BCM (BODY CONTROL MODULE) WT-23 < ECU DIAGNOSIS > C D F G H I J K L M A B WT N O P FAN ON SIG Blower fan motor switch OFF OFF Blower fan motor switch ON (other than OFF) ON AIR COND SW Compressor ON is not requested from auto amp. OFF Compressor ON is requested from auto amp. ON OIL PRESS SW • Ignition switch OFF or ACC OFF Ignition switch ON ON AIR PRESS FL Ignition switch ON (Only when the signal from the transmitter is re- Air pressure of front LH tire AIR PRESS FR Ignition switch ON (Only when the signal from the transmitter is re- Air pressure of front RH tire AIR PRESS RR Ignition switch ON (Only when the signal from the transmitter is re- Air pressure of rear RH tire AIR PRESS RL Ignition switch ON (Only when the signal from the transmitter is re- Air pressure of rear LH tire ID REGST FL1 ID of front LH tire transmitter is registered DONE ID of front LH tire transmitter is not registered YET ID REGST FR1 ID of front RH tire transmitter is registered DONE ID of front RH tire transmitter is not registered YET ID REGST RR1 ID of rear RH tire transmitter is registered DONE ID of rear RH tire transmitter is not registered YET ID REGST RL1 ID of rear LH tire transmitter is registered DONE ID of rear LH tire transmitter is not registered YET WARNING LAMP Tire pressure indicator OFF OFF Tire pressure indicator ON ON BUZZER Tire pressure warning alarm is not sounding OFF Tire pressure warning alarm is sounding ON Monitor Item Condition Value/Status |
