Nissan Frontier D40. Manual - part 1025
STARTER MOTOR
STR-33
< ON-VEHICLE REPAIR >
C
D
E
F
G
H
I
J
K
L
M
A
STR
N
P
O
ON-VEHICLE REPAIR
STARTER MOTOR
Removal and Installation (QR25DE)
INFOID:0000000005276073
REMOVAL
1.
Disconnect the negative battery terminal.
2.
Remove the air cleaner cover and the air cleaner to intake manifold collector duct. Refer to
3.
Remove terminal "1" (S) and terminal "2" (B) nuts.
4.
Remove the two starter motor bolts, using power tools.
5.
Remove the starter motor.
INSTALLATION
Installation is in the reverse order of removal.
CAUTION:
Be sure to tighten terminal nuts carefully.
AWBIA0854GB
1.
Starter motor assembly
2.
Transmission housing
3.
Engine oil cooler
4.
Terminal "1" (S) nut
5.
Terminal "2" (B) nut
