6E–158 4JX1–TC ENGINE DRIVEABILITY AND EMISSIONS DTC P1510 – Idle SW Malfunction, Short Circuit
Step Action Value(s) Yes No 1 Was the “On-Board Diagnostic (OBD) System Check” — Go to Step 2 Go to OBD System Check 2 1. Ignition “ON,” engine “OFF.” conditions as noted. 4. Using a Tech 2, monitor the “DTC” info for DTC P1510. Does the Tech 2 indicate DTC P1510 failed? — Go to Step 4 Refer to Diagnostic Aids 3 Check the Idle SW circuit for a poor connection and Did the terminal require repair? — Verify repair Go to Step 4 4 1. Ignition “ON.” OFF” on the Tech 2. Is the data list correct? — Verify repair Go to Step 5 5 Replace the Idle SW. Is the action complete? — Verify repair — |
