Nissan Frontier D40. Manual - part 863

MWI

COMBINATION METER

MWI-57

< ECU DIAGNOSIS >

C

D

E

F

G

H

I

J

K

L

M

B

A

O

P

ABNIA1690GB

MWI-58

< ECU DIAGNOSIS >

COMBINATION METER

Fail Safe

INFOID:0000000005275833

The combination meter performs a fail-safe operation for the functions listed below when communication is
lost.

ABNIA1691GB

MWI

COMBINATION METER

MWI-59

< ECU DIAGNOSIS >

C

D

E

F

G

H

I

J

K

L

M

B

A

O

P

Function

Specifications

Speedometer

Zero indication.

Tachometer

Fuel gauge

Engine coolant temperature gauge

Engine oil pressure gauge (with VQ40DE)

Voltage gauge (with VQ40DE)

Illumination control

Meter illumination

Change to nighttime mode when communication is lost.

Segment LCD

Odometer

Freeze current indication.

A/T position

Display turns off.

Buzzer

Buzzer turns off.

Warning lamp/indicator lamp

ABS warning lamp

Lamp turns on when communication is lost.

Brake warning lamp

VDC OFF indicator lamp

Malfunction indicator lamp

SLIP indicator lamp

AT oil temp warning lamp

Lamp turns off when communication is lost.

Low washer fluid warning lamp

Hill descent control indicator lamp

Door open warning lamp

CRUISE indicator lamp

SET indicator lamp

O/D OFF indicator lamp

Oil pressure warning lamp

Air bag warning lamp

High beam indicator

Turn signal indicator lamp

Driver and passenger seat belt warn-
ing lamp

Lamp turns off when disconnected.

Charge warning lamp

Security indicator lamp

4WD indicator lamp

ATP indicator lamp

Differential lock indicator lamp

Low tire pressure warning lamp

Lamp will flash every second for 1 minute and then stay on con-
tinuously thereafter.

MWI-60

< ECU DIAGNOSIS >

COMBINATION METER

DTC Index

INFOID:0000000005275834

NOTE:
“TIME” indicates the following.
• 0: Indicates that a malfunction is detected at present.
• 1-63: Indicates that a malfunction was detected in the past. (Displays number of ignition switch OFF

→

 ON

cycles after malfunction is detected. Self-diagnosis result is erased when “63” is exceeded.)

CONSULT-III display

Malfunction

Reference

page

CAN COMM CIRC
[U1000]

Malfunction is detected in CAN communication.

CAUTION:

Even when there is no malfunction on CAN communication system, malfunction may be
misinterpreted when battery has low voltage (when maintaining 7 - 8 V for about 2 sec-
onds) or 10A fuse [No. 19, located in the fuse block (J/B)] is disconnected.

MWI-27

VEHICLE SPEED
CIRC
[B2205]

Malfunction is detected when an erroneous speed signal is input.

CAUTION:

Even when there is no malfunction on speed signal system, malfunction may be misin-
terpreted when battery has low voltage (when maintaining 7 - 8 V for about 2 seconds).

MWI-28
