DRIVE LINE CONTROL SYSTEM (TOD) 4B2–116 Step Action Yes No 1 Are the front and rear tires in specified size? Go to Step 2 Replace the tires with specified ones, and service the new tires. Go to Step 16 2 Is the tire pressure correct? Go to Step 3 In flate tries to recommended pressure. Go to Step 16 3 Are the tires free from abnormal wear? Go to Step 4 Replace the tires with specified ones, and service the new tires. Go to Step 16 4 Are different types of tires used? Go to Step 5 Replace the tires with specified ones, and service the new tires. Go to Step 16 5 1. Start the engine. AUTO SW to 4WD position. 3. Fully turn the steering to the left (or right) end, and select the D range and start the creep run. Does the tight corner braking occur? Is the judder with chug-chug Go to Step 6 Go to Step 11 6 1. Shift the transfer lever to the high position and switch the 4WD AUTO SW to the 2H position. 2. Fully turn the steering to the left (or right) end, and select the D range and start the creep run. Does the tight corner braking occur? Is the judder with chug-chug Go to Step 7 Go to Step 14 7 Is an LSD mounted to the rear differential? Go to Step 8 Go to Step 9 8 Is the genuine LSD oil used in the rear differential? Go to Step 9 Replace the differential oil. Go to Step 16 9 Does the engine output the power correctly? Go to Step 10 Check the engine. Go to Step 16 10 Do the speed sensors work correctly? (Check trouble codes.) The ECU has failed. Replace the ECU. Go to Step 16 Replace the speed sensors. Go to Step 16 11 Is the tight corner braking observed only when the brake is Go to Step 12 Conduct full steering under WOT. Go to Step 5 12 1. Turn on the starter switch. Is the battery voltage observed between terminals 11 and 19? Go to Step 13 Repair the circuit of terminal 11 (ABS IN). Go to Step 16 |
