BCM (BODY CONTROL MODULE)

WT-29

< ECU DIAGNOSIS INFORMATION >

R/G

Combination switch
output 5

Output

Lighting, turn, wiper OFF
Wiper dial position 4

R/Y

Combination switch
output 4

Output

Lighting, turn, wiper OFF
Wiper dial position 4

Combination switch
output 3

Output

Lighting, turn, wiper OFF
Wiper dial position 4

O/B

Combination switch
output 2

Output

Lighting, turn, wiper OFF
Wiper dial position 4

R/W

Combination switch
output 1

B/R

Key switch and key
lock solenoid

Input

OFF

Key inserted

Battery voltage

Key removed

W/L

Ignition switch (ON)

Input

—

Battery voltage

CAN-H

—

CAN-L

—

Y/B

Rear defogger switch

Input

Rear defogger switch ON

Rear defogger switch OFF

Front door switch LH
(All)

Input

OFF

ON (open)

Rear door switch lower
LH (King Cab)

Rear door switch up-
per LH (King Cab)

OFF (closed)

Battery voltage

R/Y

Rear door switch LH
(Crew Cab)

Input

OFF

ON (open)

OFF (closed)

Battery voltage

R/Y

Cargo bed lamp con-
trol

Output

OFF

Cargo lamp switch (ON)

Cargo lamp switch (OFF)

Battery voltage

Terminal

Wire

color

Signal name

Signal

input/

output

Measuring condition

Reference value or waveform

(Approx.)

Ignition

switch

Operation or condition

SKIA5291E

SKIA5292E

SKIA5291E

SKIA5292E

WT-30

< ECU DIAGNOSIS INFORMATION >

BCM (BODY CONTROL MODULE)

Y/B

Trailer turn signal
(right)

Output

Turn right ON

G/B

Trailer turn signal (left)

Output

Turn left ON

R/G

Battery saver output

Output

OFF

15 minutes after ignition switch
is turned OFF

—

Battery voltage

Y/R

Battery power supply

Input

OFF

—

Battery voltage

W/R

Optical sensor

Input

When optical sensor is illumi-
nated

3.1V or more

When optical sensor is not illu-
minated

0.6V or less

Front door lock as-
sembly LH actuator
(unlock)

Output

OFF

OFF (neutral)

ON (unlock)

Battery voltage

G/B

Turn signal (left)

Output

Turn left ON

G/Y

Turn signal (right)

Output

Turn right ON

R/W

Step lamp LH and RH

Output

OFF

ON (any door open)

OFF (all doors closed)

Battery voltage

Interior room/map
lamp

Output

OFF

Any door
switch

ON (open)

OFF (closed)

Battery voltage

All door lock actuators
(lock)

Output

OFF

OFF (neutral)

ON (lock)

Battery voltage

G/Y

Front door lock actua-
tor RH and rear door
lock actuators LH/RH
(unlock)

Output

OFF

OFF (neutral)

ON (unlock)

Battery voltage

Terminal

Wire

color

Signal name

Signal

input/

output

Measuring condition

Reference value or waveform

(Approx.)

Ignition

switch

Operation or condition

SKIA3009J

BCM (BODY CONTROL MODULE)

WT-31

< ECU DIAGNOSIS INFORMATION >

Self-Diagnosis (With CONSULT)

INFOID:0000000009885658

NOTE:

The Signal Tech II Tool (J-50190) can be used to perform the following functions. Refer to the Signal Tech II

User Guide for additional information.

• Activate and display TPMS transmitter IDs

• Display tire pressure reported by the TPMS transmitter

• Read TPMS DTCs

• Register TPMS transmitter IDs

FUNCTION

Self-Diagnostic Results Mode

Ground

Input

—

W/L

Power window power
supply (RAP)

Output

—

Ignition switch ON

Battery voltage

Within 45 seconds after igni-
tion switch OFF

Battery voltage

More than 45 seconds after ig-
nition switch OFF

When front door LH or RH is
open or power window timer
operates

W/R

Power window power
supply

Output

—

Battery voltage

W/B

Battery power supply

Input

OFF

—

Battery voltage

Terminal

Wire

color

Signal name

Signal

input/

output

Measuring condition

Reference value or waveform

(Approx.)

Ignition

switch

Operation or condition

Diagnostic item

Diagnostic item is detected when ···

Reference

page

LOW - PRESSURE - FL [C1704]
LOW - PRESSURE - FR [C1705]
LOW - PRESSURE - RR [C1706]
LOW - PRESSURE - RL [C1707]

Tire pressures dropped below specified value. Refer to

WT-8,

"System Description"

—

[NO-DATA] - FL [C1708]
[NO-DATA] - FR [C1709]
[NO-DATA] - RR [C1710]
[NO-DATA] - RL [C1711]

Data from FL transmitter cannot be received.
Data from FR transmitter cannot be received.
Data from RR transmitter cannot be received.
Data from RL transmitter cannot be received.

WT-14

[CHECKSUM- ERR] - FL [C1712]
[CHECKSUM- ERR] - FR [C1713]
[CHECKSUM- ERR] - RR [C1714]
[CHECKSUM- ERR] - RL [C1715]

Checksum data from FL transmitter is malfunctioning.
Checksum data from FR transmitter is malfunctioning.
Checksum data from RR transmitter is malfunctioning.
Checksum data from RL transmitter is malfunctioning.

WT-16

[PRESSDATA- ERR] - FL [C1716]
[PRESSDATA- ERR] - FR [C1717]
[PRESSDATA- ERR] - RR [C1718]
[PRESSDATA- ERR] - RL [C1719]

Air pressure data from FL transmitter is malfunctioning.
Air pressure data from FR transmitter is malfunctioning.
Air pressure data from RR transmitter is malfunctioning.
Air pressure data from RL transmitter is malfunctioning.

WT-18

[CODE- ERR] - FL [C1720]
[CODE- ERR] - FR [C1721]
[CODE- ERR] - RR [C1722]
[CODE- ERR] - RL [C1723]

Function code data from FL transmitter is malfunctioning.
Function code data from FR transmitter is malfunctioning.
Function code data from RR transmitter is malfunctioning.
Function code data from RL transmitter is malfunctioning.

WT-16

[BATT - VOLT - LOW] - FL [C1724]
[BATT - VOLT - LOW] - FR [C1725]
[BATT - VOLT - LOW] - RR [C1726]
[BATT - VOLT - LOW] - RL [C1727]

Battery voltage of FL transmitter drops.
Battery voltage of FR transmitter drops.
Battery voltage of RR transmitter drops.
Battery voltage of RL transmitter drops.

WT-16

VHCL_SPEED_SIG_ERR [C1729]

Vehicle speed signal is in error.

WT-20

IGN_CIRCUIT_OPEN [C1735]

Ignition signal is in error.

WT-21

WT-32

< ECU DIAGNOSIS INFORMATION >

BCM (BODY CONTROL MODULE)

NOTE:
Before performing the self-diagnosis, be sure to register the ID or else the actual malfunction location may be different from that dis-
played on CONSULT.

Self-Diagnosis (Without CONSULT)

INFOID:0000000009885659

NOTE:

The Signal Tech II Tool (J-50190) can be used to perform the following functions. Refer to the Signal Tech II

User Guide for additional information.

• Activate and display TPMS transmitter IDs

• Display tire pressure reported by the TPMS transmitter

• Read TPMS DTCs

• Register TPMS transmitter IDs

SELF DIAGNOSTIC PROCEDURE (WITHOUT CONSULT)

1. Turn ignition switch ON.

2. Ground the tire pressure warning check connector to initiate self diagnosis.

3. Compare the flashing pattern with the flash code chart below.

NOTE:

The system is normal when the low tire pressure warning lamp flashes 5 times and continues repeating. Self-

diagnosis results are erased automatically by turning the ignition switch “OFF”.

Flash Code

Malfunction part

Reference

page

15
16
17
18

Tire pressure dropped below specified value. Refer to

WT-8, "System

Description"

—

21
22
23
24

Transmitter no data (FL)
Transmitter no data (FR)
Transmitter no data (RR)
Transmitter no data (RL)

WT-14

31
32
33
34

Transmitter checksum error (FL)
Transmitter checksum error (FR)
Transmitter checksum error (RR)
Transmitter checksum error (RL)

WT-16

35
36
37
38

Transmitter pressure data error (FL)
Transmitter pressure data error (FR)
Transmitter pressure data error (RR)
Transmitter pressure data error (RL)

WT-18

41
42
43
44

Transmitter function code error (FL)
Transmitter function code error (FR)
Transmitter function code error (RR)
Transmitter function code error (RL)

WT-16

45
46
47
48

Transmitter battery voltage low (FL)
Transmitter battery voltage low (FR)
Transmitter battery voltage low (RR)
Transmitter battery voltage low (RL)

WT-16
