Nissan 370Z Coupe (2017 year). Instruction - part 9

(130,1)

[ Edit: 2016/ 2/ 22

Model: 2017MY NISSAN 370Z(Z34) OM17E00Z34U0 ]

3-6

Pre-driving checks and adjustments

3. Within 20 seconds of performing Step 2,

push and hold the power door lock switch to
the

position (UNLOCK) for more than 5

seconds.

4. When activated, the hazard indicator will

flash twice. When deactivated, the hazard
indicator will flash once.

5. The ignition switch must be placed in the

OFF and ON position again between each
setting change.

When the automatic door unlock system is
deactivated, the doors do not unlock when the
ignition switch is placed in the OFF position. To
unlock the door manually, use the inside lock
knob or the power door lock switch (driver’s or
front passenger’s side).

WARNING

Radio waves could adversely affect
electric medical equipment. Those
who use a pacemaker should con-
tact the electric medical equipment
manufacturer for the possible influ-
ences before use.

The Intelligent Key transmits radio
w a v e s w h e n t h e b u t t o n s a r e
pushed. The FAA advises that the
radio waves may affect aircraft na-
vigation and communication sys-
t e m s .

D o

n o t

o p e r a t e

t h e

Intelligent Key while on an airplane.
Make sure the buttons are not
operated unintentionally when the
unit is stored during a flight.

The Intelligent Key system can operate all the
door and rear hatch/trunk lid locks using the
remote controller function or pushing the re-
quest switch on the vehicle without taking the
key out from a pocket or purse. The operating
environment and/or conditions may affect the
Intelligent Key system operation.

Be sure to read the following before using the
Intelligent Key system.

CAUTION

Be sure to carry the Intelligent Key
with you when operating the vehi-
cle.

Never leave the Intelligent Key in
the vehicle when you leave the
vehicle.

The Intelligent Key is always communicating with
the vehicle as it receives radio waves. The
Intelligent Key system transmits weak radio
waves. Environmental conditions may interfere
with the operation of the Intelligent Key system
under the following operating conditions.

When operating near a location where
strong radio waves are transmitted, such
as a TV tower, power station and broad-
casting station.

When in possession of wireless equipment,
such as a cellular telephone, transceiver,
and CB radio.

When the Intelligent Key is in contact with or
covered by metallic materials.

When any type of radio wave remote control
is used nearby.

When the Intelligent Key is placed near an
electric appliance such as a personal

INTELLIGENT KEY SYSTEM

Condition:

(131,1)

[ Edit: 2016/ 2/ 22

Model: 2017MY NISSAN 370Z(Z34) OM17E00Z34U0 ]

computer.

When the vehicle is parked near a parking
meter.

In such cases, correct the operating conditions
before using the Intelligent Key function or use
the mechanical key.

Although the life of the battery varies depending
on the operating conditions, the battery’s life is
approximately 2 years. If the battery is dis-
charged, replace it with a new one.

When the Intelligent Key battery is almost
discharged, insert the Intelligent Key into the
Intelligent Key port to start the engine. Replace
the discharged battery with a new one as soon
as possible. For more details, see “Push-button
ignition switch” (P.5-8).

Since the Intelligent Key is continuously receiv-
ing radio waves, if the key is left near equipment
which transmits strong radio waves, such as
signals from a TV and personal computer, the
battery life may become shorter.

For information regarding replacement of a
battery, see “Intelligent Key battery replacement”
(P.8-20).

As many as 4 Intelligent Keys can be registered
and used with one vehicle. For information about
the purchase and use of additional Intelligent
Keys, contact a NISSAN dealer.

CAUTION

Do not allow the Intelligent Key,
which contains electrical compo-
nents, to come into contact with
water or salt water. This could affect
the system function.

Do not drop the Intelligent Key.

Do not strike the Intelligent Key
sharply against another object.

Do not change or modify the Intel-
ligent Key.

Wetting may damage the Intelligent
Key. If the Intelligent Key gets wet,
immediately wipe until it is comple-
tely dry.

If the outside temperature is below
148F (

−108C), the battery of the

Intelligent Key may not function
properly.

Do not place the Intelligent Key for
an extended period in an area where
temperatures exceed 1408F (608C).

Do not attach the Intelligent Key
with a key holder that contains a
magnet.

Do not place the Intelligent Key near
equipment that produces a mag-
netic field, such as a TV, audio
equipment, personal computer or
cellular phone.

If an Intelligent Key is lost or stolen, NISSAN
recommends erasing the ID code of that
Intelligent Key from the vehicle. This may prevent
the unauthorized use of the Intelligent Key to
operate the vehicle. For information regarding
the erasing procedure, contact a NISSAN deal-
er.

The Intelligent Key function can be disabled. For
information about disabling the Intelligent Key
function, contact a NISSAN dealer.

Pre-driving checks and adjustments

3-7

Condition:

(132,1)

[ Edit: 2016/ 2/ 22

Model: 2017MY NISSAN 370Z(Z34) OM17E00Z34U0 ]

3-8

Pre-driving checks and adjustments

SPA2567

INTELLIGENT KEY OPERATING
RANGE

The Intelligent Key functions can only be used
when the Intelligent Key is within the specified
operating range from the request switch

When the Intelligent Key battery is discharged or
strong radio waves are present near the operat-

ing location, the Intelligent Key system’s operat-
ing range becomes narrower, and the Intelligent
Key may not function properly.

The operating range is within 31.50 in (80 cm)
from each request switch

If the Intelligent Key is too close to the door
glass, handle or rear bumper the request
switches may not function.

When the Intelligent Key is within the operating
range, it is possible for anyone who does not
carry the Intelligent Key to push the request
switch to lock/unlock the doors including the
rear hatch/trunk lid.

SPA2568

DOOR LOCKS/UNLOCKS PRECAU-
TION

Do not push the door handle request switch
with the Intelligent Key held in your hand as
illustrated. The close distance to the door
handle will cause the Intelligent Key system
to have difficulty recognizing that the In-
telligent Key is outside the vehicle.

After locking with the door handle request
switch, verify the doors are securely locked
by testing them.

To prevent the Intelligent Key from being left
inside the vehicle, make sure you carry the
key with you and then lock the doors.

Condition:

(133,1)

[ Edit: 2016/ 2/ 22

Model: 2017MY NISSAN 370Z(Z34) OM17E00Z34U0 ]

Do not pull the door handle before pushing
the door handle request switch. The door
will be unlocked but will not open. Release
the door handle once and pull it again to
open the door.

Models with navigation system:

The Intelligent Key system (opening/closing
doors with the door handle request switch)
can be set to remain inactive. (See “Vehicle
information and settings (models with navi-
gation system)” (P.4-8).)

SPA2569

Coupe models

INTELLIGENT KEY OPERATION

You can lock or unlock the doors without taking
the key out from your pocket or bag.

SPA2570

SPA2571

Coupe models

Pre-driving checks and adjustments

3-9

Condition:

(134,1)

[ Edit: 2016/ 2/ 22

Model: 2017MY NISSAN 370Z(Z34) OM17E00Z34U0 ]

3-10

Pre-driving checks and adjustments

SPA2680

Roadster models

When you carry the Intelligent Key with you, you
can lock or unlock all doors and the rear hatch/
trunk lid by pushing the door handle request
switch (driver’s or front passenger’s)

or the

rear hatch/trunk request switch

within the

range of operation.

When you lock or unlock the doors and the rear
hatch/trunk lid, the hazard indicator will flash and
the horn (or the outside chime) will sound as a
confirmation. For details, see “Setting hazard
indicator and horn mode” (P.3-14).

Locking doors, rear hatch/trunk lid and
fuel-filler door

1. Push the ignition switch to the OFF position

and make sure you carry the Intelligent Key
with you.*1

2. Close all the doors and the rear hatch/trunk

lid.*2

3. Push the door handle request switch (dri-

ver’s or front passenger’s) or the rear hatch/
trunk request switch while carrying the
Intelligent Key with you.*3

4. All the doors, rear hatch/trunk lid and fuel-

filler door will lock.

5. The hazard indicator flashes twice and the

outside chime sounds twice.

*1:

Doors and the rear hatch/trunk lid will lock with
the Intelligent Key while the ignition switch is in
the ACC or ON position.

*2:

Doors and the rear hatch/trunk lid will not lock
with the Intelligent Key while any door or the rear
hatch/trunk lid is open.

*3:

Doors and the rear hatch/trunk lid will not lock by
pushing the door handle request switch or the
rear hatch/trunk request switch with the Intelli-
gent Key inside the vehicle. However, when an
Intelligent Key is inside the vehicle, doors and
the rear hatch/trunk lid can be locked with
another registered Intelligent Key.

Unlocking doors, rear hatch/trunk lid and
fuel-filler door

1. Push the door handle request switch (dri-

ver’s or front passenger’s) or the rear hatch/
trunk request switch once while carrying the
Intelligent Key with you.

2. The hazard indicator flashes once and out-

side chime sounds once. The corresponding
door and the fuel-filler door or the rear
hatch/trunk lid will unlock.

3. Push the door handle request switch or the

rear hatch/trunk request switch again within
60 seconds.

4. The hazard indicator flashes once and out-

side chime sounds once again. All the doors
and the rear hatch/trunk lid will unlock.

All doors, the rear hatch/trunk lid and the fuel-
filler door will be locked automatically unless one
of the following operations is performed within 1
minute after pushing the request switch while
the doors are locked.

Opening any door and/or the rear hatch/
trunk lid

Pushing the ignition switch

Inserting the Intelligent Key into the Intelli-
gent Key port.

During this 1-minute time period, if the UNLOCK

button on the Intelligent Key is pushed, all

Condition:

(135,1)

[ Edit: 2016/ 2/ 22

Model: 2017MY NISSAN 370Z(Z34) OM17E00Z34U0 ]

doors will be locked automatically after another
1 minute.

Opening rear hatch/trunk lid

To open only the rear hatch/trunk lid, perform the
following procedure.

1. Carry the Intelligent Key.

2. Push the rear hatch/trunk lid opener switch

3. The rear hatch/trunk lid will open.

Lockout protection:

To prevent the Intelligent Key from being
accidentally locked in the trunk, lockout protec-
tion is equipped with the Intelligent Key system.

When the trunk lid is closed with the Intelligent
Key inside the trunk, the outside buzzer will
sound and all doors and the trunk lid will unlock.

BATTERY SAVER SYSTEM

When all the following conditions are met for a
period of time, the battery saver system will cut
off the power supply to prevent battery dis-
charge.

The ignition switch is in the ACC position,
and

All doors are closed, and

The shift lever is in the P (Park) position
(Automatic Transmission models).

WARNING SIGNALS

To help prevent the vehicle from moving
unexpectedly by erroneous operation of the
Intelligent Key listed on the following chart or
to help prevent the vehicle from being stolen,
chime or beep sounds inside and outside the
vehicle and a warning displays in the vehicle
information display.

When a chime or beep sounds or the warning
displays, be sure to check the vehicle and
Intelligent Key.

See “Troubleshooting guide” (P.3-12) and
“Vehicle information display” (P.2-18).

Pre-driving checks and adjustments

3-11

Condition:

(136,1)

[ Edit: 2016/ 2/ 22

Model: 2017MY NISSAN 370Z(Z34) OM17E00Z34U0 ]

3-12

Pre-driving checks and adjustments

TROUBLESHOOTING GUIDE

Symptom

Possible cause

Action to take

When pushing the ignition switch
to stop the engine

The SHIFT P warning appears on the display
and the inside warning chime sounds con-
tinuously (Automatic Transmission models).

The shift lever is not in the P (Park)
position.

Shift the shift lever to the P (Park) position.

When opening the driver’s door
to get out of the vehicle

The inside warning chime sounds continuously.

The ignition switch is in the ACC
position.

Push the ignition switch to the OFF posi-
tion.

The Intelligent Key is in the Intelligent
Key port.

Remove the Intelligent Key from the Intelli-
gent Key port.

When closing the door after get-
ting out of the vehicle

The NO KEY warning appears on the display,
the outside chime sounds 3 times and the
inside warning chime sounds for approximately
a few seconds.

The ignition switch is in the ACC or ON
position.

Push the ignition switch to the OFF posi-
tion.

The SHIFT P warning appears on the display
and the outside chime sounds continuously
(Automatic Transmission models).

The ignition switch is in the ACC or OFF
position and the shift lever is not in the P
(Park) position.

Move the shift lever to the P (Park) position
and push the ignition switch to the OFF
position.

When closing the door with the
inside lock knob turned to LOCK

The outside chime sounds for a few seconds
and all the doors unlock.

The Intelligent Key is inside the vehicle
and cargo/trunk room area.

Carry the Intelligent Key with you.

When pushing the door handle
request switch to lock the door

The outside chime sounds for a few seconds.

The Intelligent Key is inside the vehicle
and cargo/trunk room area.

Carry the Intelligent Key with you.

A door is not closed securely.

Close the door securely.

When closing the trunk lid
(Roadster models)

The outside chime sounds for a few seconds
and all doors unlock.

The Intelligent Key is inside the trunk.

Carry the Intelligent Key with you.

When shifting the shift lever to the
P (Park) position (Automatic
Transmission models)

The inside warning chime sounds continuously. The ignition switch is in the ON position. The ignition switch is in the OFF position.

Condition:

(137,1)

[ Edit: 2016/ 2/ 22

Model: 2017MY NISSAN 370Z(Z34) OM17E00Z34U0 ]

WARNING

The Intelligent Key transmits radio
waves when the buttons are pushed.
The FAA advises that the radio waves
may affect aircraft navigation and com-
munication systems. Do not operate the
Intelligent Key while on an airplane.
Make sure the buttons are not operated
unintentionally when the unit is stored
during a flight.

It is possible to lock/unlock all doors, fuel-filler
door, activate the panic alarm and open the
windows by pushing the buttons on the Intelli-
gent Key from outside the vehicle.

Before locking the doors, make sure the
Intelligent Key is not left in the vehicle.

The LOCK/UNLOCK button on the Intelligent
Key can operate at a distance of approximately
33 ft (10 m) from the vehicle. (The effective
distance depends upon the conditions around
the vehicle.)

As many as 4 Intelligent Keys can be used with
one vehicle. For information concerning the
purchase and use of additional Intelligent Keys,
contact a NISSAN dealer.

The lock and unlock buttons on the Intelligent
Key will not operate when:

the distance between the Intelligent Key and
the vehicle is over 33 ft (10 m).

the Intelligent Key battery is discharged.

After locking with the remote keyless entry
function, pull the door handle to make sure the
doors are securely locked.

The LOCK/UNLOCK operating range varies
depending on the environment. To securely
operate the lock and unlock buttons, approach
the vehicle to about 3 ft (1 m) from the door.

SPA2252B

LOCK button

UNLOCK button

PANIC button

HOW TO USE REMOTE KEYLESS
ENTRY SYSTEM

When you lock or unlock the doors and rear
hatch/trunk lid, the hazard indicator will flash and
the horn (or the outside chime) will sound as a
confirmation. For details, see “Setting hazard
indicator and horn mode” (P.3-14).

Pre-driving checks and adjustments

3-13

REMOTE KEYLESS ENTRY SYSTEM

Condition:

(138,1)

[ Edit: 2016/ 2/ 22

Model: 2017MY NISSAN 370Z(Z34) OM17E00Z34U0 ]

3-14

Pre-driving checks and adjustments

Locking doors, rear hatch/trunk lid and
fuel-filler door

1. Push the ignition switch to the OFF position

and make sure you carry the Intelligent Key
with you.*

2. Close all the doors and the rear hatch/trunk

lid.

3. Push the LOCK

button

on the

Intelligent Key.

4. All the doors, the rear hatch/trunk lid and

fuel-filler door will lock.

5. The hazard indicator flashes twice and the

horn chirps once.

Doors and the rear hatch/trunk lid will lock with
the Intelligent Key while the ignition switch is in
the ACC or ON position.

Unlocking doors, rear hatch/trunk lid and
fuel-filler door

1. Push the UNLOCK

button

on the

Intelligent Key once.

2. The hazard indicator flashes once. The

driver’s door and fuel-filler door will unlock.

3. Push the UNLOCK

button on the

Intelligent Key again within 60 seconds.

4. The hazard indicator flashes once again. All

the doors and the rear hatch/trunk lid will
unlock.

All doors and the rear hatch/trunk lid will be
locked automatically unless one of the following
operations is performed within 1 minute after
pushing the UNLOCK

button on the

Intelligent Key while the doors are locked. If
during this 1-minute time period, the UNLOCK

button on the Intelligent Key is pushed, all

doors and the rear hatch/trunk lid will be locked
automatically after another 1 minute.

Opening any door

Pushing the ignition switch

Inserting the Intelligent Key into the Intelli-
gent Key port

Opening windows

The UNLOCK

button operation also allows

you to open a window that is equipped with the
automatic open/close function. (See “Power
windows” (P.2-45).)

To open the window, push the door UNLOCK

button

on the Intelligent Key for about

3 seconds after the door is unlocked.

To stop opening, release the UNLOCK
button.

Window cannot be closed using the Intelligent
Key.

The door window can be opened or closed by
turning the metal key in a door lock. (See
“Doors” (P.3-4).)

Using panic alarm

If you are near your vehicle and feel threatened,
you may activate the alarm to call attention as
follows:

1. Push the PANIC

button

on the Key

for more than 1 second.

2. The theft warning alarm and headlights will

stay on for 25 seconds.

3. The panic alarm stops when:

It has run for 25 seconds, or

Any of the buttons on the Intelligent Key

are pushed. (Note: Panic button should
be pushed for more than 1 second.)

Setting hazard indicator and horn mode

This vehicle is set in hazard indicator and horn
mode when you first receive the vehicle.

In hazard indicator and horn mode, when the
LOCK

button

is pushed, the hazard

indicator flashes twice and the horn chirps once.
When the UNLOCK

button

is pushed,

the hazard indicator flashes once.

If horns are not necessary, the system can be
switched to the hazard indicator mode.

In hazard indicator mode, when the LOCK
button is pushed, the hazard indicator flashes
twice. When the UNLOCK

button is

pushed, neither the hazard indicator nor the

Condition:

(139,1)

[ Edit: 2016/ 2/ 22

Model: 2017MY NISSAN 370Z(Z34) OM17E00Z34U0 ]

horn operates.

Hazard indicator and horn mode:

DOOR LOCK

DOOR UNLOCK

Intelligent Key system

(Using door handle or rear hatch/trunk

request switch)

HAZARD - twice
OUTSIDE CHIME - twice

HAZARD - once
OUTSIDE CHIME - once

Remote keyless entry system

(Using

button)

HAZARD - twice
HORN - once

HAZARD - once
HORN - none

Hazard indicator mode:

DOOR LOCK

DOOR UNLOCK

Intelligent Key system

(Using door handle or rear hatch/trunk

request switch)

HAZARD - twice
OUTSIDE CHIME - none

HAZARD - none
OUTSIDE CHIME - none

Remote keyless entry system

(Using

button)

HAZARD - twice
HORN - none

HAZARD - none
HORN - none

Pre-driving checks and adjustments

3-15

Condition:

(140,1)

[ Edit: 2016/ 2/ 22

Model: 2017MY NISSAN 370Z(Z34) OM17E00Z34U0 ]

3-16

Pre-driving checks and adjustments

Switching procedure:

To switch the hazard indicator and horn (chime)
operation, push the LOCK

and UN-

LOCK

buttons on the Intelligent Key

simultaneously for more than 2 seconds.

When the hazard indicator mode is set, the
hazard indicator flashes 3 times.

When the hazard indicator and horn mode is
set, the hazard indicator flashes once and
the horn chirps once.

SPA2572

When opening the hood:

1. Pull the hood lock release handle

located below the instrument panel; the
hood will then spring up slightly.

2. Pull the lever

up at the front of the hood

with your fingertips and raise the hood.

3. Hold the insulator

of the support rod

and insert its end into the slot

on the

front edge of the hood.

When closing the hood:

1. While supporting the hood, return the

support rod to its original position.

2. Slowly lower the hood to about 8 to 12 in

(20 to 30 cm) above the hood lock, then let
it drop.

3. Make sure it is securely latched.

WARNING

Make sure the hood is completely
closed and latched before driving.
Failure to do so could cause the
hood to fly open and result in an
accident.

If you see steam or smoke coming
from the engine compartment, to

HOOD

Condition:

(141,1)

[ Edit: 2016/ 2/ 22

Model: 2017MY NISSAN 370Z(Z34) OM17E00Z34U0 ]

avoid injury do not open the hood.

WARNING

Do not drive with the rear hatch open.
This could allow dangerous exhaust
gases to be drawn into the vehicle.
See “Exhaust gas (carbon monoxide)”
(P.5-2) of this manual.

SPA2573

REAR HATCH OPENER SWITCH

The rear hatch can be opened by pushing the
rear hatch opener switch when the Intelligent
Key is within the operating range of the rear
hatch lock/unlock function regardless of the
inside lock knob position. (See “Intelligent Key
system” (P.3-6).)

To close the rear hatch, push it down securely.

Pre-driving checks and adjustments

3-17

REAR HATCH (Coupe models)

Condition:

(142,1)

[ Edit: 2016/ 2/ 22

Model: 2017MY NISSAN 370Z(Z34) OM17E00Z34U0 ]

3-18

Pre-driving checks and adjustments

JVP0317X

NISMO models

CAUTION

Do not use the rear spoiler

to open

or close the rear hatch. Doing so may

damage the rear spoiler.

Always hold area

to open or close the rear

hatch.

SPA2580

SECONDARY REAR HATCH RELEASE

The secondary rear hatch release mechanism
allows opening the rear hatch in the event of
discharged battery or emergency.

The release handle is located under the cargo
room carpet. To open the rear hatch from the
passenger compartment, perform the following
procedure.

1. Remove the cargo room carpet.

2. Find the rear hatch release handle

shown in the illustration.

3. Free the release handle that is fixed with

velcro.

Condition:

(143,1)

[ Edit: 2016/ 2/ 22

Model: 2017MY NISSAN 370Z(Z34) OM17E00Z34U0 ]

4. Firmly pull the release handle until the rear

hatch releases.

WARNING

Do not drive with the trunk lid open.
This could allow dangerous exhaust
gases to be drawn into the vehicle.
See “Exhaust gas (carbon monox-
ide)” (P.5-2) of this manual.

Closely supervise children when
they are around cars to prevent
them from playing and becoming
locked in the trunk where they could
be seriously injured. Keep the car
locked, with the trunk closed, when
not in use, and prevent children’s
access to Intelligent Keys.

SPA2692

TRUNK LID OPENER SWITCH

The trunk lid can be opened by pushing the
trunk lid opener switch when the Intelligent Key
is within the operating range of the trunk lock/
unlock function regardless of the inside lock
knob position. (See “Intelligent Key system”
(P.3-6).)

Pre-driving checks and adjustments

3-19

TRUNK LID (Roadster models)

Condition:

(144,1)

[ Edit: 2016/ 2/ 22

Model: 2017MY NISSAN 370Z(Z34) OM17E00Z34U0 ]

3-20

Pre-driving checks and adjustments

SPA2681

TRUNK RELEASE POWER CANCEL
SWITCH

When the switch located inside the glove box is
in the OFF position

, the power to the trunk

lid will be canceled and the trunk lid cannot be
opened by the trunk lid opener or trunk request
switch.

When you have to leave the vehicle with a valet
and want to keep your belongings safe in the
glove box and the trunk, push this switch to OFF
and lock the glove box with the mechanical key.
Then leave the vehicle and the Intelligent Key
with the valet and keep the mechanical key with
you.

See “Keys” (P.3-2).

To connect the power to the trunk lid, push the
switch to the ON

position.

INTERIOR TRUNK LID RELEASE

WARNING

Closely supervise children when they
are around cars to prevent them from
playing and becoming locked in the
trunk where they could be seriously
injured. Keep the car locked, with the
trunk lid securely latched, when not in
use, and prevent children’s access to
Intelligent Keys.

The interior trunk lid release mechanism allows
opening of the trunk lid in the event that people
become locked inside the trunk.

SPA2682

Releasing inside the trunk

To open the trunk lid from the inside, pull the
release handle

until the lock releases and

push up on the trunk lid. The release lever is
made of a material that glows in the dark after a
brief exposure to ambient light.

The handle

is located inside the trunk

compartment as illustrated.

Condition:

(145,1)

[ Edit: 2016/ 2/ 22

Model: 2017MY NISSAN 370Z(Z34) OM17E00Z34U0 ]

SPA2683

SECONDARY TRUNK LID RELEASE

The secondary trunk lid release mechanism
allows opening the trunk lid in the event of
discharged battery or emergency.

1. Open the rear parcel box.

2. Remove the cap

with a suitable tool

3. Insert the key into the key cylinder and turn it

counterclockwise. The trunk lid will open.

SPA2685

Interior/exterior view

Soft top indicator light (on the combination
meter)

Soft top operating switch

Top lock hole

Soft top

Top storage lid

Trunk lid

Rear window

BEFORE OPERATING THE TOP

The soft top of this vehicle is electrically
operated. You can fully open or close the top
only by pressing the operating switch located on
the center console.

The soft top operating switch must be operated

under all of the following conditions:

When the trunk is closed.

When the vehicle is stopped.

When the engine is running.

When the ignition switch is in the ON
position.

When the shift lever is in a position other
than the R (Reverse) position.

CAUTION

Always keep the engine running while
operating the soft top. The top will also

Pre-driving checks and adjustments

3-21

SOFT TOP (Roadster models)

Condition:

Content .. 7 8 9 10 ..
