AIR CONDITIONING 1B – 29 3. Drive Belt 1) Temporary tighten the power steering pump unit fixing bolts. 2) Push the drive belt when the force of 98N {10kgf}., and adjust the drive belt tension by tightening ∼ 17 mm (0.55 ∼ 0.67 in) of deflection of the belt is obtained. Then tighten the power steering pump 2. Magnetic Clutch Harness Connector 1. Air Duct (Turbo to air cleaner) Power steering Tension adjustment Crank pulley Drive belt Compressor 98N{10kgf} 14 ∼ 17mm (0.55 ∼ 0.67 in.) 850RY00002 |
