Trouble Diagnoses

Alarm Trigger Feedback

To verify the last three triggers that activated the theft warning system, the Time Control Unit (TCU) can be
switched into Diagnostic Mode (see page EL-218 how to enter Diagnostic Mode).
Approximately 2 seconds after the TCU has finished flashing the hazard lamp to confirm that the Diagnostic
Mode has been successfully entered, the TCU will generate a short beep indicating the trigger that will be dis-
played. A single beep means the most recent trigger, three beeps means the oldest trigger. Following each
beep or group of beeps, the hazard lamp will flash to indicate the alarm trigger.

Source of Alarm Trigger

Number (of flashes)

Driver’s door lock status switch

1

Passenger door lock status switch

2

Rear door lock status switch

3

Ignition line

4

Driver’s door open switch

5

Other door open switch

6

Trunk or back door open switch

8

Hood switch

9

Ultrasonic sensors

10

In case there have been no alarm triggers, there will be no indicator flashes between the audible signals. After
completing the alarm trigger feedback, the TCU will enter Diagnostic Mode as described on page EL-218.
Before continuing trouble diagnoses on the next page, perform the checks as mentioned in the table on page
EL-219.

THEFT WARNING SYSTEM

EL-264

PRELIMINARY CHECK

The system operation is canceled by turning the ignition switch to “ON” at any step between START and
ARMED in the following flow chart.

System phase

START

Note: Before starting operation check, open front windows.

E

DISARMED

Turn ignition switch “OFF” and remove the ignition key.
“SECURITY” indicator lamp will blink every 2.6 seconds.
(NATS)

OK

E

NG

Refer to NATS
trouble diagno-
sis.

Close all doors, hood and trunk lid.

Press the ultrasonic cancel switch. The “SECURITY” indicator lamp
will go on for approximately 6 seconds.

OK

E

NG

SYMPTOM 1

PRE-ARMED

Lock doors using key or multi-remote controller.

ARMED

For about 30 seconds, “SECURITY” indicator lamp will blink inter-
mittently.

OK

E

NG

SYMPTOM 2

Disarm the system by unlocking the vehicle using the remote con-
troller. Arm the system again without excluding the ultrasonic sen-
sors.

ALARM

Unlock any door without multi-remote controller, activate the ultra-
sonic sensors by inserting an object into the vehicle’s interior, or
open hood or door.
.......................................................................................................
Alarm (horn and hazard lamp) will operate.

OK

E

NG

SYMPTOM 3

E

NG

SYMPTOM 4

E

DISARMED

Unlock the vehicle using the multi-remote controller or insert the
key in the ignition and switch it to ON.
Alarm (horn and hazard lamp) will stop.

OK

E

NG

SYMPTOM 5

System is OK.

After performing preliminary check, go to “SYMPTOM CHART”, EL-266.

H

H

H

H

H

H

H

H

H

H

H

H

H

THEFT WARNING SYSTEM

Trouble Diagnoses (Cont’d)

EL-265

Before starting trouble diagnoses below, perform “PRELIMINARY CHECK”, EL-265.
Symptom numbers in the symptom chart correspond with those of Preliminary check.

SYMPTOM CHART

Procedure

Power supply

and ground cir-

cuit check

Diagnostic procedure

REFERENCE PAGE

EL-265

EL-267

EL-267

EL-268

EL-270

EL-271

EL-272

EL-273

EL-274

EL-204

EL-222

SYMPTOM

Preliminary

check

Power

supply

circuit

check

Ground

circuit

check

Diagnostic

Procedure

1

(Door

,

hood

and

back

door

switch

check)

Diagnostic

Procedure

2

(Security

indicator

lamp

check)

Diagnostic

Procedure

3

(Door

unlock

sensor

check)

Diagnostic

Procedure

4

(Door

key

cylinder

switch

check)

Diagnostic

Procedure

5

(Theft

warning

horn

alarm

check)

Diagnostic

procedure

6

(Hazard

lamp

alarm

check)

Check

“MUL

TI-REMOTE

CONTROL”

system.

Check

“NA

TS

(Nissan

Anti-Theft

system)”.

1

Security indicator does not turn “ON” or

blinking.

X

X

X

X

2

Theft

warning

system

cannot

be set

by...

All items

X

X

X

X

X

Door out side key

X

X

X

X

Multi-remote control

X

X

X

X

3

*1 Theft

warning

system

does not

alarm

when...

Any door is opened.

X

X

X

X

Any door is unlocked with-

out using key or multi-re-

mote controller

X

X

X

X

4

Theft

warning

alarm

does not

activate.

All function

X

X

X

X

X

Horn alarm

X

X

X

X

Hazard lamp

X

X

X

X

5

Theft

warning

system

cannot be

canceled

by...

Turning the ignition ON *2

X

X

X

X

Multi-remote controller

X

X

X

X

X: Applicable
*1: Make sure the system is in the armed phase.
*2: Make sure the key is NATS registered.

THEFT WARNING SYSTEM

Trouble Diagnoses (Cont’d)

EL-266

POWER SUPPLY AND GROUND CIRCUIT CHECK

Main power supply circuit check

Terminals

Ignition switch position

!

@

OFF

ACC

ON

U09

Ground

Battery
voltage

Battery
voltage

Battery
voltage

U01

Ground

0V

0V

Battery
voltage

Ground circuit check

Terminals

Continuity

U16

- Ground

Yes

NEL606

YEL336D

THEFT WARNING SYSTEM

Trouble Diagnoses (Cont’d)

EL-267
