6A–32 ENGINE MECHANICAL (6VD1 3.2L) 2. Align the alignment mark on the RH bank camshaft drive gear pulley (2) to the alignment 3. Align the alignment mark (white line) on the timing belt (1) with alignment mark on the RH bank 014RW00004 Legend (1) Alignment Mark on Timing Belt (White line). Pulley. (3) Alignemnt Mark on Cylinder Head Cover RH. 4. Align the alignment mark on the LH bank camshaft drive gear pulley (2) to the alignment 5. Align the alignment mark (white line) on the timing belt (1) with the alignment mark on the LH bank NOTE: It is recommended for easy installation that the 014RW00005 Legend (1) Alignment Mark on Timing Belt (White line). Pulley. (3) Alignemnt Mark on Cylinder Head Cover LH. 6. Install crankshaft pulley temporarily and tighten center bolt by hand (do not use a wrench). 2. Install pusher and tighten bolt to the specified torque. Torque : 25 N·m (2.5 Kg·m/18 lb ft) 1. Install the pusher while pushing the tension pulley to the belt. 2. Pull out pin from the pusher. NOTE: When reusing the pusher, press the pusher with 014RW011 |
