Opel Frontera UBS. Manual - part 19

00 – 48 SERVICE INFORMATION

FIXING TORQUE

N·m (kg·m / lb·ft)

1 6 1 4 1 A

芳賀

25(2.5/18)

15(1.5/11)

15(1.5/11)

13(1.3/113in)

6.0(0.6/52in)

6(0.6/52in)

38(3.9/28)

19(1.9/14)

19(1.9/14)

15(1.5/11)

25(2.5 / 18)

27(2.8 / 20)

40(4.1/30)

40(4.1/30)

20(2.0/14)

15(1.5/11)

25(2.5/18)

27(2.8/20)

4JX1

4JG2

6VD1/6VE1, RHD

19(1.9/14)

40(4.1/30)

19(1.9/14)

27(2.8/20)

6VD1/6VE1, LHD

19(1.9/14)

15(1.5/11)

E01RY00001

SERVICE INFORMATION  00 – 49

15(1.5/11)

5(0.5/43in)

14(1.4/122in)

22(2.2/16)

DKV-14D TYPE

N·m (kg·m / lb·in)

13(1.3/113)

5(0.5/43)

DKS-15CH TYPE

N·m (kg·m / lb·ft)

871RY00027

871RY00026

00 – 50 SERVICE INFORMATION

Legend

1. Clutch Driver
2. Rotor Bearing Retainer
3. Pulley Rotor and Bearing

Assembly

4. Clutch Coil Assembly
5. Connector
6. Shaft Seal Parts
7. Pump Assembly
8. High Pressure Relief Valve
9. Shipping Cap
10. Special 134a Suction Port
11. Special 134a Discharge Port

Caution

The operations described below are based
on bench overhaul with the compressor
removed from the vehicle, except as noted.
They have been prepared in order of
accessibility of the components. When a
compressor is removed from the vehicle for
servicing, the amount of PAG lubricant
remaining in the compressor should be
drained, measured and recorded. This PAG
lubricant should then be discarded and an
equal amount of new PAG lubricant added to
the compressor.
The service compressor is shipped without
PAG oil. When service procedures require,
use only Isuzu approved PAG oil.

HEATING, VENTILATION AND AIR CONDITIONING(HVAC)

1

2

3

4

5

6

8

9

7

10

11

871RW002

SERVICE INFORMATION  00 – 51

Metric Thread Size Information

Compressor to mounting bracket bolts(Front)
M10

×

1.5 – 6H

Compressor to mounting bracket bolts(Rear)
M8

×

1.25 – 6H

Suction-discharge port screw
M10

×

1.5 – 6H

Compressor shaft
M9

×

1.25 – 6H

Internal hub-clutch drive assembly
M22

×

1.5 – 6H
