SRC-80 < ECU DIAGNOSIS > DIAGNOSIS SENSOR UNIT CONSULT-III name DTC DTC detecting condition Repair order DRIVER AIRBAG MODULE [OPEN] B1049 Driver air bag module circuit (DR1) is 1. Visually check the wiring harness connection. 2. Replace the harness if it has visible damage. 3. Replace the driver air bag module. 4. Replace the spiral cable. 5. Replace the air bag diagnosis sensor unit. 6. Replace the related harness. B1054 Driver air bag module circuit (DR2) is DRIVER AIRBAG MODULE [VB-SHORT] B1050 Driver air bag module circuit (DR1) is B1055 Driver air bag module circuit (DR2) is DRIVER AIRBAG MODULE [GND-SHORT] B1051 Driver air bag module circuit (DR1) is B1056 Driver air bag module circuit (DR2) is DRIVER AIRBAG MODULE [SHORT] B1052 Driver air bag module circuits (DR1) are B1057 Driver air bag module circuits (DR2) are ASSIST A/B MODULE [OPEN] B1065 Front passenger air bag module circuit 1. Visually check the wiring harness connection. 2. Replace the harness if it has visible damage. 3. Replace the front passenger air bag module. 4. Replace the air bag diagnosis sensor unit. 5. Replace the related harness. B1070 Front passenger air bag module circuit ASSIST A/B MODULE [VB-SHORT] B1066 Front passenger air bag module circuit B1071 Front passenger air bag module circuit ASSIST A/B MODULE [GND-SHORT] B1067 Front passenger air bag module circuit B1072 Front passenger air bag module circuit ASSIST A/B MODULE [SHORT] B1068 Front passenger air bag module circuits B1073 Front passenger air bag module circuits SIDE MODULE LH [OPEN] B1134 Front LH side air bag module circuit is 1. Visually check the wiring harness connection. 2. Replace the harness if it has visible damage. 3. Replace the front LH seat back assembly. 4. Replace the air bag diagnosis sensor unit. 5. Replace the related harness. SIDE MODULE LH [VB-SHORT] B1135 Front LH side air bag module circuit is SIDE MODULE LH [GND-SHORT] B1136 Front LH side air bag module circuit is SIDE MODULE LH [SHORT] B1137 Front LH side air bag module circuits are |
