5D–3 PARKING BRAKE SYSTEM Parking Brake Lever and Front Cable Parking Brake Lever Assembly and Associated Parts 311RW013–1 Legend (1) Rear Console (5) Trunnion Pin Removal 1. Remove rear console (1). D Refer to Body and Accessories section. 2. Disconnect switch connector (2). (8). 7. Disconnect parking brake rear cable (7). Installation 1. Apply grease (BESCO L–2 or equivalent) to the connecting portion of the rear cable (7) and equalizer 2. Connect parking brake rear cable (7) to equalizer adjust nut and lock nut (4). D To adjust the parking brake lever, see “Parking Lock Nut Torque: 13 N·m (1.3 kg·m/113 lb in) 5. Tighten the parking brake lever fixing bolt (3) to the specified torque. Torque: 15 N·m (1.5 kg·m/11 lb ft) 6. Connect switch connector (2). D Refer to Body and Accessories section. |
