6A – 18 ENGINE MECHANICAL

Injector

N·m (kg·m/lb·ft)

011RX003

20N·m(2.0kg·m/14.5 Ib ft)

6.5N·m(0.7kg·m/5.0 Ib ft)

Recheck tightening torque
after tighten the oil rail

Apply engine oil on the
thread of stud bolts

20N·m(2.0kg·m/14.5 Ib ft)

Tighten 30N·m(3.1kg·m/22 Ib ft)
Then loosen it again tighten with
25N·m(2.4kg·m/17 Ib ft)

Apply engine oil
both side

田中

'98/ 11/ 5

発注者

発注日

13278

作業番号

ENGINE MECHANICAL 6A – 19

High Pressure Oil Pipe

N·m (kg·m/lb·ft)

80(8.1/57.9)

040RW016

6A – 20 ENGINE MECHANICAL

Air Duct and Intercooler

N·m (kg·m/lb·ft)

4.0(0.4/3)

3.0(0.3/2.2)

20(2.0/14.5)

036RW013

ENGINE MECHANICAL 6A – 21

Engine Mount Bracket

N·m (kg·m/lb·ft)

50(5.1/37)

127(13/94)

40(4/29)

022RW019
