Nissan Cube (2014 year). Instruction

2-10

Instruments and controls

Average fuel consumption (mpg or l
(liter)/100 km)

The average fuel consumption mode shows the
average fuel consumption since the last reset.
Resetting is done by pushing the trip computer
mode switch

for approximately 1 second.

The display is updated every 30 seconds. At
about the first 1/3 mile (500 m) after a reset, the
display shows “---”.

Average speed (mph or km/h)

The average speed mode shows the average
vehicle speed since the last reset. Resetting is
done by pushing the trip computer mode switch

for approximately 1 second.

The display is updated every 30 seconds. The
first 30 seconds after a reset, the display shows
“---”.

Resetting displays

When the average fuel consumption, average
speed or TRIP B is displayed, push the trip
computer mode switch

for longer than 3

seconds. The average fuel consumption, aver-
age speed and trip odometer (TRIP B only)
displays will be reset at the same time.

2-10

Instruments and controls

Average fuel consumption (mpg or l
(liter)/100 km)

The average fuel consumption mode shows the
average fuel consumption since the last reset.
Resetting is done by pushing the trip computer
mode switch

for approximately 1 second.

The display is updated every 30 seconds. At
about the first 1/3 mile (500 m) after a reset, the
display shows “---”.

Average speed (mph or km/h)

The average speed mode shows the average
vehicle speed since the last reset. Resetting is
done by pushing the trip computer mode switch

for approximately 1 second.

The display is updated every 30 seconds. The
first 30 seconds after a reset, the display shows
“---”.

Resetting displays

When the average fuel consumption, average
speed or TRIP B is displayed, push the trip
computer mode switch

for longer than 3

seconds. The average fuel consumption, aver-
age speed and trip odometer (TRIP B only)
displays will be reset at the same time.

Anti-lock Braking System (ABS) warning
light

Low tire pressure warning light

Front passenger air bag status light

Brake warning light

P position selecting warning light*

High beam indicator light

Charge warning light

Seat belt warning light

Malfunction Indicator Light (MIL)

Door open warning light

Supplemental air bag warning light

Overdrive off indicator light*

Electric power steering warning light

Vehicle Dynamic Control (VDC) warning
light

Security indicator light

Engine oil pressure warning light

Cruise indicator light

Turn signal/hazard indicator lights

Intelligent Key system warning light*

Engine start operation indicator light*

Vehicle Dynamic Control (VDC) off indicator
light

Low fuel warning light

Exterior light indicator

*: if so equipped

Instruments and controls

2-11

WARNING/INDICATOR LIGHTS AND
AUDIBLE REMINDERS

Anti-lock Braking System (ABS) warning
light

Low tire pressure warning light

Front passenger air bag status light

Brake warning light

P position selecting warning light*

High beam indicator light

Charge warning light

Seat belt warning light

Malfunction Indicator Light (MIL)

Door open warning light

Supplemental air bag warning light

Overdrive off indicator light*

Electric power steering warning light

Vehicle Dynamic Control (VDC) warning
light

Security indicator light

Engine oil pressure warning light

Cruise indicator light

Turn signal/hazard indicator lights

Intelligent Key system warning light*

Engine start operation indicator light*

Vehicle Dynamic Control (VDC) off indicator
light

Low fuel warning light

Exterior light indicator

*: if so equipped

Instruments and controls

2-11

WARNING/INDICATOR LIGHTS AND
AUDIBLE REMINDERS

2-12

Instruments and controls

CHECKING BULBS

With all doors closed, apply the parking brake
and place the ignition switch in the ON position
without starting the engine. The following lights
will come on:

The following lights come on briefly and then go
off (if so equipped):

If any light does not come on, it may indicate a
burned-out bulb or an open circuit in the
electrical system. Have the system checked by
a NISSAN dealer.

WARNING LIGHTS

Anti-lock Braking System (ABS)

warning light

When the ignition switch is in the ON position,
the Anti-lock Braking System (ABS) warning
light illuminates and then turns off. This indicates
the ABS is operational.

If the ABS warning light illuminates while the
engine is running, or while driving, it may
indicate the ABS is not functioning properly.
Have the system checked by a NISSAN dealer.

If an ABS malfunction occurs, the anti-lock
function is turned off. The brake system then
operates normally, but without anti-lock assis-

tance. (See “Brake system” (P.5-27).)

Brake warning light

This light functions for both the parking brake
and the foot brake systems.

Parking brake indicator:

When the ignition switch is in the ON position,
the light illuminates when the parking brake is
applied.

Low brake fluid warning light:

When the ignition switch is in the ON position,
the light warns of a low brake fluid level. If the
light illuminates while the engine is running with
the parking brake not applied, stop the vehicle
and perform the following:

1. Check the brake fluid level. If brake fluid is

necessary, add fluid and have the system
checked by a NISSAN dealer. (See “Brake
and clutch fluid” (P.8-12).)

2. If the brake fluid level is correct, have the

warning system checked by a NISSAN
dealer.

Anti-lock Braking System (ABS) warning
indicator:

When the parking brake is released and the
brake fluid level is sufficient, if both the brake
warning light and the Anti-lock Braking System
(ABS) warning light illuminate, it may indicate

the ABS is not functioning properly. Have the
brake system checked, and if necessary re-
paired, by a NISSAN dealer promptly. (See
“Anti-lock Braking System (ABS) warning light”
(P.2-12).)

WARNING

. Your brake system may not be

working properly if the warning light
is on. Driving could be dangerous. If
you judge it to be safe, drive care-
fully to the nearest service station
for repairs. Otherwise, have your
vehicle towed because driving it
could be dangerous.

. Pressing the brake pedal with the

engine stopped and/or low brake
fluid level may increase your stop-
ping distance and braking will re-
quire greater pedal effort as well as
pedal travel.

. If the brake fluid level is below the

minimum or MIN mark on the brake
fluid reservoir, do not drive until the
brake system has been checked at a
NISSAN dealer.

2-12

Instruments and controls

CHECKING BULBS

With all doors closed, apply the parking brake
and place the ignition switch in the ON position
without starting the engine. The following lights
will come on:

The following lights come on briefly and then go
off (if so equipped):

If any light does not come on, it may indicate a
burned-out bulb or an open circuit in the
electrical system. Have the system checked by
a NISSAN dealer.

WARNING LIGHTS

Anti-lock Braking System (ABS)

warning light

When the ignition switch is in the ON position,
the Anti-lock Braking System (ABS) warning
light illuminates and then turns off. This indicates
the ABS is operational.

If the ABS warning light illuminates while the
engine is running, or while driving, it may
indicate the ABS is not functioning properly.
Have the system checked by a NISSAN dealer.

If an ABS malfunction occurs, the anti-lock
function is turned off. The brake system then
operates normally, but without anti-lock assis-

tance. (See “Brake system” (P.5-27).)

Brake warning light

This light functions for both the parking brake
and the foot brake systems.

Parking brake indicator:

When the ignition switch is in the ON position,
the light illuminates when the parking brake is
applied.

Low brake fluid warning light:

1. Check the brake fluid level. If brake fluid is

necessary, add fluid and have the system
checked by a NISSAN dealer. (See “Brake
and clutch fluid” (P.8-12).)

2. If the brake fluid level is correct, have the

warning system checked by a NISSAN
dealer.

Anti-lock Braking System (ABS) warning
indicator:

When the parking brake is released and the
brake fluid level is sufficient, if both the brake
warning light and the Anti-lock Braking System
(ABS) warning light illuminate, it may indicate

the ABS is not functioning properly. Have the
brake system checked, and if necessary re-
paired, by a NISSAN dealer promptly. (See
“Anti-lock Braking System (ABS) warning light”
(P.2-12).)

WARNING

. Your brake system may not be

. Pressing the brake pedal with the

engine stopped and/or low brake
fluid level may increase your stop-
ping distance and braking will re-
quire greater pedal effort as well as
pedal travel.

. If the brake fluid level is below the

minimum or MIN mark on the brake
fluid reservoir, do not drive until the
brake system has been checked at a
NISSAN dealer.

Charge warning light

If the light illuminates while the engine is running,
it may indicate the charging system is not
functioning properly. Turn the engine off and
check the alternator belt. If the belt is loose,
broken, missing or if the light remains on, see a
NISSAN dealer immediately.

CAUTION

Do not continue driving if the alternator
belt is loose, broken or missing.

Door open warning light

This light illuminates when any of the doors and/
or back door are not closed securely while the
ignition switch is in the ON position.

Electric power steering warning

light

When the ignition switch is in the ON position,
the electric power steering warning light illumi-
nates. After starting the engine, the electric
power steering warning light turns off. This
indicates the electric power steering system is
operational.

If the electric power steering warning light
illuminates while the engine is running, it may

indicate the electric power steering system is
not functioning properly and may need servicing.
Have the electric power steering system
checked by a NISSAN dealer.

When the electric power steering warning light
illuminates with the engine running, the power
assist to the steering will cease operation but
you will still have control of the vehicle. At this
time, greater steering efforts are required to
operate the steering wheel, especially in sharp
turns and at low speeds.

See “Electric power steering system” (P.5-26).

Engine oil pressure warning light

This light warns of low engine oil pressure. If the
light flickers or illuminates during normal driving,
pull off the road in a safe area, stop the engine
immediately and call a NISSAN dealer or other
authorized repair shop.

The engine oil pressure warning light is
not designed to indicate a low oil level.
Use the dipstick to check the oil level. (See
“Engine oil” (P.8-9).)

CAUTION

Running the engine with the engine oil
pressure warning light on could cause
serious damage to the engine almost

immediately. Such damage is not cov-
ered by warranty. Turn off the engine as
soon as it is safe to do so.

Intelligent Key system warning light

(if so equipped)

After the ignition switch is placed in the ON
position, this light comes on for about 2 seconds
and then turns off.

This light illuminates or blinks as follows:
. The light blinks in yellow when the door is

closed with the Intelligent Key left outside
the vehicle and the ignition switch in the
ACC or ON position. Make sure that the
Intelligent Key is inside the vehicle.

. The light blinks in green when the Intelligent

Key battery is running out of power. Replace
the battery with a new one. (See “Key
battery replacement” (P.8-23).)

. The light illuminates in yellow when it warns

of a malfunction with the Intelligent Key
system.

If the warning light illuminates in yellow while the
engine is stopped, it may be impossible to start
the engine. If the light comes on while the engine
is running, you can drive the vehicle. However in
these cases, contact a NISSAN dealer for repair
as soon as possible.

Instruments and controls

2-13

Charge warning light

CAUTION

Do not continue driving if the alternator
belt is loose, broken or missing.

Door open warning light

This light illuminates when any of the doors and/
or back door are not closed securely while the
ignition switch is in the ON position.

Electric power steering warning

light

If the electric power steering warning light
illuminates while the engine is running, it may

indicate the electric power steering system is
not functioning properly and may need servicing.
Have the electric power steering system
checked by a NISSAN dealer.

See “Electric power steering system” (P.5-26).

Engine oil pressure warning light

The engine oil pressure warning light is
not designed to indicate a low oil level.
Use the dipstick to check the oil level. (See
“Engine oil” (P.8-9).)

CAUTION

Running the engine with the engine oil
pressure warning light on could cause
serious damage to the engine almost

immediately. Such damage is not cov-
ered by warranty. Turn off the engine as
soon as it is safe to do so.

Intelligent Key system warning light

(if so equipped)

After the ignition switch is placed in the ON
position, this light comes on for about 2 seconds
and then turns off.

This light illuminates or blinks as follows:
. The light blinks in yellow when the door is

closed with the Intelligent Key left outside
the vehicle and the ignition switch in the
ACC or ON position. Make sure that the
Intelligent Key is inside the vehicle.

. The light blinks in green when the Intelligent

Key battery is running out of power. Replace
the battery with a new one. (See “Key
battery replacement” (P.8-23).)

. The light illuminates in yellow when it warns

of a malfunction with the Intelligent Key
system.

Instruments and controls

2-13

2-14

Instruments and controls

Low fuel warning light

This light illuminates when the fuel in the tank is
getting low. Refuel as soon as it is convenient,
preferably before the fuel gauge reaches the 0
(empty) position.

There will be a small reserve of fuel
remaining in the tank when the fuel gauge
reaches the 0 position.

Low tire pressure warning light

Your vehicle is equipped with a Tire Pressure
Monitoring System (TPMS) that monitors the tire
pressure of all tires except the spare.

The low tire pressure warning light warns of low
tire pressure or indicates that the TPMS is not
functioning properly.

After the ignition switch is placed in the ON
position, this light illuminates for about 1 second
and turns off.

Low tire pressure warning:

If the vehicle is being driven with low tire
pressure, the warning light will illuminate. A
CHECK TIRE PRES (pressure) warning mes-
sage is also displayed in the vehicle information
display.

When the low tire pressure warning light
illuminates, you should stop and adjust the tire
pressure to the recommended COLD tire

pressure shown on the Tire and Loading
Information label. The low tire pressure warning
light does not automatically turn off when the tire
pressure is adjusted. After the tire is inflated to
the recommended pressure, the vehicle must be
driven at speeds above 16 MPH (25 km/h) to
activate the TPMS and turn off the low tire
pressure warning light. Use a tire pressure
gauge to check the tire pressure.

The low tire pressure warning light remains
illuminated until the tires are inflated to the
recommended COLD tire pressure. The CHECK
TIRE PRES warning message is displayed each
time the ignition switch is placed in the ON
position as long as the low tire pressure warning
light remains illuminated.

For additional information, see “Check tire
pressure warning message” (P.2-6), “Tire Pres-
sure Monitoring System (TPMS)” (P.5-3) and
“Tire Pressure Monitoring System (TPMS)” (P.6-
3).

TPMS malfunction:

If the TPMS is not functioning properly, the low
tire pressure warning light will flash for approxi-
mately 1 minute when the ignition switch is
placed in the ON position. The light will remain
on after 1 minute. The CHECK TIRE PRES
warning message is not displayed if the low tire
pressure warning light illuminates to indicate a

TPMS malfunction. Have the system checked by
a NISSAN dealer.

For additional information, see “Tire Pressure
Monitoring System (TPMS)” (P.5-3).

WARNING

. If the light does not illuminate with

the ignition switch placed in the ON
position, have the vehicle checked
by a NISSAN dealer as soon as
possible.

. If the light illuminates while driving,

avoid sudden steering maneuvers or
abrupt braking, reduce vehicle
speed, pull off the road to a safe
location and stop the vehicle as
soon as possible. Driving with un-
der-inflated tires may permanently
damage the tires and increase the
likelihood of tire failure. Serious
vehicle damage could occur and
may lead to an accident and could
result in serious personal injury.
Check the tire pressure for all four
tires. Adjust the tire pressure to the
recommended COLD tire pressure
shown on the Tire and Loading
Information label to turn the low

2-14

Instruments and controls

Low fuel warning light

This light illuminates when the fuel in the tank is
getting low. Refuel as soon as it is convenient,
preferably before the fuel gauge reaches the 0
(empty) position.

There will be a small reserve of fuel
remaining in the tank when the fuel gauge
reaches the 0 position.

Low tire pressure warning light

Your vehicle is equipped with a Tire Pressure
Monitoring System (TPMS) that monitors the tire
pressure of all tires except the spare.

The low tire pressure warning light warns of low
tire pressure or indicates that the TPMS is not
functioning properly.

After the ignition switch is placed in the ON
position, this light illuminates for about 1 second
and turns off.

Low tire pressure warning:

If the vehicle is being driven with low tire
pressure, the warning light will illuminate. A
CHECK TIRE PRES (pressure) warning mes-
sage is also displayed in the vehicle information
display.

When the low tire pressure warning light
illuminates, you should stop and adjust the tire
pressure to the recommended COLD tire

For additional information, see “Check tire
pressure warning message” (P.2-6), “Tire Pres-
sure Monitoring System (TPMS)” (P.5-3) and
“Tire Pressure Monitoring System (TPMS)” (P.6-
3).

TPMS malfunction:

TPMS malfunction. Have the system checked by
a NISSAN dealer.

For additional information, see “Tire Pressure
Monitoring System (TPMS)” (P.5-3).

WARNING

. If the light does not illuminate with

the ignition switch placed in the ON
position, have the vehicle checked
by a NISSAN dealer as soon as
possible.

. If the light illuminates while driving,

tire pressure warning light OFF. If
the light still illuminates while driv-
ing after adjusting the tire pressure,
a tire may be flat. If you have a flat
tire, replace it with a spare tire as
soon as possible.

. When a spare tire is mounted or a

wheel is replaced, the TPMS will not
function and the low tire pressure
warning light will flash for approxi-
mately 1 minute. The light will
remain on after 1 minute. Contact
your NISSAN dealer as soon as
possible for tire replacement and/
or system resetting.

. Replacing tires with those not ori-

ginally specified by NISSAN could
affect the proper operation of the
TPMS.

CAUTION

. The TPMS is not a substitute for the

regular tire pressure check. Be sure
to check the tire pressure regularly.

. If the vehicle is being driven at

speeds of less than 16 MPH (25
km/h), the TPMS may not operate

correctly.

. Be sure to install the specified size

of tires to the four wheels correctly.

P position selecting warning light

(if so equipped)

The warning light blinks in red when the ignition
switch is pushed to stop the engine with the
shift lever in any position except the P (Park)
position.

If this warning appears, move the shift lever to
the P (Park) position or push the ignition switch
to the ON position.

An inside warning chime will also sound.

See “Intelligent Key system” (P.3-10).

Seat belt warning light

The light and chime remind you to fasten seat
belts. The light illuminates whenever the ignition
switch is placed in the ON position, and will
remain illuminated until the driver’s seat belt is
fastened. At the same time, the chime will sound
for about 6 seconds unless the driver’s seat belt
is securely fastened.

The seat belt warning light for the front
passenger will illuminate if the seat belt is not
fastened when the front passenger’s seat is
occupied. For 5 seconds after the ignition

switch is in the ON position, the system does
not activate the warning light for the front
passenger.

See “Seat belts” (P.1-11) for precautions on
seat belt usage.

Supplemental air bag warning light

After placing the ignition switch in the ON
position, the supplemental air bag warning light
will illuminate. The supplemental air bag warning
light will turn off after about 7 seconds if the
supplemental front air bag and supplemental
side air bag, curtain side-impact air bag systems
and/or pretensioner seat belt are operational.

If any of the following conditions occur, the front
air bag, side air bag, curtain air bag and
pretensioner systems need servicing and your
vehicle must be taken to your nearest NISSAN
dealer.
. The supplemental air bag warning light

remains on after approximately 7 seconds.

. The supplemental air bag warning light

flashes intermittently.

. The supplemental air bag warning light does

not illuminate at all.

Unless checked and repaired, the Supplemental
Restraint Systems and/or the pretensioners may
not function properly.

For additional information, see “Supplemental

Instruments and controls

2-15

. When a spare tire is mounted or a

. Replacing tires with those not ori-

ginally specified by NISSAN could
affect the proper operation of the
TPMS.

CAUTION

. The TPMS is not a substitute for the

regular tire pressure check. Be sure
to check the tire pressure regularly.

. If the vehicle is being driven at

speeds of less than 16 MPH (25
km/h), the TPMS may not operate

correctly.

. Be sure to install the specified size

of tires to the four wheels correctly.

P position selecting warning light

(if so equipped)

The warning light blinks in red when the ignition
switch is pushed to stop the engine with the
shift lever in any position except the P (Park)
position.

If this warning appears, move the shift lever to
the P (Park) position or push the ignition switch
to the ON position.

An inside warning chime will also sound.

See “Intelligent Key system” (P.3-10).

Seat belt warning light

The seat belt warning light for the front
passenger will illuminate if the seat belt is not
fastened when the front passenger’s seat is
occupied. For 5 seconds after the ignition

switch is in the ON position, the system does
not activate the warning light for the front
passenger.

See “Seat belts” (P.1-11) for precautions on
seat belt usage.

Supplemental air bag warning light

remains on after approximately 7 seconds.

. The supplemental air bag warning light

flashes intermittently.

. The supplemental air bag warning light does

not illuminate at all.

Unless checked and repaired, the Supplemental
Restraint Systems and/or the pretensioners may
not function properly.

For additional information, see “Supplemental

Instruments and controls

2-15

2-16

Instruments and controls

restraint system” (P.1-41).

WARNING

If the supplemental air bag warning
light is on, it could mean that the front
air bag, side air bag, curtain air bag
and/or pretensioner systems will not
operate in an accident. To help avoid
injury to yourself or others, have your
vehicle checked by a NISSAN dealer as
soon as possible.

Vehicle Dynamic Control (VDC)

warning light

The light will blink when the Vehicle Dynamic
Control (VDC) system or the traction control
system is operating, thus alerting the driver that
the vehicle is nearing its traction limits. The road
surface may be slippery.

If the VDC warning light illuminates while the
VDC system is on, this light alerts the driver to
the fact that the VDC system’s fail-safe mode is
operating, for example the VDC system may not
be functioning properly. Have the system
checked by a NISSAN dealer. If a malfunction
occurs in the system, the VDC system function
will be canceled but the vehicle is still driveable.

For additional information, see “Vehicle Dynamic
Control (VDC) system” (P.5-29) of this manual.

INDICATOR LIGHTS

Cruise indicator light

Cruise main switch indicator:

This light illuminates when the cruise control
main switch is pushed. The light turns off when
the main switch is pushed again. When the
cruise indicator light illuminates, the cruise
control system is operational.

Cruise malfunction:

If the cruise indicator light blinks while the
engine is running, it may indicate the cruise
control system is not functioning properly. Have
the system checked by a NISSAN dealer.

See “Cruise control” (P.5-21).

Engine start operation indicator

light (if so equipped)

This light appears when the shift lever is in the P
(Park) position. This light means that the engine
will start by pushing the ignition switch with the
brake pedal depressed. You can start the engine
directly in any position.

Exterior light indicator

This indicator illuminates when the headlight
switch is turned to the AUTO (if so equipped),

position and the front parking lights,

instrument panel lights, tail lights, license plate
lights or headlights are on. The indicator turns
off when these lights are turned off.

Front passenger air bag status light

The front passenger air bag status light (located
on the center of the instrument panel) will be lit
and the passenger front air bag will be OFF
depending on how the front passenger seat is
being used.

For front passenger air bag status light opera-
tion, see “NISSAN Advanced Air Bag System
(front seats)” (P.1-47) of this manual.

High beam indicator light

This light illuminates when the headlight high
beam is on and goes out when the low beam is
selected.

2-16

Instruments and controls

restraint system” (P.1-41).

WARNING

Vehicle Dynamic Control (VDC)

warning light

For additional information, see “Vehicle Dynamic
Control (VDC) system” (P.5-29) of this manual.

INDICATOR LIGHTS

Cruise indicator light

Cruise main switch indicator:

Cruise malfunction:

If the cruise indicator light blinks while the
engine is running, it may indicate the cruise
control system is not functioning properly. Have
the system checked by a NISSAN dealer.

See “Cruise control” (P.5-21).

Engine start operation indicator

light (if so equipped)

Exterior light indicator

This indicator illuminates when the headlight
switch is turned to the AUTO (if so equipped),

position and the front parking lights,

instrument panel lights, tail lights, license plate
lights or headlights are on. The indicator turns
off when these lights are turned off.

Front passenger air bag status light

For front passenger air bag status light opera-
tion, see “NISSAN Advanced Air Bag System
(front seats)” (P.1-47) of this manual.

High beam indicator light

This light illuminates when the headlight high
beam is on and goes out when the low beam is
selected.

Malfunction Indicator Light (MIL)

If the malfunction indicator light illuminates
steady or blinks while the engine is running, it
may indicate a potential emission control and/or
Continuously Variable Transmission (CVT) mal-
function.

The malfunction indicator light may also illumi-
nate steady if the fuel-filler cap is loose or
missing, or if the vehicle runs out of fuel. Check
to make sure the fuel-filler cap is installed and
closed tightly, and that the vehicle has at least 3
US gallons (11.4 liters) of fuel in the fuel tank.

After a few driving trips, the

light should

turn off if no other potential emission control
system malfunction exists.

If this indicator light remains on for 20 seconds
and then blinks for 10 seconds when the engine
is not running, it indicates that the vehicle is not
ready for an emission control system inspection/
maintenance test. (See “Readiness for Inspec-
tion/Maintenance (I/M) test” (P.9-19).)

Operation:

The malfunction indicator light will illuminate in
one of two ways:
. Malfunction indicator light illuminated steady

— An emission control system and/or CVT
malfunction has been detected. Check the
fuel-filler cap if the LOOSE FUEL CAP

warning message is displayed on the twin
trip odometer. If the fuel-filler cap is loose or
missing, tighten or install the cap and
continue to drive the vehicle. The

light

should turn off after a few driving trips. If the

light does not turn off after a few driving

trips, have the vehicle inspected by a
NISSAN dealer. You do not need to have
your vehicle towed to the dealer.

. Malfunction indicator light blinking — An

engine misfire has been detected which may
damage the emission control system.
To reduce or avoid emission control system
damage:
1) Do not drive at speeds above 45 MPH

(72 km/h).

2) Avoid hard acceleration or deceleration.
3) Avoid steep uphill grades.
4) If possible, reduce the amount of cargo

being hauled or towed.

The malfunction indicator light may stop
blinking and remain on.
Have the vehicle inspected by a NISSAN
dealer. You do not need to have your vehicle
towed to the dealer.

CAUTION

Continued vehicle operation without
having the emission control system
and/or CVT system checked and re-
paired as necessary could lead to poor
driveability, reduced fuel economy, and
possible damage to the emission con-
trol system.

Overdrive off indicator light (if so

equipped)

The overdrive off indicator light illuminates when
the overdrive off mode is selected.

For additional information, see “Continuously
Variable Transmission (CVT)” (P.5-14) of this
manual.

Security indicator light

The light blinks when the ignition switch is in the
ACC, OFF or LOCK position. This function
indicates the security system equipped on the
vehicle is operational.

If the security system is malfunctioning, this light
will remain on while the ignition switch is in the
ON position. For additional information, see
“Security systems” (P.2-19).

Instruments and controls

2-17

Malfunction Indicator Light (MIL)

After a few driving trips, the

light should

turn off if no other potential emission control
system malfunction exists.

Operation:

The malfunction indicator light will illuminate in
one of two ways:
. Malfunction indicator light illuminated steady

— An emission control system and/or CVT
malfunction has been detected. Check the
fuel-filler cap if the LOOSE FUEL CAP

warning message is displayed on the twin
trip odometer. If the fuel-filler cap is loose or
missing, tighten or install the cap and
continue to drive the vehicle. The

light

should turn off after a few driving trips. If the

light does not turn off after a few driving

trips, have the vehicle inspected by a
NISSAN dealer. You do not need to have
your vehicle towed to the dealer.

. Malfunction indicator light blinking — An

engine misfire has been detected which may
damage the emission control system.
To reduce or avoid emission control system
damage:
1) Do not drive at speeds above 45 MPH

(72 km/h).

2) Avoid hard acceleration or deceleration.
3) Avoid steep uphill grades.
4) If possible, reduce the amount of cargo

being hauled or towed.

The malfunction indicator light may stop
blinking and remain on.
Have the vehicle inspected by a NISSAN
dealer. You do not need to have your vehicle
towed to the dealer.

CAUTION

Overdrive off indicator light (if so

equipped)

The overdrive off indicator light illuminates when
the overdrive off mode is selected.

For additional information, see “Continuously
Variable Transmission (CVT)” (P.5-14) of this
manual.

Security indicator light

The light blinks when the ignition switch is in the
ACC, OFF or LOCK position. This function
indicates the security system equipped on the
vehicle is operational.

If the security system is malfunctioning, this light
will remain on while the ignition switch is in the
ON position. For additional information, see
“Security systems” (P.2-19).

Instruments and controls

2-17

2-18

Instruments and controls

Turn signal/hazard indicator lights

The light flashes when the turn signal switch
lever or hazard switch is turned on.

Vehicle Dynamic Control (VDC) off

indicator light

The light comes on when the Vehicle Dynamic
Control (VDC) off switch is pushed to OFF. This
indicates that the VDC system and traction
control system are not operating.

AUDIBLE REMINDERS

Key reminder chime

Models with Intelligent Key system:

A chime will sound if the driver side door is
opened while the ignition switch is pushed to
the ACC position.

Make sure the ignition switch is pushed to the
OFF position, and take the Intelligent Key with
you when leaving the vehicle.

Models without Intelligent Key system:

The key reminder chime sounds if the driver’s
side door is opened while the key is left in the
ignition switch and the ignition switch is in the
ACC, OFF or LOCK position. Remove the key
and take it with you when leaving the vehicle.

Light reminder chime

The light reminder chime will sound when the
driver side door is opened with the light switch
in the

position, and the ignition

switch is in the ACC, OFF or LOCK position.

Turn the light switch off when you leave the
vehicle.

Brake pad wear warning

The disc brake pads have audible wear warn-
ings. When a brake pad requires replacement, it
will make a high pitched scraping sound when
the vehicle is in motion. This scraping sound will
first occur only when the brake pedal is
depressed. After more wear of the brake pad,
the sound will always be heard even if the brake
pedal is not depressed. Have the brakes
checked as soon as possible if the warning
sound is heard.

Parking brake reminder chime

The parking brake reminder chime will sound if
the vehicle is driven at more than 4 MPH (7
km/h) with the parking brake applied. Stop the
vehicle and release the parking brake.

Seat belt warning chime

The seat belt warning chime will sound for about
6 seconds unless the driver’s seat belt is
securely fastened.

2-18

Instruments and controls

Turn signal/hazard indicator lights

The light flashes when the turn signal switch
lever or hazard switch is turned on.

Vehicle Dynamic Control (VDC) off

indicator light

The light comes on when the Vehicle Dynamic
Control (VDC) off switch is pushed to OFF. This
indicates that the VDC system and traction
control system are not operating.

AUDIBLE REMINDERS

Key reminder chime

Models with Intelligent Key system:

A chime will sound if the driver side door is
opened while the ignition switch is pushed to
the ACC position.

Make sure the ignition switch is pushed to the
OFF position, and take the Intelligent Key with
you when leaving the vehicle.

Models without Intelligent Key system:

Light reminder chime

The light reminder chime will sound when the
driver side door is opened with the light switch
in the

position, and the ignition

switch is in the ACC, OFF or LOCK position.

Turn the light switch off when you leave the
vehicle.

Brake pad wear warning

Parking brake reminder chime

The parking brake reminder chime will sound if
the vehicle is driven at more than 4 MPH (7
km/h) with the parking brake applied. Stop the
vehicle and release the parking brake.

Seat belt warning chime

The seat belt warning chime will sound for about
6 seconds unless the driver’s seat belt is
securely fastened.

SIC4160

Your vehicle has two types of security systems,
as follows:
. Vehicle security system
. NISSAN Vehicle Immobilizer System
The security condition will be shown by the
security indicator light.

VEHICLE SECURITY SYSTEM

The vehicle security system provides visual and
audio alarm signals if someone opens the doors,
or back door when the system is armed. It is not,
however, a motion detection type system that
activates when a vehicle is moved or when a
vibration occurs.

The system helps deter vehicle theft but cannot
prevent it, nor can it prevent the theft of interior
or exterior vehicle components in all situations.
Always secure your vehicle even if parking for a
brief period. Never leave your keys in the vehicle,
and always lock it when unattended. Be aware
of your surroundings, and park in secure, well-lit
areas whenever possible.

Many devices offering additional protection,
such as component locks, identification markers,
and tracking systems, are available at auto
supply stores and specialty shops. Your
NISSAN dealer may also offer such equipment.
Check with your insurance company to see if
you may be eligible for discounts for various
theft protection features.

SIC2045

How to arm the vehicle security system

1. Close all windows.

The system can be armed even if the
windows are open.

2. Models with Intelligent Key system:

Place the ignition switch in the OFF position
and remove the Intelligent Key from the
vehicle.

Models without Intelligent Key system:

Place the ignition switch in the LOCK
position and remove the key.

3. Close all doors. Lock all doors. The doors

can be locked with:

Instruments and controls

2-19

SECURITY SYSTEMS

SIC4160

Your vehicle has two types of security systems,
as follows:
. Vehicle security system
. NISSAN Vehicle Immobilizer System
The security condition will be shown by the
security indicator light.

VEHICLE SECURITY SYSTEM

SIC2045

How to arm the vehicle security system

1. Close all windows.

The system can be armed even if the
windows are open.

2. Models with Intelligent Key system:

Place the ignition switch in the OFF position
and remove the Intelligent Key from the
vehicle.

Models without Intelligent Key system:

Place the ignition switch in the LOCK
position and remove the key.

3. Close all doors. Lock all doors. The doors

can be locked with:

Instruments and controls

2-19

SECURITY SYSTEMS

2-20

Instruments and controls

a. the LOCK

button on the keyfob or

Intelligent Key (if so equipped)

b. any request switch (Intelligent Key

equipped model)

c. the power door lock switch

d. the key — master or mechanical (Intelli-

gent Key equipped model)

4. Confirm that the security indicator light

illuminates. The security indicator light stays
on for about 30 seconds. The vehicle
security system is now pre-armed. After
about 30 seconds the vehicle security
system automatically shifts into the armed
phase. The security light begins to flash
once every approximately 3 seconds. If,
during this 30-second pre-arm time period,
the door is unlocked, or the ignition switch is
placed in the ACC or ON position, the
system will not arm.

Even when the driver and/or passengers
are in the vehicle, the system will activate
with all doors locked with the ignition
switch in the LOCK position. When placing
the ignition switch in the ACC or ON
position, the system will be released.

Vehicle security system activation

The vehicle security system will give the follow-
ing alarm:
. The headlights blink and the horn sounds

intermittently.

. The alarm automatically turns off after

approximately 50 seconds. However, the
alarm reactivates if the vehicle is tampered
with again.

The alarm is activated by:
. Unlocking the door without using the keyfob,

the Intelligent Key (if so equipped) the
request switch (if so equipped) or the key.
(Even if the door is opened by releasing the
door inside lock knob, the alarm will
activate.)

How to stop an activated alarm

The alarm will stop by unlocking a door by
pushing the UNLOCK

button on the keyfob

or Intelligent Key, pushing the request switch or
using the key. The alarm will not stop if the
ignition switch is placed in the ACC or ON
position.

If the system does not operate as de-
scribed above, have it checked by a
NISSAN dealer.

NISSAN VEHICLE IMMOBILIZER SYS-
TEM

The NISSAN Vehicle Immobilizer System will not
allow the engine to start without the use of the
registered key.

If the engine fails to start using the registered
key, it may be due to interference caused by
another registered key, an automated toll road
device or automated payment device on the key
ring. Restart the engine using the following
procedures:

1. Leave the ignition switch in the ON position

for approximately 5 seconds.

2. Place the ignition switch in the OFF or

LOCK position and wait approximately 10
seconds.

3. Repeat step 1 and 2 again.

4. Restart the engine while holding the device

(which may have caused the interference)
separate from the registered key.

If this procedure allows the engine to start,
NISSAN recommends placing the regis-
tered key on a separate key ring to avoid
interference from other devices.

Statement related to section 15 of FCC
rules for NISSAN Vehicle Immobilizer
System (CONT ASSY-BCM. ANT ASSY-
IMMOBILISER)

2-20

Instruments and controls

a. the LOCK

button on the keyfob or

Intelligent Key (if so equipped)

b. any request switch (Intelligent Key

equipped model)

c. the power door lock switch

d. the key — master or mechanical (Intelli-

gent Key equipped model)

4. Confirm that the security indicator light

Vehicle security system activation

The vehicle security system will give the follow-
ing alarm:
. The headlights blink and the horn sounds

intermittently.

. The alarm automatically turns off after

approximately 50 seconds. However, the
alarm reactivates if the vehicle is tampered
with again.

The alarm is activated by:
. Unlocking the door without using the keyfob,

the Intelligent Key (if so equipped) the
request switch (if so equipped) or the key.
(Even if the door is opened by releasing the
door inside lock knob, the alarm will
activate.)

How to stop an activated alarm

The alarm will stop by unlocking a door by
pushing the UNLOCK

button on the keyfob

or Intelligent Key, pushing the request switch or
using the key. The alarm will not stop if the
ignition switch is placed in the ACC or ON
position.

If the system does not operate as de-
scribed above, have it checked by a
NISSAN dealer.

NISSAN VEHICLE IMMOBILIZER SYS-
TEM

The NISSAN Vehicle Immobilizer System will not
allow the engine to start without the use of the
registered key.

1. Leave the ignition switch in the ON position

for approximately 5 seconds.

2. Place the ignition switch in the OFF or

LOCK position and wait approximately 10
seconds.

3. Repeat step 1 and 2 again.

4. Restart the engine while holding the device

(which may have caused the interference)
separate from the registered key.

If this procedure allows the engine to start,
NISSAN recommends placing the regis-
tered key on a separate key ring to avoid
interference from other devices.

Statement related to section 15 of FCC
rules for NISSAN Vehicle Immobilizer
System (CONT ASSY-BCM. ANT ASSY-
IMMOBILISER)

FCC Notice:

This device complies with Part 15 of the
FCC Rules. Operation is subject to the
following two conditions: (1) This device
may not cause harmful interference, and
(2) this device must accept any interfer-
ence received, including interference that
may cause undesired operation.

NOTE:

Changes or modifications not expressly
approved by the party responsible for
compliance could void the user’s authority
to operate the equipment.

SIC2045

Security indicator light

The security indicator light is located on the
meter panel. It indicates the status of the
NISSAN Vehicle Immobilizer System.

The light blinks after the ignition switch was in
the LOCK position. This function indicates the
security systems equipped on the vehicle are
operational.

If the NISSAN Vehicle Immobilizer System is
malfunctioning, this light will remain on while the
ignition switch is in the ON position.

If the light still remains on and/or the
engine will not start, see a NISSAN dealer
for NISSAN Vehicle Immobilizer System

service as soon as possible. Please bring
all registered keys that you have when
visiting a NISSAN dealer for service.

Instruments and controls

2-21

FCC Notice:

NOTE:

Changes or modifications not expressly
approved by the party responsible for
compliance could void the user’s authority
to operate the equipment.

SIC2045

Security indicator light

The security indicator light is located on the
meter panel. It indicates the status of the
NISSAN Vehicle Immobilizer System.

The light blinks after the ignition switch was in
the LOCK position. This function indicates the
security systems equipped on the vehicle are
operational.

If the NISSAN Vehicle Immobilizer System is
malfunctioning, this light will remain on while the
ignition switch is in the ON position.

If the light still remains on and/or the
engine will not start, see a NISSAN dealer
for NISSAN Vehicle Immobilizer System

service as soon as possible. Please bring
all registered keys that you have when
visiting a NISSAN dealer for service.

Instruments and controls

2-21

2-22

Instruments and controls

WARNING

In freezing temperatures the washer
solution may freeze on the windshield
and obscure your vision which may lead
to an accident. Warm windshield with
the defroster before you wash the
windshield.

CAUTION

. Do not operate the washer continu-

ously for more than 30 seconds.

. Do not operate the washer if the

reservoir tank is empty.

. Do not fill the window washer

reservoir tank with washer fluid
concentrates at full strength. Some
methyl alcohol based washer fluid
concentrates may permanently stain
the grille if spilled while filling the
window washer reservoir tank.

. Pre-mix washer fluid concentrates

with water to the manufacturer’s
recommended levels before pouring
the fluid into the window washer

reservoir tank. Do not use the
window washer reservoir tank to
mix the washer fluid concentrate
and water.

If the windshield wiper operation is inter-
rupted by snow or ice, the wiper may stop
moving to protect its motor. If this occurs,
turn the wiper switch to the OFF position
and remove the snow or ice that is on and
around the wiper arms. In approximately 1
minute, turn the switch on again to operate
the wiper.

SIC3664

The windshield wiper and washer operates
when the ignition switch is in the ON position.

Push the lever down to operate the wiper at the
following speed:

Intermittent — intermittent operation can be
adjusted by turning the knob toward

(Slower) or

(Faster).

Low — continuous low speed operation

High — continuous high speed operation

Push the lever up

to have one sweep

operation of the wiper.

Pull the lever toward you

to operate the

washer. Then the wiper will also operate several
times.

WINDSHIELD WIPER AND WASHER
SWITCH

2-22

Instruments and controls

WARNING

In freezing temperatures the washer
solution may freeze on the windshield
and obscure your vision which may lead
to an accident. Warm windshield with
the defroster before you wash the
windshield.

CAUTION

. Do not operate the washer continu-

ously for more than 30 seconds.

. Do not operate the washer if the

reservoir tank is empty.

. Do not fill the window washer

. Pre-mix washer fluid concentrates

with water to the manufacturer’s
recommended levels before pouring
the fluid into the window washer

reservoir tank. Do not use the
window washer reservoir tank to
mix the washer fluid concentrate
and water.

SIC3664

The windshield wiper and washer operates
when the ignition switch is in the ON position.

Push the lever down to operate the wiper at the
following speed:

Intermittent — intermittent operation can be
adjusted by turning the knob toward

(Slower) or

(Faster).

Low — continuous low speed operation

High — continuous high speed operation

Push the lever up

to have one sweep

operation of the wiper.

Pull the lever toward you

to operate the

washer. Then the wiper will also operate several
times.

WINDSHIELD WIPER AND WASHER
SWITCH

WARNING

In freezing temperatures the washer
solution may freeze on the rear window
glass and obscure your vision. Warm
the rear window with the defroster
before you wash the rear window.

CAUTION

. Do not operate the washer continu-

ously for more than 30 seconds.

. Do not operate the washer if the

reservoir tank is empty.

. Do not fill the window washer

. Pre-mix washer fluid concentrates

with water to the manufacturer’s
recommended levels before pouring
the fluid into the window washer
reservoir tank. Do not use the

window washer reservoir tank to
mix the washer fluid concentrate
and water.

If the rear window wiper operation is
interrupted by snow or ice, the wiper may
stop moving to protect its motor. If this
occurs, turn the wiper switch to the OFF
position and remove the snow or ice that is
on and around the wiper arms. In approxi-
mately 1 minute, turn the switch on again
to operate the wiper.

SIC3666

The rear window wiper and washer operate
when the ignition switch is in the ON position.

Turn the switch clockwise from the OFF position
to operate the wiper.

Intermittent (INT) — intermittent operation (not
adjustable)

Low (ON) — continuous low speed operation

Push the switch forward

to operate the

washer. Then the wiper will also operate several
times.

Instruments and controls

2-23

REAR WINDOW WIPER AND
WASHER SWITCH

WARNING

In freezing temperatures the washer
solution may freeze on the rear window
glass and obscure your vision. Warm
the rear window with the defroster
before you wash the rear window.

CAUTION

. Do not operate the washer continu-

ously for more than 30 seconds.

. Do not operate the washer if the

reservoir tank is empty.

. Do not fill the window washer

. Pre-mix washer fluid concentrates

with water to the manufacturer’s
recommended levels before pouring
the fluid into the window washer
reservoir tank. Do not use the

window washer reservoir tank to
mix the washer fluid concentrate
and water.

SIC3666

The rear window wiper and washer operate
when the ignition switch is in the ON position.

Turn the switch clockwise from the OFF position
to operate the wiper.

Intermittent (INT) — intermittent operation (not
adjustable)

Low (ON) — continuous low speed operation

Push the switch forward

to operate the

washer. Then the wiper will also operate several
times.

Instruments and controls

2-23

REAR WINDOW WIPER AND
WASHER SWITCH

2-24

Instruments and controls

SIC4127

Type A

SIC4145

Type B

To defog/defrost the rear window glass, start the
engine and push the switch

on. The

indicator light

will illuminate. Push the switch

again to turn the defroster off.

It will automatically turn off in approximately 15
minutes.

CAUTION

When cleaning the inner side of the rear
window, be careful not to scratch or
damage the rear window defroster.

SIC3668

HEADLIGHT SWITCH

Lighting

Turn the switch to the

position:

The front parking, side marker, tail, license plate
and instrument lights will come on.

Turn the switch to the

position:

Headlights will come on and all the other lights
remain on.

REAR WINDOW DEFROSTER
SWITCH

HEADLIGHT AND TURN SIGNAL
SWITCH

2-24

Instruments and controls

SIC4127

Type A

SIC4145

Type B

To defog/defrost the rear window glass, start the
engine and push the switch

on. The

indicator light

will illuminate. Push the switch

again to turn the defroster off.

It will automatically turn off in approximately 15
minutes.

CAUTION

When cleaning the inner side of the rear
window, be careful not to scratch or
damage the rear window defroster.

SIC3668

HEADLIGHT SWITCH

Lighting

Turn the switch to the

position:

The front parking, side marker, tail, license plate
and instrument lights will come on.

Turn the switch to the

position:

Headlights will come on and all the other lights
remain on.

REAR WINDOW DEFROSTER
SWITCH

HEADLIGHT AND TURN SIGNAL
SWITCH

SIC3669

Autolight system (if so equipped)

The autolight system allows the headlights to be
set so they turn on and off automatically.

To set the autolight system:

1. Make sure the headlight switch is in the

AUTO position

2. Place the ignition switch in the ON position.

3. The autolight system automatically turns the

headlights on and off.

To turn the autolight system off, turn the switch
to the OFF,

position.

The autolight system can turn on the headlights
automatically when it is dark and turn off the

headlights when it is light.

The headlights will also be turned on automa-
tically at twilight or in rainy weather (when the
windshield wiper is operated continuously).

If the ignition switch is placed in the OFF
position and one of the doors is opened and this
condition is continued, the headlights remain on
for a period of time.

Automatic headlights off delay:

You can keep the headlights on for up to 45
seconds after you place the ignition switch in
OFF and open any door then close all the doors.

SIC3784A

Be sure not to put anything on top of the
photo sensor

located on the top of the

instrument panel. The photo sensor con-
trols the autolight; if it is covered, the
photo sensor reacts as if it is dark and the
headlights will illuminate.

Instruments and controls

2-25

SIC3669

Autolight system (if so equipped)

The autolight system allows the headlights to be
set so they turn on and off automatically.

To set the autolight system:

1. Make sure the headlight switch is in the

AUTO position

2. Place the ignition switch in the ON position.

3. The autolight system automatically turns the

headlights on and off.

To turn the autolight system off, turn the switch
to the OFF,

position.

The autolight system can turn on the headlights
automatically when it is dark and turn off the

headlights when it is light.

The headlights will also be turned on automa-
tically at twilight or in rainy weather (when the
windshield wiper is operated continuously).

If the ignition switch is placed in the OFF
position and one of the doors is opened and this
condition is continued, the headlights remain on
for a period of time.

Automatic headlights off delay:

You can keep the headlights on for up to 45
seconds after you place the ignition switch in
OFF and open any door then close all the doors.

SIC3784A

Be sure not to put anything on top of the
photo sensor

located on the top of the

instrument panel. The photo sensor con-
trols the autolight; if it is covered, the
photo sensor reacts as if it is dark and the
headlights will illuminate.

Instruments and controls

2-25

Nissan Cube (2014 year). Instruction - part 6
