8A–18 LIGHTING SYSTEM Door Switch Removal 1. Disconnect the battery ground cable. 2. Remove the door switch (2). • Remove the screw (1). • Disconnect the connector (3). 825RW289 Installation To install, follow the removal steps in the reverse order. Rear Defogger Switch Removal 1. Disconnect the battery ground cable. 2. Remove the meter cluster assembly (1). • Refer to Instrument Panel Assembly in Body Structure section. 3. Remove the rear defogger switch (2). • Disconnect the switch connector. • Push the lock from the back side of the meter cluster assembly. 825RW280 Installation To install, follow the removal steps in the reverse order. |
