt: • m (7.8 kg·m/56 lb ft) Rear mount nut: 50 N • m (5.1 kg·m/37 lb ft) 13. Install exhaust pipe and connect oxygen sensor connector. Tighten the bolts to the specified torque. Exhaust pipe flange bolt torque: • m (4.4 kg·m/32 lb ft) 14. Install transfer and exhaust protectors. Tighten the bolts to the specified torque. Torque: 37 N • m (3.8 kg·m/27 lb ft) 15. Fill transmission through overfill screw hole of oil pan, using ATF DEXRON –III, refer to Changing Transmission Fluid in this section. 16. Connect battery ground cable. |
