MA-20

< PERIODIC MAINTENANCE >

PERIODIC MAINTENANCE

Maintenance for off-road driving (4WD only)

Whenever you drive off-road through sand, mud or water, more frequent maintenance may be required of the

following items.

• Brake pads and rotors

• Brake lines and hoses

• Differential gear oil, transfer fluid and automatic transmission fluid

• Steering linkage

• Propeller shafts and front drive shafts

• Air cleaner filter

A

.

C

.

.

.

G H

I

Brake pads, drums & linings

Inspect

Every 5,000 km (3,000
miles) or 3 months

MA-43,

"DISC

BRAKE :

Checking

Disc

Brake"

A

.

.

.

.

.

.

.

.

Air  conditioner  filter

Replace

More  frequently

MA-34,

"IN-CAB-

IN MICRO-

FILTER :
Removal

and Instal-

lation"

RECOMMENDED FLUIDS AND LUBRICANTS

MA-21

< PERIODIC MAINTENANCE >

C

D

E

F

G

H

I

J

K

L

M

B

MA

N

O

A

RECOMMENDED FLUIDS AND LUBRICANTS

FOR NORTH AMERICA
FOR NORTH AMERICA : Fluids and Lubricants

INFOID:0000000006748436

*1: For further details, refer to

MA-22, "FOR NORTH AMERICA : Engine Oil Recommendation"

 .

*2: If Genuine NISSAN Matic S ATF is not available, Genuine Matic J ATF may also be used. Using automatic transmission fluid
other than Genuine NISSAN Matic S ATF or Matic J ATF will cause deterioration in driveability and automatic transmission
durability, and may damage the automatic transmission, which is not covered by the NISSAN new vehicle limited warranty.

*3: DEXRON

TM

  VI type ATF may also be used.

*4: Available in mainland U.S.A. through a NISSAN dealer.
*5: For further details, see “Air conditioner specification label”.
*6: See a NISSAN dealer for service for synthetic oil.
*7: For further details, refer to

GI-28, "Precaution for Fuel (Unleaded Regular Gasoline Recommended)"

.

*8: For hot climates, Viscosity SAE 90 is suitable for ambient temperatures above 0

°C (32°F).

*9: Using fluid other than Genuine NISSAN Matic D ATF will cause deterioration in driveability and transfer durability, and may
damage the transfer, which is not covered by the NISSAN new vehicle limited warranty.

Description

Capacity (Approximate)

Recommended Fluids/Lubricants

Metric

US measure

Imp measure

Windshield Washer Fluid

4.5

1 1/4 gal

1 gal

Genuine NISSAN Windshield Washer Con-
centrate & Antifreeze or equivalent

Fuel

105.8

28 gal

23 1/4 gal

Unleaded gasoline with an octane rating of
at least 87 AKI (RON 91), or E-85 Ethanol
fuel for Flexible Fuel Vehicles (FFV) *7

Engine oil
Drain and refill

With oil filter
change

6.5

6 7/8 qt

5 3/4 qt

• Engine oil with API Certification Mark*1
• Viscosity SAE 5W-30

Without oil filter
change

6.2

6 1/2 qt

5 1/2 qt

Dry engine (engine overhaul)

7.6

 8 qt

6 3/4 qt

Cooling system

With reservoir
at MAX level

12.2

12 7/8 qt

10 3/4 qt

Genuine NISSAN Long Life Anti-freeze
coolant (blue) or equivalent

Automatic transmission fluid (ATF)

10.6

11 1/4 qt

9 3/8 qt

Genuine NISSAN Matic S ATF*2

Rear differential gear oil

2.01

4 1/4 pt

3 1/2 pt

Genuine NISSAN differential oil synthetic
75W-140 or API GL-5 synthetic gear oil, Vis-
cosity SAE 75W-140 *6

Transfer fluid

2.0

2 1/8 qt

1 3/4 qt

Genuine NISSAN Matic D ATF (Continental
U.S and Alaska) or Canada NISSAN Auto-
matic Transmission Fluid or equivalent (if
available)*9

Front differential gear oil

1.6

3 3/8 pt

2 7/8 pt

Genuine NISSAN Differential Oil Hypoid Su-
per GL-5 80W-90 or API GL-5 Viscosity
SAE 80W-90 *8

Power steering fluid (PSF)

1.0

1 1/8 qt

 7/8 qt

Genuine NISSAN PSF or equivalent*3

Brake fluid

Genuine NISSAN Super Heavy Duty Brake
Fluid*4 or equivalent,
DOT 3 (US FMVSS No. 116)

Multi-purpose grease

NLGI No. 2 (lithium soap base)

Windshield washer fluid

4.5

4 3/4 qt

4 qt

Genuine NISSAN Windshield Washer Con-
centrate Cleaner & Anti-freeze or equivalent

Air conditioning system refrigerant

0.70

± 0.05 kg

1.54

± 0.11 lb

1.54

± 0.11 lb

HFC-134a (R-134a)*5

Air conditioning system oil

200 m

6.8 fl oz

7.0 fl oz

A/C System Oil Type S  (DH-PS) *5

MA-22

< PERIODIC MAINTENANCE >

RECOMMENDED FLUIDS AND LUBRICANTS

FOR NORTH AMERICA : Engine Oil Recommendation

INFOID:0000000006748437

NISSAN recommends the use of an energy conserving oil in order to

improve fuel economy. Select only engine oils that meet the Ameri-

can Petroleum Institute (API) certification and International Lubricant

Standardization and Approval Committee (ILSAC) certification and

SAE viscosity standard (2). These oils have the API certification

mark (1) on the front of the container. Oils which do not have the

specified quality label should not be used as they could cause

engine damage.

FOR NORTH AMERICA : Engine Coolant Mixture Ratio

INFOID:0000000006750395

MIXTURE RATIO

The engine cooling system is filled at the factory with a high-quality, year-round, anti-freeze coolant solution.

The anti-freeze solution contains rust and corrosion inhibitors. Therefore, additional cooling system additives

are not necessary.

CAUTION:

• When adding or replacing coolant, be sure to use only genuine NISSAN Engine Coolant (blue) or

equivalent in quality with the proper mixture ratio as specified.

• Mixing any other type of coolant or the use of non-distilled water will reduce the life expectancy of

the factory-fill coolant.

FOR MEXICO
FOR MEXICO : Fluids and Lubricants

INFOID:0000000006748439

ALPIA0001ZZ

Anti-freeze coolant mixure ratio

Protection for outside temperature down to:

Genuine NISSAN Engine Coolant or equiv-

alent

Demineralized water or distilled water

°C

°F

–35

°

–30

°

50%

50%

Description

Capacity (Approximate)

Recommended Fluids/Lubricants

Metric

US measure

Imp measure

Windshield Washer Fluid

4.5

1 1/4 gal

1 gal

Genuine NISSAN Windshield Washer Fluid
or equivalent

Fuel

105.8

28 gal

23 1/4 gal

Unleaded gasoline with an octane rating of
at least 87 AKI (RON 91)

RECOMMENDED FLUIDS AND LUBRICANTS

MA-23

< PERIODIC MAINTENANCE >

C

D

E

F

G

H

I

J

K

L

M

B

MA

N

O

A

*1: For further details, refer to

MA-23, "FOR MEXICO : SAE Viscosity Number"

 .

*2: Use Genuine NISSAN Engine Coolant or equivalent in its quality, in order to avoid possible aluminium corrosion within the
engine cooling system caused by the use of non-genuine engine coolant. Note that any repairs for the incidents within the
engine cooling system while using non-genuine engine coolant may not be covered by the warranty even if such incidents
occurred during the warranty period.
*3: If Genuine NISSAN Matic S ATF is not available, Genuine NISSAN Matic J ATF may also be used. Using automatic transmis-
sion fluid other than Genuine NISSAN Matic S ATF or Matic J ATF will cause deterioration in driveability and automatic trans-
mission durability, and may damage the automatic transmission, which is not covered by the warranty
*4: See a NISSAN dealer for service for synthetic oil.
*5: Using fluid other than Genuine NISSAN Matic D ATF will cause deterioration in driveability and transfer durability, and may damage
the transfer, which is not covered by the warranty.

*6: DEXRON

TM

 VI type ATF may also be used.

*7: For further details, see “Air conditioner specification label”.

FOR MEXICO : SAE Viscosity Number

INFOID:0000000006748440

GASOLINE ENGINE OIL

Engine oil
Drain and refill

With oil filter
change

6.5

6 7/8 qt

5 3/4 qt

• Genuine NISSAN engine oil *1
• API grade SL or SM *1
• ILSAC grade GF-2, GF-3 or GF-4 *1
• Viscosity SAE 10W-30 *1

Without oil filter
change

6.2

6 1/2 qt

5 1/2 qt

Dry engine (engine overhaul)

7.6

 8 qt

6 3/4 qt

Cooling system

With reservoir
at MAX level

12.2

12 7/8 qt

10 3/4 qt

Genuine NISSAN Engine Coolant or equiv-
alent in its quality*2

Automatic transmission fluid (ATF)

10.6

11 1/4 qt

9 3/8 qt

Genuine NISSAN Matic S ATF*3

Rear differential gear oil

2.01

4 1/4 pt

3 1/2 pt

API GL-5 Synthetic gear oil,Viscosity SAE
75W-140 or equivalent *4

Transfer fluid

2.0

2 1/8 qt

1 3/4 qt

Genuine NISSAN Matic D ATF recommend-
ed *5

Front differential gear oil

1.6

3 3/8 pt

2 7/8 pt

Genuine NISSAN Differential Oil Hypoid Su-
per GL-5 80W-90 or API GL-5 *1

Power steering fluid (PSF)

1.0

1 1/8 qt

 7/8 qt

Genuine NISSAN PSF or equivalent *6

Brake fluid

Genuine NISSAN Brake Fluid, or equivalent
DOT 3 (US FMVSS No. 116)

Multi-purpose grease

NLGI No. 2 (lithium soap base)

Windshield washer fluid

4.5

4 3/4 qt

4 qt

Windshield washer fluid

Air conditioning system refrigerant

0.70

± 0.05 kg

1.54

± 0.11 lb

1.54

± 0.11 lb

HFC-134a (R-134a) *7

Air conditioning system oil

200 m

6.8 fl oz

7.0 fl oz

A/C System Oil Type S (DH-PS) *7

Description

Capacity (Approximate)

Recommended Fluids/Lubricants

Metric

US measure

Imp measure
