Nissan Frontier D40. Manual - part 116

BRC-162

< ECU DIAGNOSIS >

[TYPE 2]

ABS ACTUATOR AND ELECTRIC UNIT (CONTROL UNIT)

Fail-Safe

INFOID:0000000005548362

CAUTION:

If the Fail-Safe function is activated, perform Self Diagnosis for ABS/TCS/VDC system.

ABS/EBD SYSTEM

ABFIA0279GB

ABS ACTUATOR AND ELECTRIC UNIT (CONTROL UNIT)

BRC-163

< ECU DIAGNOSIS >

[TYPE 2]

C

D

E

G

H

I

J

K

L

M

A

B

BRC

N

O

P

In case of an electrical malfunction with the ABS, the ABS warning lamp, VDC OFF indicator lamp and SLIP
indicator lamp will turn on. In case of an electrical malfunction with the EBD system, the BRAKE warning lamp,
ABS warning lamp, VDC OFF indicator lamp and SLIP indicator lamp will turn on.
The system will revert to one of the following conditions of the Fail-Safe function.

1.

For ABS malfunction, only the EBD is operative and the condition of the vehicle is the same condition of
vehicles without ABS/TCS/VDC system.

2.

For EBD malfunction, the EBD and ABS become inoperative, and the condition of the vehicle is the same
as the condition of vehicles without ABS/TCS/VDC or EBD system.

HILL DESCENT CONTROL/HILL START ASSIST SYSTEM

In case of hill descent control system malfunction, the hill descent control indicator lamp will remain off even
though the hill descent control switch is operated and the condition of the vehicle is the same as the condition
of vehicles without hill descent control system.
In case of hill start assist system malfunction, the VDC OFF and SLIP indicator lamps are turned on and the
condition of the vehicle is the same as the condition of vehicles without hill start assist system.

VDC/TCS SYSTEM

In case of TCS/VDC system malfunction, the VDC OFF indicator lamp and SLIP indicator lamp are turned on
and the condition of the vehicle is the same as the condition of vehicles without TCS/VDC system. In case of
an electrical malfunction with the TCS/VDC system, the ABS control continues to operate normally without
TCS/VDC control.

DTC No. Index

INFOID:0000000005548363

DTC

Items (CONSULT screen terms)

Reference

C1101

RR RH SENSOR-1

BRC-100, "Description"

C1102

RR LH SENSOR-1

C1103

FR RH SENSOR-1

C1104

FR LH SENSOR-1

C1105

RR RH SENSOR-2

BRC-103, "Description"

C1106

RR LH SENSOR-2

C1107

FR RH SENSOR-2

C1108

FR LH SENSOR-2

C1109

BATTERY VOLTAGE [ABNORMAL]

BRC-106, "Description"

C1110

CONTROLLER FAILURE

BRC-108, "DTC Logic"

C1111

PUMP MOTOR

BRC-109, "Description"

C1113

G-SENSOR

BRC-111, "Description"

C1115

ABS SENSOR [ABNORMAL SIGNAL]

BRC-113, "Description"

C1116

STOP LAMP SW

BRC-116, "Description"

C1120

FR LH IN ABS SOL

BRC-118, "Description"

C1121

FR LH OUT ABS SOL

BRC-121, "Description"

C1122

FR RH IN ABS SOL

BRC-118, "Description"

C1123

FR RH OUT ABS SOL

BRC-121, "Description"

C1124

RR LH IN ABS SOL

BRC-118, "Description"

C1125

RR LH OUT ABS SOL

BRC-121, "Description"

C1126

RR RH IN ABS SOL

BRC-118, "Description"

C1127

RR RH OUT ABS SOL

BRC-121, "Description"

BRC-164

< ECU DIAGNOSIS >

[TYPE 2]

ABS ACTUATOR AND ELECTRIC UNIT (CONTROL UNIT)

C1130

ENGINE SIGNAL 1

BRC-124, "Description"

C1131

ENGINE SIGNAL 2

C1132

ENGINE SIGNAL 3

C1133

ENGINE SIGNAL 4

C1136

ENGINE SIGNAL 6

C1140

ACTUATOR RLY

BRC-126, "Description"

C1143

ST ANG SEN CIRCUIT

BRC-128, "Description"

C1144

ST ANG SEN SIGNAL

C1145

YAW RATE SENSOR

BRC-111, "Description"

C1146

SIDE G-SEN CIRCUIT

C1155

BR FLUID LEVEL LOW

BRC-131, "Description"

C1156

ST ANG SEN COM CIR

BRC-134, "Description"

C1160

DECEL G SEN SET

BRC-135, "Description"

C1163

ST ANGL SEN SAFE

BRC-136, "Description"

C1164

CV1

BRC-137, "Description"

C1165

CV2

C1166

SV1

C1167

SV2

C1170

VARIANT CODING

BRC-108, "DTC Logic"

C1187

ABS DIFLOCK CONTROLLER NG

BRC-140, "Description"

U1000

CAN COMM CIRCUIT

BRC-141, "Description"

DTC

Items (CONSULT screen terms)

Reference

APPLICATION NOTICE

BRC-165

< SYMPTOM DIAGNOSIS >

[TYPE 2]

C

D

E

G

H

I

J

K

L

M

A

B

BRC

N

O

P

SYMPTOM DIAGNOSIS

APPLICATION NOTICE

Application Notice

INFOID:0000000005548390

Service information

Remarks

TYPE 1

ABS

TYPE 2

VDC/TCS/ABS

TYPE 3

HILL DESCENT CONTROL/HILL START ASSIST/VDC/TCS/ABS
