6E–314 ENGINE DRIVEABILITY AND EMISSIONS 3. Connect the wiring connector to the fuel gauge unit. TS23771 4. Fill the fuel tank with fuel. D Tighten the fuel filler cap. D Check for leaks at the fuel gauge unit gasket. 5. Connect the negative battery cable. Fuel Injectors Removal Procedure NOTE: If the fuel injectors are leaking, the engine oil may NOTE: Use care in removing the fuel injectors in order to IMPORTANT: Fuel injectors are serviced as a complete assembly only. 1. Disconnect the negative battery cable. Common Chamber in Engine Mechanical.. 3. Remove the fuel rail. Refer to Fuel Rail. 014RW164 4. Remove the injector retainer clip. 055RW009 5. Remove the fuel injector assembly. Inspection Procedure 1. Inspect the O-rings for cracks or leaks. installation. |
