6C–8 ENGINE FUEL 7. Disconnect two fuel tank wiring connectors(4) on front right side of tank. 8. Disconnect evapo fuel hose(5). NOTE: Handling of the fuel tube, be sure to refer “Fuel 10. Remove fuel tank fixing bolts on both sides and remove fuel tank(7). Installation 1. Install fuel tank(7). D Place a flange on right side of tank on the bracket. D Install a flange on left side on the bracket from the Torque: 36 N·m (3.7 Kg·m/27 lb ft) 2. Connect fuel feed tube and fuel return tube(6). hose(2). 7. Install fender liner(1). D Mount fender liner to the wheel well. D Fill the tank with fuel and tighten fuel filler cap. D Connect battery ground cable. Fuel Tube / Quick – Connect Fittings Precautions D Lighting of Fires Prohibited. D Keep flames away from your work area to prevent the D Disconnect the battery negative cable to prevent D When welding or conducting other heat-generating Cautions During Work Do not expose the assembly to battery electrolyte or do Removal 1. Open the fuel cap to relieve the fuel pressure in the tank. 141RW016 As some pressure may remain in the piping, cover the |
