ENGINE CONTROL SYSTEM EC-479 < FUNCTION DIAGNOSIS > [VQ40DE] C D E F G H I J K L M A EC N P O 1. EVAP canister purge volume control 2. EVAP service port 3. Oil filler cap 4. EVAP canister vent control valve 5. EVAP control system pressure sen- 6. Drain filter 7. EVAP canister 8. Power steering pressure sensor 9. Throttle valve (view with intake air 10. Electric throttle control actuator 11. Intake manifold collector 12. Intake valve timing control solenoid valve (bank 1) 13. Intake valve timing control solenoid valve (bank 2) (view with engine cov- 14. Cooling fan motor harness connec- tor (view with battery removed) 15. Fuel pump, fuel level sensor unit and fuel filter 16. Fuel pressure regulator : Front ALBIA0516ZZ |
