4C–10 DRIVE SHAFT SYSTEM Disassembly NOTE: For the left side, follow the same steps as right 1. Raise the hooked end of the band with a screwdriver or equivalent. 412RS009 2. Remove band(1). 3. Pry off circlip (1) with a screwdriver or equivalent. 412RS010 4. Remove drive shaft joint assembly. 5. Remove the six balls (1) with a screwdriver or equivalent. 412RS012 6. Using snap ring pliers, remove the snap ring (1) fastening the ball retainer to the center shaft. 412RS013 |
