4A1–6 DIFFERENTIAL (FRONT) Removal 1. Jack up the vehicle and support it using jack stand. 2. Remove the tire and wheel. 3. Remove the stone guard. 4. Remove the brake caliper fixing bolt and hang the caliper. Refer to Disc Brakes in Brake section. 5. Remove the antilock brake system speed sensor. Refer to Front Wheel Speed Sensor in Brake 6. Remove the hub and disc assembly. Refer to Front Hub and Disc in this section. 7. Remove the propeller shaft, refer to Front Propeller Shaft in this section. 8. Loosen the height control arm of the torsion bar, then remove the torsion bar from lower control arm. 9. Remove the suspension crossmember. 10. Remove the lower nut (1) of the stabilizer link. 11. Remove the lower bolt and nut (2) of the shock absorber. 412RW057 12. Remove the tie-rod end from the knuckle. Refer to Power Steering Unit in Steering Section. 13. Disconnect the hose of the shift on the fly, at the hose clip portion (1). 14. Disconnect the shift switch connector (2). 412RW058 15. Remove the bolts and nuts of the lower control arm (Frame side), then disconnect the lower control arm 16. Disconnect between the right side upper control arm and the knuckle, then remove the knuckle with lower CAUTION: When removing the knuckle, be careful 410RW008 |
